MC GRATH - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

PAMC
ICAO PAMCIATA MCGLocal MCG
MC GRATH
PublicPUB

0 miles W of MC GRATH, AK, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
62° 57' 10"N 155° 36' 25"W
Elevation
343' MSL
Pattern Alt
1343' MSL
Mag Variation
13°E
Declination
12°E
Fuel
JET A-1+, 100LL
FSS
MCGRATH (MCG)
Sectional
MC GRATH
ARTCC
ANCHORAGE (ZAN)
Data Effective
2/19/26-3/19/26
PAMC VFR
5:53 PM AKST
Clear
10sm
2°F
-13°F
29.75"Hg
030° 9kts
AO2 SLP089 T11671250 56011 TSNO
METAR PAMC 040253Z AUTO 03009KT 10SM CLR M17/M25 A2975 RMK AO2 SLP089 T11671250 56011 TSNO
+ Add Your Business

PAMC FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Weather and Advisory

ASOS 135.65
(907) 524-3850

Common

CTAF 123.6
ACTVT REIL RWY 17 & 35; VASI RWY 17 & 35; MIRL RWY 05/23 & 17/35 - CTAF.

Center

ANCHORAGE CENTER 128.1
LOW, APCH/DEP SVC PRVDD BY ANCHORAGE ARTCC ON FREQS 128.1/353.8 (MC GRATH RCAG).

Flight Service

Flight Service 121.5
(ENA)
Flight Service 122.2
(ENA)
Flight Service 122.65
(ENA)
Flight Service 123.6
(ENA)

FAA A/FD Pages

Airport Minimums

Instrument Approach

Terminal Area Forecast

PAMC
Tue, 3/3 2:20 PM AKST
Tue, 3/3 3:00 PM AKST - Wed, 3/4 3:00 PM AKST
VFR
3:00 PM AKST - 3:00 PM AKST
Sky Clear
6sm
020° 9kts
TAF PAMC 032320Z 0400/0424 02009KT P6SM SKC
PAMC
EffectiveExpiresCategoryNOTAM
Domestic
2/25/26
1900Z
2/26/26
0159Z
!MCG 02/123 MCG NAV LOC RWY 17 LOC/DME U/S 2602251900-2602260159
2/24/26
1944Z
2/25/26
1944Z
Runway!MCG 02/122 MCG RWY 17 FICON 3/3/3 100 PCT COMPACTED SN SANDED 100FT WID OBS AT 2602241944. 2602241944-2602251944
2/24/26
1743Z
2/25/26
1743Z
!MCG 02/121 MCG APRON ALL FICON COMPACTED SN 3IN DRIFTS OBS AT 2602241743. 2602241743-2602251743
2/24/26
1743Z
2/25/26
1743Z
!MCG 02/120 MCG TWY ALL FICON COMPACTED SN 3IN DRIFTS OBS AT 2602241743. 2602241743-2602251743
2/24/26
1743Z
2/25/26
1743Z
Runway!MCG 02/118 MCG RWY 05 FICON 100 PCT COMPACTED SN 3IN DRIFTS OBS AT 2602241743. 2602241743-2602251743
FDC
10/3/25
1023Z
!FDC 5/5657 MCG IAP MC GRATH, MC GRATH, AK.
LOC RWY 17, AMDT 4...
S-17 MDA 800/HAT 457 ALL CATS. CATS C/D VISIBILITY 1 3/8 SM. CIRCLING CAT C MDA 1580/HAT 1237, CAT D MDA 1640/HAT 1297. ALTERNATE MINIMUMS: STANDARD EXCEPT CATS C/D 1300-3. DISREGARD NOTE: MAXIMUM HOLDING AIRSPEED 230 KIAS. TERMINAL ROUTE FROM MCG VORTAC TO NICIB (IAF) NA. HOLD-IN-LIEU OF PROCEDURE TURN AT NICIB (IAF) NA.
2510031023-2605151020EST
10/2/25
0905Z
!FDC 5/1590 MCG IAP MC GRATH, MC GRATH, AK.
RNAV- A, ORIG...
CIRCLING CAT C MDA 1580/HAT 1237, CAT D MDA 1640/HAT 1297. ALTERNATE MINIMUMS: STANDARD EXCEPT CATS C/D 1300-3.
2510020905-2709301236EST
10/2/25
0905Z
!FDC 5/1589 MCG IAP MC GRATH, MC GRATH, AK.
RNAV (GPS) RWY 17, AMDT 2...
LNAV/VNAV CAT A VISIBILITY 1 3/8 SM. CIRCLING CAT C MDA 1580/HAT 1237, CAT D MDA 1640/HAT 1297. ALTERNATE MINIMUMS: STANDARD EXCEPT CATS C/D 1300-3.
2510020905-2709301236EST
No
MAY-SEPT MON-WED 0700-1730
OCT-APR MON-FRI 0800 - 1630
MAY-SEPT THURS 0700-1500
ALASKA DOT&PF CENTRAL REGION
PO BOX 196900
ANCHORAGE, AK 99519
Phone: 907-269-0749
STEFFEN STRICK
PO BOX 21
MCGRATH, AK 99627
Phone: 907-524-3241
MCGRATH FSS (MCG)
Toll Free: LD524-3611
MCG
--
ACTVT REIL RWY 17 & 35; VASI RWY 17 & 35; MIRL RWY 05/23 & 17/35 - CTAF.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Minor
Minor
None
None
Cargo Handling

