KAPALUA - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

PHJH
ICAO PHJHIATA JHMLocal JHM
KAPALUA
PrivatePVT

5 miles NW of LAHAINA, HI, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
20° 57' 47"N 156° 40' 23"W
Elevation
256' MSL
Pattern Alt
1256' MSL
Mag Variation
10°E
Declination
11°E
Fuel
None Listed
FSS
HONOLULU (HNL)
Sectional
HAWAIIAN ISLANDS
ARTCC
HONOLULU CONTROL FACILITY (ZHN)
Data Effective
2/19/26-3/19/26
PHOG (14nm) VFR
6:54 PM HST
Scattered 6,500'
Few 3,000'
10sm
75°F
64°F
30.01"Hg
070° 12kts
Gusts 21kts
AO2 SLP168 T02390178 $
METAR PHOG 040454Z 07012G21KT 10SM FEW030 SCT065 24/18 A3001 RMK AO2 SLP168 T02390178 $
+ Add Your Business

PHJH FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Weather and Advisory

AWOS-3PT 118.525
(808) 665-6101

Common

CTAF 122.7

Center

Center 119.3
LOW/HIGH, PRIMARY FOR LANAI AREA. PRIMARY FOR AREA NE AND E OF HNL VORTAC OUT TO APPROXLY 90NM.

FAA A/FD Pages

Terminal Area Forecast

PHJH
Tue, 3/3 1:26 PM HST
Tue, 3/3 2:00 PM HST - Wed, 3/4 2:00 PM HST
VFR
2:00 PM HST - 8:00 PM HST
Scattered 4,000'
Few 2,500'
6sm
070° 15kts
VFR
8:00 PM HST - 11:00 AM HST
Scattered 6,000'
Few 2,500'
6sm
060° 10kts
VFR
11:00 AM HST - 2:00 PM HST
Scattered 4,000'
Few 2,500'
6sm
080° 16kts
TAF PHJH 032326Z 0400/0424 07015KT P6SM FEW025 SCT040
   FM040600 06010KT P6SM FEW025 SCT060
   FM042100 08016KT P6SM FEW025 SCT040
PHJH
EffectiveExpiresCategoryNOTAM
FDC
3/31/25
1629Z
!FDC 5/9925 JHM SPECIAL KAPALUA, LAHAINA, HI.
SPECIAL TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES, AMDT 4 ...
TAKEOFF MINIMUMS: RWY 2, 400-1 OR STANDARD WITH MINIMUM CLIMB OF 332 FT PER NM TO 600. ALL OTHER DATA REMAINS THE SAME. 2503311629-2704011629EST
No
0600-1800
STATE OF HAWAII AIRPORTS DIVISION
HONOLULU INTL AIRPORT 300 RODGERS BLVD
HONOLULU, HI 96819
Phone: 808-838-8600
MARVIN MONIZ
KAPALUA AIRPORT 4050 HI-30
LAHAINA, HI 96761
Phone: 808-281-6261
HONOLULU FSS (HNL)
Toll Free: 1-800-WX-BRIEF
JHM
--
--
N/A
Yes
Yes
No
None
No
None
None
None
None
None

Runway 02/20

3000 ft. x 100 ft.
ASPH
Good
NONE


--
44,000lbs
--
--
  Runway 02 Runway 20
True Heading 28°208°
Traffic Pattern Right
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 20° 57' 33"N 20° 57' 60"N
Longitude 156° 40' 30"W 156° 40' 15"W
Elevation 241' 256'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1ARPT RESTRICTED TO PART 121 & 135 FAR OPERATORS WITH PPR CTC KAHULUI ARPT OPNS 808-872-3880 (24 HRS).
A110-2NO HELICOPTER OPNS PERMITTED.
A110-3NO JET POWERED ACFT ALLOWED.
A110-4NO PRACTICE & TRAINING FLTS PERMITTED.
A110-5SPECIAL NOISE LEVEL STANDARDS FOR ACFT OPER AT ARPT.
A110-6RESTRICTION ON NUMBER OF DAILY FLTS DEPENDING ON ACFT CAPACITY & SIZE.
A110-7RAPIDLY RISING TERRAIN UP TO 300 FT MSL ALONG THE FULL LENGTH OF RWY 02/20 APPROX 160 FT EAST OF CENTERLINE.
A110-9FOR CD CTC HONOLULU CONTROL FACILITY AT 808-840-6262.
A14ARPT OPNS/MAINT MGR/ADM MR. MARVIN MONIZ - PHONE KAPALUA 808-872-3808/808-665-6108.
A26-CARFF HRS: 0600-1800
A39-02/20PCR VALUE: 35/F/B/X/T
E111VFR,PRIVATE USE ONLY; TFC PTRNS ESTABLISHED TO AVOID CONFLICT WITH KAANOPALI ARPT.
KAPALUA (ICAO: PHJH, IATA: JHM) is a private airport located in LAHAINA, HI, US.
