1/21/251845Z
|
!FDC 5/5323 Y50 PART 1 OF 4 ODP WAUTOMA MUNI, WAUTOMA, WI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG-A...
TAKEOFF OBSTACLE NOTES: RWY 13: TREE 75 FT FROM DER,489 FT RIGHT
OF CENTERLINE, 891FT MSL.
TREES BEGINNING 154 FT FROM DER, 26 FT RIGHT OF CENTERLINE, UP TO
894 FT MSL.
TRAVERSE WAY BEGINNING 344 FT FROM DER, 297 FT LEFT OF CENTERLINE,
UP TO 870 FT MSL.
TREE 622 FT FROM DER, 373 FT LEFT OF CENTERLINE, 873 FT MSL.
TREE 757 FT FROM DER, 374 FT LEFT OF CENTERLINE, 875 FT MSL.
TREE 1006 FT FROM DER, ON CENTERLINE, 905 FT MSL.
TREE 1027 FT FROM DER, 13 FT RIGHT OF CENTERLINE, 906 FT MSL.
TREE 1037 FT FROM DER, 38 FT LEFT OF CENTERLINE, 897 FT MSL.
TREES BEGINNING 1040 FT FROM DER, 8 FT LEFT OF CENTERLINE, UP TO
904 FT MSL.
TREE 1092 FT FROM DER, 284 FT RIGHT OF CENTERLINE, 914 FT MSL.
TREES BEGINNING 1123 FT FROM DER, 12 FT LEFT OF CENTERLINE, UP TO
905 FT MSL.
TREES, TOWER BEGINNING 1161 FT FROM DER, 4 FT RIGHT OF CENTERLINE,
UP TO 935 FT MSL.
TREES BEGINNING 1174 FT FROM DER, 1 FT LEFT OF CENTERLINE, UP TO
2501211845-2701211845EST
END PART 1 OF 4
!FDC 5/5323 Y50 PART 2 OF 4 ODP WAUTOMA MUNI, WAUTOMA, WI.
916 FT MSL.
TREES BEGINNING 1617 FT FROM DER, 19 FT LEFT OF CENTERLINE, UP TO
919 FT MSL.
TREES BEGINNING 1710 FT FROM DER, 32 FT LEFT OF CENTERLINE, UP TO
920 FT MSL.
TREES BEGINNING 1752 FT FROM DER, 4 FT LEFT OF CENTERLINE, UP TO
926 FT MSL.
TREES BEGINNING 1879 FT FROM DER, 10 FT LEFT OF CENTERLINE, UP TO
927 FT MSL.
TREES BEGINNING 1904 FT FROM DER, 2 FT LEFT OF CENTERLINE, UP TO
933 FT MSL.
TREES BEGINNING 2012 FT FROM DER, 15 FT RIGHT OF CENTERLINE, UP TO
940 FT MSL.
TREE 2882 FT FROM DER, 974 FT LEFT OF CENTERLINE, 935 FT MSL.
TREES BEGINNING 2885 FT FROM DER, 408 FT RIGHT OF CENTERLINE, UP TO
942 FT MSL.
TREE 3597 FT FROM DER, 616 FT LEFT OF CENTERLINE, 948 FT MSL.
RWY 31: TREE 848 FT FROM DER, 631 FT RIGHT OF CENTERLINE, 919 FT
MSL.
TREE 1003 FT FROM DER, 544 FT RIGHT OF CENTERLINE, 925 FT MSL.
2501211845-2701211845EST
END PART 2 OF 4
!FDC 5/5323 Y50 PART 3 OF 4 ODP WAUTOMA MUNI, WAUTOMA, WI.
TREES BEGINNING 1032 FT FROM DER, 183 FT RIGHT OF CENTERLINE, UP TO
932 FT MSL.
TREES BEGINNING 1498 FT FROM DER, 145 FT RIGHT OF CENTERLINE, UP TO
937 FT MSL.
TREE 2016 FT FROM DER, 230 FT LEFT OF CENTERLINE, 921 FT MSL.
TREE 2094 FT FROM DER, 114 FT LEFT OF CENTERLINE, 940 FT MSL.
TREES BEGINNING 2108 FT FROM DER, 5 FT LEFT OF CENTERLINE, UP TO
941 FT MSL.
TREES BEGINNING 2119 FT FROM DER, 57 FT RIGHT OF CENTERLINE, UP TO
939 FT MSL.
TREES BEGINNING 2139 FT FROM DER, 1 FT RIGHT OF CENTERLINE, UP TO
941 FT MSL.
TREES BEGINNING 2324 FT FROM DER, 39 FT LEFT OF CENTERLINE, UP TO
942 FT MSL.
TREES BEGINNING 2324 FT FROM DER, 12 FT RIGHT OF CENTERLINE, UP TO
942 FT MSL.
TREES BEGINNING 2353 FT FROM DER, ON CENTERLINE, UP TO 946 FT MSL.
TREES BEGINNING 2387 FT FROM DER, 110 FT LEFT OF CENTERLINE, UP TO
954 FT MSL.
TREES BEGINNING 2465 FT FROM DER, 8 FT LEFT OF CENTERLINE, UP TO
2501211845-2701211845EST
END PART 3 OF 4
!FDC 5/5323 Y50 PART 4 OF 4 ODP WAUTOMA MUNI, WAUTOMA, WI.
957 FT MSL.
TREES BEGINNING 2585 FT FROM DER, 1 FT LEFT OF CENTERLINE, UP TO
960 FT MSL.
TREES BEGINNING 2635 FT FROM DER, 2 FT RIGHT OF CENTERLINE, UP TO
947 FT MSL.
TREES BEGINNING 2732 FT FROM DER, ON CENTERLINE, UP TO 958 FT MSL.
2501211845-2701211845EST
END PART 4 OF 4
|
