Y31
WEST BRANCH COMMUNITY
PublicPUB

3 miles SE of WEST BRANCH, MI
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
44° 14' 41"N 84° 10' 47"W
882' MSL
1882' MSL
06W
JET A (FSII), 100LL
LANSING (LAN)
LAKE HURON
MINNEAPOLIS (ZMP)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

Y31 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

AWOS-3P

AWOS-3P
989-787-1100
 119.575

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

No TAF is available for this location.
Y31
Domestic
1/13/250151Z !LAN 01/426 Y31 OBST TOWER LGT (ASR 1327853) 441609.30N0840357.80W (5.1NM ENE Y31) 1112FT (265FT AGL) U/S 2501130151-2502270151
12/30/242051Z !LAN 12/932 Y31 OBST TOWER LGT (ASR 1247949) 442007.60N0841340.00W (5.8NM NNW Y31) 1594.8FT (239.8FT AGL) U/S 2412302051-2505022359
12/19/241853Z !LAN 12/579 Y31 RWY 09 PAPI U/S 2412191853-2501202359
No
MON-FRI 0800-1700
SAT-SUN ON CALL
FOR SVC AFT HRS CALL AMGR SUBJ CALL-IN FEE.
CO OGEMAW CITY W BRANCH
121 N 4TH ST
WEST BRANCH, MI 48661-1217
Phone: 989-345-0500
BEN EVERGREEN
PO BOX 183
WEST BRANCH, MI 48661-0183
Phone: 989-345-1453
LANSING FSS (LAN)
Toll Free: 1-800-WX-BRIEF
LAN
--
ACTVT REIL RWYS 09 & 27; PAPI RWYS 09 & 27; MIRL RWY 09/27 - CTAF.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
None

Runway 09/27

5000 ft. x 100 ft.
ASPH
Good
NONE
MED

26,000lbs
--
--
--
  Runway 09 Runway 27
True Heading 89°269°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 44° 14' 41"N 44° 14' 42"N
Longitude 84° 11' 22"W 84° 10' 13"W
Elevation 882' 861'
Threshold Crossing Height 41 ft. AGL 41 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes
A110-2ADMIN BLDG ACCESS, 5-3-2-1-#.
A110-3FOR CD CTC MINNEAPOLIS ARTCC AT 651-463-5588.
A110-4DEER & LRG BIRDS ON & INVOF ARPT.
WEST BRANCH COMMUNITY (IATA: Y31) is a public airport located in WEST BRANCH, MI.
