iFlightPlanner



...
No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

PATL
TATALINA LRRS
PrivatePVT

7 miles S of TAKOTNA, AK
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
62° 53' 42"N 155° 58' 41"W
933' MSL
1933' MSL
12E
None Listed
KENAI (ENA)
MC GRATH
ANCHORAGE (ZAN)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

PATL FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 126.2

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

No TAF is available for this location.
PATL
Domestic
8/22/232138Z !PATL 08/001 TLJ RWY 17 PAPI U/S 2308222138-PERM
No
MON-FRI 0800-1700 CLSD WKEND & HOLS.
U.S. AIR FORCE 611TH AIR SPT GP.
10471 20TH STREET, SUITE 361
ELMENDORF AFB, AK 99506
Phone: 907-552-3442
NICK HILTON
10471 20TH STREET, SUITE 222
ELMENDORF, AK 99506
Phone: 907-552-7610
KENAI FSS (ENA)
Toll Free: 1-866-864-1737
PATL
--
OPR CONSLY.
N/A
Yes
No
No
None
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
Cargo Handling

Runway 17/35

3820 ft. x 150 ft.

GRVL
NONE


--
--
--
--
  Runway 17 Runway 35
True Heading 182°2°
Traffic Pattern Left Left
Markings NSTD NSTD
Markings Condition
Latitude 62° 54' 00"N 62° 53' 23"N
Longitude 155° 58' 39"W 155° 58' 42"W
Elevation 933' 891'
Threshold Crossing Height 52 ft. AGL 40 ft. AGL
Visual Glide Path Angle 5° 3°
Visual Slope Indicator P2R P2L
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes Yes
A110-10PAX MUST COORD BFR NON EMERG TRAVEL TO SITE - D317-552-4935/1089/C907-552-4935/1089.
A110-11WX CAMERA AVBL ON INTERNET AT HTTPS://WEATHERCAMS.FAA.GOV
A110-5PRKG FAC RSTRD TO TWO C123.
A110-6RADIO - 364.2/126.2.
A110-7AFT INITIAL CTC EXP 30 MIN DLA FOR COND RPRT.
A110-8USAF FAC; CIV ACFT LNDG PMT RQRD BFR ARR - D317-552-5282/C907-552-5282 OR MAIL ATTN: 11 AF AMGR 10471 20TH STREET SUITE 218 ELMENDORF AFB AK 99506.
A110-9PPR ALL OPS; MNM 1 HR PRIOR TO DEP FOR SITE & NO EARLIER THAN DAY TRAVEL - D317-552-1106/1040/C907-552-1106/1040.
TATALINA LRRS (ICAO: PATL, IATA: TLJ) is a private airport located in TAKOTNA, AK.