Runway 05/23

2000 ft. x 60 ft.
GRAVEL
Good
NONE
MED

--
--
--
--
  Runway 05 Runway 23
True Heading 68°248°
Traffic Pattern
Markings
Markings Condition
Latitude 62° 57' 24"N 62° 57' 32"N
Longitude 155° 37' 08"W 155° 36' 28"W
Elevation 342' 342'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 17/35

5936 ft. x 100 ft.
ASPH
Good
GRVD
MED

32,000lbs
80,000lbs
120,000lbs
--
  Runway 17 Runway 35
True Heading 179°359°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 62° 57' 33"N 62° 56' 35"N
Longitude 155° 36' 19"W 155° 36' 17"W
Elevation 342' 342'
Threshold Crossing Height 38 ft. AGL 33 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator V4L V4L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes
A110-11APRON TSNT PRKG MKD BY GREEN CONES.
A110-13WX CAMERA AVBL ON INTERNET AT HTTPS://WEATHERCAMS.FAA.GOV/.
A110-15WX BLN FAC ON ARPT; SEE INSIDE BACK COVER FOR OPS DETAILS.
A110-17MAINT SVC AVBL MAY-SEPT MON-THURS 0700L-1730L; OCT-APR MON-FRI 0800L-1700; AFT HR - AMGR.
A110-18LOCK WHEELED TURNS NA.
A110-19COLD TEMPERATURE AIRPORT. ALTITUDE CORRECTION REQUIRED AT OR BELOW -45C.
A110-2WATER FOWL ON & INVOF ARPT SPRING-FALL; MOOSE INVOF ARPT.
A110-20ARPT SAND LRGR GRADATION THAN FAA RCMDD/SEE AC150/5200-30.
A110-21FUEL SVC FEE AFT 1700 DAILY & ON SUNDAYS.
A110-3FIRE ATTACK OPS DURG SUMMER.
A110-7RWY COND UNMNT; RCMD VISUAL INSP BFR LNDG.
A110-8CLSD TO ACR GTR THAN 30 PAX SEATS.
A110-9PAEW ON RWY.
A58-17TRAIL 7 FT BLW 170 FT BYD RWY.
A58-35ROAD 6 FT BLW 115 FT BYD RWY.
A81-APTACTVT REIL RWY 17 & 35; VASI RWY 17 & 35; MIRL RWY 05/23 & 17/35 - CTAF.
MC GRATH (ICAO: PAMC, IATA: MCG) is a public airport located in MC GRATH, AK, US.
