| FDC |
|
5/12/251527Z
|
!FDC 5/9217 T11 ODP YAP INTL, YAP ISLAND, .
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
DEPARTURE PROCEDURE RWY 7 NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS.
YAP (YP) NDB OUT OF SERVICE. 2505121527-2512221527EST
|
|
3/25/252032Z
|
!FDC 5/7730 T11 IAP YAP INTL, YAP ISLAND, .
NDB/DME RWY 25, ORIG-C...
S-25 MDA 1120/HAT 1030.
CIRCLING ALL CATS MDA 1120/HAA 1029.
MISSED APPROACH: CLIMBING LEFT TURN TO 1900 ON 057 BEARING FROM YP NDB/DME TO ADABE/11.1 DME AND HOLD.
VPA NA.
NOTE: RWY 25 HELICOPTER VISIBILITY REDUCTION BELOW 3/4 SM NA.
2503252032-2511042032EST
|
|
3/25/252026Z
|
!FDC 5/7723 T11 IAP YAP INTL, YAP ISLAND, .
RNAV (GPS) RWY 7, ORIG-A...
LNAV MDA 620/HAT 529. CIRCLING CATS A/B/C MDA 620/HAA 529.
MISSED APPROACH: CLIMB TO 1800 DIRECT OMOCO AND HOLD.
NOTE: RWY 7 HELICOPTER VISIBILITY REDUCTION BELOW 3/4 SM NA.
VGSI AND DESCENT ANGLES NOT COINCIDENT (VGSI ANGLE 3.00/TCH 47).
MSA FROM RW07 25NM 1900.
2503252026-2511042026EST
|
|
3/25/252023Z
|
!FDC 5/7721 T11 IAP YAP INTL, YAP ISLAND, .
NDB/DME RWY 7, AMDT 2B...
VDP NA.
NOTE: RWY 7 HELICOPTER VISIBILITY REDUCTION BELOW 3/4 SM NA.
2503252023-2511042023EST
|
|
3/25/252020Z
|
!FDC 5/7718 T11 IAP YAP INTL, YAP ISLAND, .
NDB RWY 7, AMDT 2B...
S-7 MDA 900/HAT 809.
CIRCLING ALL CATS MDA 900/HAA 809.
PROCEDURE TURN ENTRY AND COMPLETION TURN ALTITUDE AT YP NDB/DME 1900 FT MSL.
MISSED APPROACH: CLIMB TO 1900 THEN RIGHT TURN ON 180 BEARING FROM YP NDB/DME THEN RIGHT TURN DIRECT YP NDB/DME AND HOLD.
NOTE: RWY 7 HELICOPTER VISIBILITY REDUCTION BELOW 3/4 SM NA.
CHANGE PROFILE VIEW NOTE TO READ: *YP NDB/DME ARRIVALS DESCEND TO 1900 IN YP NDB/DME HOLDING PATTERN (E, RT, 254 INBOUND) PRIOR TO COMMENCING APPROACH.
2503252020-2511042019EST
|
|
3/25/252017Z
|
!FDC 5/7716 T11 IAP YAP INTL, YAP ISLAND, .
NDB RWY 25, ORIG-C...
S-25 MDA 1160/HAT 1070.
CIRCLING ALL CATS MDA 1160/HAA 1069.
PROCEDURE TURN ENTRY AND COMPLETION TURN ALTITUDE AT YP NDB/DME 1900 FT MSL.
MISSED APPROACH: CLIMB TO 1900 THEN LEFT TURN DIRECT YP NDB/DME AND HOLD.
CHANGE PROFILE VIEW NOTE TO READ: *YP NDB/DME ARRIVALS DESCEND TO 1900 IN YP NDB/DME HOLDING PATTERN (SW, RT, 057 INBOUND) PRIOR TO COMMENCING APPROACH.
VDP NA.
RWY 25 HELICOPTER VISIBILITY REDUCTION BELOW 3/4 SM NA.
2503252017-2511042016EST
|
|
3/25/252012Z
|
!FDC 5/7714 T11 IAP YAP INTL, YAP ISLAND, .
