X01
EVERGLADES AIRPARK
PublicPUB

1 miles SW of EVERGLADES CITY, FL
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
25° 50' 56"N 81° 23' 25"W
5' MSL
1005' MSL
02W
100LL
MIAMI (MIA)
MIAMI
MIAMI (ZMA)
4/17/25-5/15/25
KAPF (28nm) VFR
12:53 PM EST
Clear
10sm
81°F
63°F
30.18"Hg
080° 10kts
AO2 SLP220 T02720172 10283 20183 58018
METAR KAPF 041753Z 08010KT 10SM CLR 27/17 A3018 RMK AO2 SLP220 T02720172 10283 20183 58018
+ Add Your Business

X01 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
123.075 123.075

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

  • No Documents

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

  • No Documents

Terminal Area Forecast

KAPF (28nm)
Tue, 11/4 12:24 PM EST
Tue, 11/4 1:00 PM EST - Wed, 11/5 1:00 PM EST
VFR
9:00 AM EST - 1:00 PM EST
Broken 25,000'
Scattered 4,000'
6sm
070° 10kts
VFR
1:00 AM EST - 9:00 AM EST
Sky Clear
6sm
VRB° 4kts
VFR
7:00 PM EST - 1:00 AM EST
Sky Clear
6sm
060° 8kts
VFR
1:00 PM EST - 7:00 PM EST
Few 5,000'
6sm
060° 13kts
Gusts 20kts
TAF KAPF 041724Z 0418/0518 06013G20KT P6SM FEW050
   FM050000 06008KT P6SM SKC
   FM050600 VRB04KT P6SM SKC
   FM051400 07010KT P6SM SCT040 BKN250
X01
EffectiveExpiresCategoryNOTAM
Domestic
8/5/25
0555Z
11/3/25
0400Z
!MIA 08/060 X01 OBST TOWER LGT (ASR 1210617) 255444.40N0812219.30W (3.9NM NNE X01) 269.0FT (263.1FT AGL) U/S 2508050555-2511030400
7/1/25
1410Z
7/1/26
1500Z
Runway!MIA 07/011 X01 RWY 15 THR DISPLACED 240FT NONPRECISION MARKING. DECLARED DIST: TORA 2349FT TODA 2349FT ASDA 2109FT LDA 2109FT. 2507011410-2607011500
7/1/25
1409Z
7/1/26
1500Z
Runway!MIA 07/010 X01 RWY 33 THR DISPLACED 240FT NONPRECISION MARKING. DECLARED DIST: TORA 2349FT TODA 2349FT ASDA 2109FT LDA 2109FT. 2507011409-2607011500
3/7/23
1720Z
!MIA 03/084 X01 AD AP FIXED BASE OPR CHANGED TO 239-252-6298 2303071720-PERM
No
0800-1600
COLLIER COUNTY AIRPORT AUTHORITY
2005 MAINSAIL DR., SUITE 1
NAPLES, FL 34114-8955
Phone: 239-252-8400
BRYANT GARRETT
650 EC AIRPARK RD
EVERGLADES CITY, FL 34139
Phone: 239-252-8425
MIAMI FSS (MIA)
Toll Free: 1-800-WX-BRIEF
MIA
--
ACTIVATE - MIRL RY 15/33 - CTAF.
N/A
Yes - Lighted
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
None
None
None
None
Charter Service

Runway 15/33

2400 ft. x 50 ft.
ASPH
Excellent
NONE
MED

10,000lbs
12,000lbs
--
--
  Runway 15 Runway 33
True Heading 150°330°
Traffic Pattern Right Left
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 25° 51' 06"N 25° 50' 46"N
Longitude 81° 23' 32"W 81° 23' 18"W
Elevation 4' 4'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1HIGH DENSITY BIRD POPULATION ON & AROUND ARPT.
A110-210 FT TREES 125 -150 FT W OF RWY.
A110-4PAEW INVOF RY 15/33 INDEFLY.
A110-6DITCH 54 FT L OF CNTRLN FIRST 664 FT OF RY 33.
A110-7RWY 15 AND RWY 33 SAFETY AREAS END AT END OF RWY. SAFETY AREAS MAY HOLD WTR AFT HVY RNFL EVENTS.
A110-8BANNER TOW OPNS ON AND INVOF OF ARPT.
A110-9FOR CD CTC MIAMI ARTCC AT 305-716-1731.
EVERGLADES AIRPARK (IATA: X01) is a public airport located in EVERGLADES CITY, FL.
