iFlightPlanner



...
ASHLAND MUNI/SUMNER PARKER FLD - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

S03
Local S03
ASHLAND MUNI/SUMNER PARKER FLD
PublicPUB

2 miles E of ASHLAND, OR, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
42° 11' 25"N 122° 39' 38"W
Elevation
1889' MSL
Pattern Alt
2904' MSL
Mag Variation
14°E
Declination
18°E
Fuel
JET A, 100LL
FSS
MC MINNVILLE (MMV)
Sectional
KLAMATH FALLS
ARTCC
SEATTLE (ZSE)
Data Effective
2/19/26-3/19/26
KMFR (15nm) VFR
7:53 PM PST
Clear
10sm
54°F
42°F
30.05"Hg
320° 7kts
AO2 SLP178 T01220056
METAR KMFR 040353Z 32007KT 10SM CLR 12/06 A3005 RMK AO2 SLP178 T01220056
+ Add Your Business

S03 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.8
ACTVT MIRL RY 12/30, & REIL RY 30 - CTAF. PAPI RYS 12 & 30 OPR 24 HRS.
UNICOM 122.8
AUTOMATED UNICOM.

Approach

CASCADE APPROACH 124.3
0600-2300

Departure

CASCADE DEPARTURE 124.3
0600-2300

Center

CASCADE CENTER 127.55
LOW, APCH/DEP SVC PRVDD BY SEATTLE ARTCC (ZSE) ON FREQS 127.55/254.35 (KING MOUNTAIN RCAG) WHEN CASCADE APCH CLSD.

FAA A/FD Pages

Terminal Area Forecast

KMFR (15nm)
Tue, 3/3 3:38 PM PST
Tue, 3/3 4:00 PM PST - Wed, 3/4 4:00 PM PST
VFR
4:00 PM PST - 3:00 AM PST
Sky Clear
6sm
280° 8kts
MVFR
3:00 AM PST - 1:00 PM PST
Light Showers and Rain
Overcast 3,000'
6sm
VRB° 2kts
VFR
1:00 PM PST - 4:00 PM PST
Light Showers and Rain
Overcast 3,500'
Few 1,500'
6sm
300° 5kts
TAF KMFR 032338Z 0400/0424 28008KT P6SM SKC
   FM041100 VRB02KT 6SM -SHRA OVC030
   FM042100 30005KT P6SM -SHRA FEW015 OVC035
S03
EffectiveExpiresCategoryNOTAM
Domestic
1/8/26
1905Z
3/8/26
1200Z
!MMV 01/055 S03 OBST TOWER LGT (ASR 1034359) 421139.00N1223760.00W (1.2NM E S03) 2419.9FT (60.0FT AGL) U/S 2601081905-2603081200
No
OCT-APR MON-SAT 0800-1700
MAY-SEP MON-SAT 0800-1800
SUN 0900-1700
CITY OF ASHLAND
CITY HALL 2- E. MAIN ST
ASHLAND, OR 97520
Phone: 541-488-5587
ROBERT SKINNER
403 DEAD INDIAN MEMORIAL ROAD
ASHLAND, OR 97520
Phone: 541-482-7675
MC MINNVILLE FSS (MMV)
Toll Free: 1-800-WX-BRIEF
MMV
--
ACTVT MIRL RY 12/30, & REIL RY 30 - CTAF. PAPI RYS 12 & 30 OPR 24 HRS.
N/A
Yes - Lighted
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Major
Major
Low Pressure
None
Charter Service
Pilot Instruction
Aircraft Rental
Annual Surveying

Runway 12/30

3603 ft. x 75 ft.
ASPH
Excellent
NONE
MED

15,000lbs
--
--
--
  Runway 12 Runway 30
True Heading 141°321°
Traffic Pattern Left Left
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 42° 11' 39"N 42° 11' 11"N
Longitude 122° 39' 53"W 122° 39' 23"W
Elevation 1,849' 1,888'
Threshold Crossing Height 37 ft. AGL 22 ft. AGL
Visual Glide Path Angle 3.75° 4°
Visual Slope Indicator P2L P2R
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes
A110-1RY 12 HAS 165 FT TERRAIN 5000 FT AT 29:1.
A110-2DEER & BIRDS ON & INVOF ARPT
A110-324 HR CREDIT CARD FUEL AVBL.
A110-4TAXILANE WIDTH IN VCNTY HANGARS: 36 FEET FROM CENTER.
A110-5FOR CD CTC CASCADE APCH AT 541-607-4674/4675, WHEN APCH CLSD CTC SEATTLE ARTCC AT 253-351-3694.
A57-30RWY 30 +110 FT TREES AT 1420 FT, 150 FT R, 13:1 BASED ON DTHR. 55 FT TREES AT 505 FT, 125 L OF CNTRLN, 9:1 BASED ON DTHR.
A58-12+40 FT TREE 110 FT FM RY END 100 FT R.; 9' BRIARS AT 0-200' FROM RUNWAY END AND 60-125' RIGHT OF CENTER LINE.
A58-309' BRIARS AT 0-200' FROM RUNWAY END AND 80-125' LEFT OF CENTERLINE.
A81-APTACTVT MIRL RY 12/30, & REIL RY 30 - CTAF. PAPI RYS 12 & 30 OPR 24 HRS.
A82AUTOMATED UNICOM.
ASHLAND MUNI/SUMNER PARKER FLD (IATA: S03) is a public airport located in ASHLAND, OR, US.
