Y71
ELGIN MUNI
PublicPUB

1 miles S of ELGIN, ND
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
46° 22' 58"N 101° 50' 42"W
2355' MSL
3355' MSL
10E
None Listed
GRAND FORKS (GFK)
BILLINGS
MINNEAPOLIS (ZMP)
7/11/24-8/8/24
KD57 (26nm) MVFR
5:35 AM CDT
Overcast 2,500'
Broken 2,000'
10sm
59°F
55°F
29.54"Hg
240° 9kts
AO2
KD57 191035Z AUTO 24009KT 10SM BKN020 OVC025 15/13 A2954 RMK AO2
Add Your Business

Y71 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 122.9

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

  • No Documents

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

  • No Documents

Terminal Area Forecast

KDIK (47nm)
Thu, 9/19 2:15 AM MDT
Thu, 9/19 2:00 AM MDT - Fri, 9/20 12:00 AM MDT
MVFR
2:00 AM MDT - 10:00 AM MDT
Broken 1,500'
6sm
250° 17kts
Gusts 25kts
MVFR
10:00 AM MDT - 1:00 PM MDT
Broken 2,500'
6sm
280° 22kts
Gusts 30kts
VFR
1:00 PM MDT - 8:00 PM MDT
Scattered 9,000'
6sm
280° 23kts
Gusts 33kts
VFR
8:00 PM MDT - 12:00 AM MDT
Few 25,000'
6sm
280° 11kts
Gusts 19kts
KDIK 190815Z 1908/2006 25017G25KT P6SM BKN015
   FM191600 28022G30KT P6SM BKN025
   FM191900 28023G33KT P6SM SCT090
   FM200200 28011G19KT P6SM FEW250
Y71
Domestic
8/15/241346Z !GFK 08/148 Y71 OBST TOWER LGT (ASN 2018-AGL-20106-OE) 461513N1011950W (22.7NM ESE Y71) 2719FT (404FT AGL) U/S 2408151346-2409291346
5/2/242122Z !GFK 05/032 Y71 OBST TOWER LGT (ASR 1264535) 463154.90N1013310.60W (15.0NM NE Y71) 2436.7FT (259.8FT AGL) U/S 2405022122-2409302359
No
UNATNDD
ELGIN ARPT AUTHORITY
7125 67TH AVE SW
ELGIN, ND 58533
Phone: 701-220-3442
AARON LEVORSEN
7125 67TH AVE SW
ELGIN, ND 58533
Phone: 701-220-3442
GRAND FORKS FSS (GFK)
Toll Free: 1-800-WX-BRIEF
GFK
--
--
N/A
Yes
No
No
Tie-Down
No
2
0
0
0
0
0
None
None
None
None
None

Runway 12/30

2842 ft. x 120 ft.
TURF
Fair
NONE


--
--
--
--
  Runway 12 Runway 30
True Heading 137°317°
Traffic Pattern Left Left
Markings NONE NONE
Markings Condition
Latitude 46° 23' 08"N 46° 22' 48"N
Longitude 101° 50' 56"W 101° 50' 28"W
Elevation 2,343' 2,355'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No
A110-1CONFIRM SNOW REMOVAL; ON REQUEST ONLY IN WINTER MOS WITH AMGR BEFORE USE 701-584-3442.
A110-2NO LINE-OF-SIGHT BTN RWYS 12 & 30 BGNG 500'FM RWY 12 END & 1000'FM RWY 30 END TO A HGT OF 20' MID-CNTR.
A110-4RWY 30; 10 FT DROPOFF 100 FT FROM THR OUTBOUND.
A110-5FOR CD CTC MINNEAPOLIS ARTCC AT 651-463-5588.
ELGIN MUNI (IATA: Y71) is a public airport located in ELGIN, ND.