RNAV (GPS) RWY 25, ORIG-A...
NOTE: RWY 25 HELICOPTER VISIBILITY REDUCTION BELOW 3/4 SM NA.
MSA FROM RW25 25NM 1900.
2503252012-2511042007EST
|
|
3/10/252122Z
|
!FDC 5/1275 T11 PART 1 OF 3 ODP YAP INTL, YAP ISLAND, .
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
TAKEOFF OBSTACLE NOTES:
RWY 7: TREES BEGINNING 11 FT FROM DER, 384 FT LEFT OF CENTERLINE,
UP TO 119 FT MSL.
TREE, FENCE BEGINNING 32 FT FROM DER, 281 FT LEFT OF CENTERLINE, UP
TO 125 FT MSL.
TREES BEGINNING 99 FT FROM DER, 66 FT RIGHT OF CENTERLINE, UP TO 72
FT AGL/139 FT MSL.
TREES BEGINNING 417 FT FROM DER, 357 FT LEFT OF CENTERLINE, UP TO
133 FT MSL.
TREES BEGINNING 758 FT FROM DER, 453 FT LEFT OF CENTERLINE, UP TO
149 FT MSL.
TREES BEGINNING 780 FT FROM DER, 360 FT RIGHT OF CENTERLINE, UP TO
158 FT MSL.
TREES BEGINNING 1019 FT FROM DER, 130 FT RIGHT OF CENTERLINE, UP TO
164 FT MSL.
TREE, FENCE BEGINNING 1132 FT FROM DER, 25 FT RIGHT OF CENTERLINE,
UP TO 173 FT MSL.
TREES BEGINNING 1160 FT FROM DER, 1 FT LEFT OF CENTERLINE, UP TO
138 FT AGL/231 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2503102122-2603190500EST
END PART 1 OF 3
!FDC 5/1275 T11 PART 2 OF 3 ODP YAP INTL, YAP ISLAND, .
TREE, TERRAIN, BUILDING, POLE BEGINNING 1230 FT FROM DER, ON
CENTERLINE, UP TO 72 FT AGL/196 FT MSL.
RWY 25: POLE 9 FT FROM DER, 53 FT LEFT OF CENTERLINE, 1 FT AGL/92
FT MSL.
TREE, TERRAIN, FENCE BEGINNING 21 FT FROM DER, 297 FT RIGHT OF
CENTERLINE, UP TO 130 FT MSL.
TREES BEGINNING 96 FT FROM DER, 412 FT LEFT OF CENTERLINE, UP TO
119 FT MSL.
TREE, FENCE, VEGETATION BEGINNING 136 FT FROM DER, 11 FT RIGHT OF
CENTERLINE, UP TO 18 FT AGL/144 FT MSL.
TREES BEGINNING 279 FT FROM DER, 36 FT LEFT OF CENTERLINE, UP TO
120 FT MSL.
TREES BEGINNING 408 FT FROM DER, 21 FT LEFT OF CENTERLINE, UP TO
132 FT MSL.
TREE, FENCE, POLE BEGINNING 439 FT FROM DER, ON AND RIGHT OF
CENTERLINE, UP TO 178 FT MSL.
TREES BEGINNING 526 FT FROM DER, 138 FT LEFT OF CENTERLINE, UP TO
135 FT MSL.
TREES BEGINNING 1248 FT FROM DER, 72 FT LEFT OF CENTERLINE, UP TO
140 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2503102122-2603190500EST
END PART 2 OF 3
!FDC 5/1275 T11 PART 3 OF 3 ODP YAP INTL, YAP ISLAND, .
TREES BEGINNING 1350 FT FROM DER, 27 FT LEFT OF CENTERLINE, UP TO
70 FT AGL/146 FT MSL.
TREE 1467 FT FROM DER, 240 FT LEFT OF CENTERLINE, 68 FT AGL/150 FT
MSL.
TREES BEGINNING 1475 FT FROM DER, 14 FT LEFT OF CENTERLINE, UP TO
49 FT AGL/151 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2503102122-2603190500EST
END PART 3 OF 3
|
