TJCP
BENJAMIN RIVERA NORIEGA
PublicPUB

1 miles N of ISLA DE CULEBRA, PR
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
18° 18' 47"N 65° 18' 14"W
49' MSL
1049' MSL
11W
None Listed
SAN JUAN (SJU)
PUERTO RICO-VIRGIN ISLANDS
SAN JUAN (ZSU)
10/31/24-11/28/24
TIST (19nm) VFR
7:53 AM AST
Few 12,000'
10sm
82°F
78°F
29.86"Hg
Calm
AO2 SLP112 T02780256 10278 20267 53017 $
TIST 091153Z 10SM FEW120 28/26 A2986 RMK AO2 SLP112 T02780256 10278 20267 53017 $
Add Your Business

TJCP FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 122.9

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

  • No Documents

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

  • No Documents

Terminal Area Forecast

TIST (19nm)
Sat, 11/9 7:36 AM AST
Sat, 11/9 8:00 AM AST - Sun, 11/10 8:00 AM AST
VFR
8:00 AM AST - 9:00 AM AST
Showers in vicinity
Scattered 2,400'
6sm
110° 6kts
VFR
9:00 AM AST - 12:00 PM AST
Light Showers and Rain and Thunderstorm in vicinity
Broken 5,000'
Scattered 3,000'
Scattered 2,000'
6sm
110° 60kts
IFR
Temporary 9:00 AM AST - 12:00 PM AST
Heavy Showers and Rain
Broken 5,000'
Broken 3,000'
Scattered 2,200'
2sm
Calm
VFR
12:00 PM AST - 7:00 PM AST
Thunderstorm in vicinity
Broken 8,000'
Broken 3,500'
Scattered 2,000'
6sm
120° 12kts
VFR
7:00 PM AST - 8:00 AM AST
Light Showers and Rain and Thunderstorm in vicinity
Broken 9,000'
Scattered 3,500'
Scattered 2,000'
6sm
090° 6kts
TIST 091136Z 0912/1012 11006KT P6SM VCSH SCT024
   FM091300 11060KT P6SM -SHRA VCTS SCT020 SCT030CB BKN050
   TEMPO 0913/0916 2SM +SHRA SCT022 BKN030 BKN050
   FM091600 12012KT P6SM VCTS SCT020CB BKN035 BKN080
   FM092300 09006KT P6SM -SHRA VCTS SCT020CB SCT035 BKN090
TJCP
Domestic
10/28/241000Z !TJSJ 10/191 CPX RWY 13/31 SAFETY AREA WIP 2410281000-2411142200
No
SR-SS
PUERTO RICO PORTS AUTHORITY
GPO BOX 362829
SAN JUAN, PR 00936-2829
Phone: (787) 729-8715
JORGE SANTIAGO
PO BOX 1303
CEIBA, PR 00735-1303
Phone: 787-742-0022
SAN JUAN FSS (SJU)
Toll Free: 1-800-WX-BRIEF
TJSJ
Sunset to Sunrise
--
N/A
RTG BCN OTS INDEF.
Yes - Lighted
No
Yes
None
Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
Charter Service

Runway 13/31

2600 ft. x 60 ft.
ASPH
Poor
NONE
MED

12,000lbs
--
--
--
  Runway 13 Runway 31
True Heading 121°301°
Traffic Pattern Left Left
Markings BSC BSC
Markings Condition FAIR FAIR
Latitude 18° 18' 53"N 18° 18' 40"N
Longitude 65° 18' 26"W 65° 18' 02"W
Elevation 43' 8'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1LOW ALT MANEUVERING REQUIRED FOR FINAL ALIGNMENT TO RWY. VARIABLE DEGS OF TURBULENCE MAY BE EXPECTED.
A110-10LDG FEE FOR ALL ACFT.
A110-13600 FT AGL ANT 1/2 MILE EAST OF ARPT.
A110-14RWY 13, 480 FT HILL, 12/ MILE FROM RWY END.
A110-15RAPIDLY RISING TERRAIN NW.
A110-16FOR CD CTC SAN JUAN CERAP AT 787-253-8664/8665
A110-5ACFT DEPARTING ARPT NORTHBOUND BE ALERT FOR TRAFFIC DESCENDING ON FINAL FOR CHARLOTTE AMALIE ST THOMAS, CYRIL E KING (STT).
A110-6BIRDS ON & INVOF RWY
A110-8UNATNDD SS-SR. EMERGS ONLY. OPNS BETWEEN SS-SR WILL BE AN OWN RISK.
BENJAMIN RIVERA NORIEGA (ICAO: TJCP, IATA: CPX) is a public airport located in ISLA DE CULEBRA, PR.
