3/31/25 1636Z | 4/5/27 1636Z | | !FDC 5/9942 W81 PART 1 OF 3 ODP CREWE MUNI, CREWE, VA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 15: TREES BEGINNING 52 FT FROM DER,
474 FT RIGHT OF CENTERLINE, UP TO 405 FT MSL.
TREE 79 FT FROM DER, 340 FT LEFT OF CENTERLINE, 439 FT MSL.
TREES BEGINNING 224 FT FROM DER, 310 FT LEFT OF CENTERLINE, UP TO
441 FT MSL.
TREE 826 FT FROM DER, 689 FT RIGHT OF CENTERLINE, 407 FT MSL.
TREE 1754 FT FROM DER, 680 FT RIGHT OF CENTERLINE, 446 FT MSL.
TREE 2105 FT FROM DER, 893 FT LEFT OF CENTERLINE, 448 FT MSL.
TREE 2217 FT FROM DER, 766 FT RIGHT OF CENTERLINE, 450 FT MSL.
TREE 2262 FT FROM DER, 818 FT LEFT OF CENTERLINE, 451 FT MSL.
TREES BEGINNING 2479 FT FROM DER, 918 FT LEFT OF CENTERLINE, UP TO
479 FT MSL.
TREES BEGINNING 2527 FT FROM DER, 1086 FT RIGHT OF CENTERLINE, UP
TO 497 FT MSL.
TREES BEGINNING 2577 FT FROM DER, 52 FT LEFT OF CENTERLINE, UP TO
498 FT MSL.
TREES BEGINNING 2742 FT FROM DER, 45 FT RIGHT OF CENTERLINE, UP TO
501 FT MSL. RWY 33: TREES BEGINNING 6 FT FROM DER, 196 FT RIGHT OF
CENTERLINE, UP TO 482 FT MSL.
537 FT MSL. 2503311636-2704051636EST
END PART 1 OF 3
!FDC 5/9942 W81 PART 2 OF 3 ODP CREWE MUNI, CREWE, VA.
LIGHT POLE, POLE, TREES, TERRAIN BEGINNING 13 FT FROM DER, 105 FT
LEFT OF CENTERLINE, UP TO 52 FT AGL/488 FT MSL.
TREES, TERRAIN BEGINNING 107 FT FROM DER, 173 FT LEFT OF
CENTERLINE, UP TO 497 FT MSL.
TREES BEGINNING 161 FT FROM DER, 286 FT RIGHT OF CENTERLINE, UP TO
487 FT MSL.
TREES, TERRAIN, BUILDINGS, POLES, TRAVERSE WAYS BEGINNING 174 FT
FROM DER, 74 FT LEFT OF CENTERLINE, UP TO 522 FT MSL.
TREES, BUILDING, POLE BEGINNING 252 FT FROM DER, 166 FT RIGHT OF
CENTERLINE, UP TO 494 FT MSL.
TREES, BUILDING BEGINNING 430 FT FROM DER, 366 FT RIGHT OF
CENTERLINE, UP TO 506 FT MSL.
TREES, POLES, TRAVERSE WAYS, BUILDINGS BEGINNING 513 FT FROM DER,
ON CENTERLINE, UP TO 519 FT MSL.
TREE 1035 FT FROM DER, 317 FT RIGHT OF CENTERLINE, 521 FT MSL.
TREES BEGINNING 1067 FT FROM DER, 137 FT RIGHT OF CENTERLINE, UP TO
525 FT MSL.
TREES BEGINNING 1081 FT FROM DER, 273 FT LEFT OF CENTERLINE, UP TO
524 FT MSL.
TREES, POLE BEGINNING 1157 FT FROM DER, 1 FT LEFT OF CENTERLINE, UP
537 FT MSL. 2503311636-2704051636EST
END PART 2 OF 3
!FDC 5/9942 W81 PART 3 OF 3 ODP CREWE MUNI, CREWE, VA.
TO 525 FT MSL.
TREES, BUILDING, POLE BEGINNING 1211 FT FROM DER, 21 FT RIGHT OF
CENTERLINE, UP TO 529 FT MSL.
TREES BEGINNING 2291 FT FROM DER, 61 FT LEFT OF CENTERLINE, UP TO
531 FT MSL.
TREES BEGINNING 2730 FT FROM DER, 443 FT LEFT OF CENTERLINE, UP TO
537 FT MSL. 2503311636-2704051636EST
END PART 3 OF 3
|
