No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

PAED
ELMENDORF AFB
PrivatePVT

3 miles NE of ANCHORAGE, AK
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
61° 15' 05"N 149° 48' 23"W
213' MSL
1213' MSL
18E
JP-8
KENAI (ENA)
ANCHORAGE
ANCHORAGE (ZAN)
7/11/24-8/8/24
PAED VFR
1:55 AM AKDT
Few 10,000'
10sm
43°F
40°F
29.78"Hg
060° 3kts
AO2A SLP081 T00590042 $
PAED 190955Z 06003KT 10SM FEW100 06/04 A2978 RMK AO2A SLP081 T00590042 $
Add Your Business

PAED FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- --

ATIS

ATIS
Hours: 0700-2300
 124.3

Clearance Delivery

CD/P
 128.8

Ground

GND/P
 121.8

Tower

LCL/P
 127.2

Other

OPS
11AF RESCUE COORD CNTR
 123.1
PTD
 134.8

Terminal Area Forecast

PAED
Wed, 9/18 9:00 PM AKDT
Wed, 9/18 9:00 PM AKDT - Fri, 9/20 3:00 AM AKDT
VFR
9:00 PM AKDT - 6:00 AM AKDT
Broken 15,000'
Broken 6,000'
Scattered 3,000'
6sm
29.70"Hg
VRB° 4kts
Light, In Cloud (Rime): 6,000-12,000'
Light Turbulence: 4,000 - 10,000'
VFR
Becoming 6:00 AM AKDT - 4:00 PM AKDT
Fog in vicinity
Broken 4,000'
Scattered 200'
6sm
29.79"Hg
310° 6kts
Light, In Cloud (Rime): 5,000-9,000'
LIFR
Temporary 7:00 AM AKDT - 11:00 AM AKDT
Fog
Broken 200'
0.5sm
Calm
VFR
Becoming 4:00 PM AKDT - 8:00 PM AKDT
Broken 4,000'
Scattered 2,500'
6sm
29.88"Hg
330° 7kts
Light, In Cloud (Rime): 4,000-6,000'
MVFR
Becoming 8:00 PM AKDT - 3:00 AM AKDT
Broken 2,500'
Scattered 1,500'
Few 1,000'
6sm
29.85"Hg
030° 5kts
TAF PAED 190500Z 1905/2011 VRB04KT 9999 SCT030 BKN060 BKN150 620606 510406 QNH2970INS
   BECMG 1914/1915 31006KT 9999 VCFG SCT002 BKN040 620504 QNH2978INS
   TEMPO 1915/1919 0800 FG BKN002
   BECMG 2000/2001 33007KT 9999 NSW SCT025 BKN040 620402 QNH2989INS
   BECMG 2004/2005 03005KT 9999 FEW010 SCT015 BKN025 QNH2985INS TX12/1923Z TN06/1916Z
PAED
Domestic
2/5/242042Z !PAED 02/001 EDF RWY 16/34 CLSD 2402052042-2506012359
Military
9/18/240106Z RWY 06/24 RSC WET WITH LESS THAN 1/10TH INCH STANDING WATER
9/17/242152Z WEST RAMP SPOTS 3 & 4 EAST TAXILANE HAS REPAIRS LOCATED 59 FEET EAST OF TAXILANE CENTERLINE AND AIRCRAFT TAXIING REQUIRED TO OFFSET CENTERLINE 50 FEET TO THE WEST OF TAXILANE CENTERLINE
9/17/241708Z M0664/24 NOTAMC M0663/24
9/15/241901Z M0662/24 NOTAMC M0661/24
9/13/240013Z WEST RAMP 1 & 2 CLOSED
9/11/240118Z HS19 IS RESTRICTED TO C17 AND SMALLER. USE CAUTION FOR REPAIRS BETWEEN HS19 AND HS20 UNTIL 27SEP
9/11/240117Z HS18 CLOSED
9/10/240659Z RWY 06/24 CAUTION: ASPHALT DEPRESSION LOCATED ON RWY CENTERLINE WITH A DEPTH OF 3/4 AND SPANS 19 FT IN LENGTH LOCATED 487 FT FROM RWY 24 END.
9/9/242354Z RWY 06/24 NO 180 DEGREE TURNS TO BE CONDUCTED BETWEEN TWY D AND RWY INTERSECTION.
9/9/241946Z !PAED V0680/24 EDF AERODROME INSTRUMENT APPROACH PROCEDURE NOT AUTHORIZED PAR RWY 16 NOT AUTHORIZED DUE TO RWY CONSTRUCTION. 2409091946-2511250001
9/9/241942Z !PAED V0678/24 EDF AERODROME INSTRUMENT APPROACH PROCEDURE AMENDMENT TACAN Y RWY 16 AND TACAN Z RWY 16: STRAIGHT-IN NOT AUTHORIZED DUE TO RWY16 CLOSURE, CIRCLING TO LAND RWY 06 OR RWY 24 AUTHORIZED ONLY WITH ATC APPROVAL. REMAIN ON OR ABOVE PAPI GLIDEPATH UNTIL THLD. CIRCLING PROCEDURE N/A AT NIGHT WHEN PAPI TO CIRCLING RWY OTS. 2409091942-2502150001
8/30/240757Z TWY T LOCATION SIGN/TWY R DIRECTIONAL SIGN UNLIT.
8/30/240756Z TWY M LOCATION/TWY D DIRECTIONAL SIGN UNLIT
8/30/240756Z TWY S LOCATION/TWY R DIRECTIONAL SIGN UNLIT.
8/29/240059Z RED RAMP HANGAR 17 SLOT 3, 5, & 6 EAST SIDE RESTRICTED TO TOW OPERATIONS ONLY
8/28/240028Z RED RAMP HANGAR 17 WEST SIDE: OFFSET AIRCRAFT TAXING BY 40 FEET OF TAXILANE CENTERLINE
8/20/240801Z AERODROME BASH PHASE II PROCEDURES IN EFFECT. CONTACT TOWER (127.2/352.05) OR 907-552-BIRD (2473) WITH WILDLIFE SIGHTINGS ON OR NEAR THE AIRFIELD
8/17/240013Z CAUTION: MEN AND EQUIPMENT WILL BE OPERATING SOUTH OF OPS RAMP
8/12/242140Z GOLD RAMP ACFT WITH WINGSPAN GREATER THAN 96 FT MUST REVERSE TAXI OR TOW OUT OF SPOT IF PARKED NOSE FACING SOUTH
8/12/242137Z OPS RAMP INTERIOR TAXILANE WEST OF SPOTS 8, 9, & 10 RESTRICTED TO ACFT WINSPAN LESS THAN 110 FT WHILE ACFT ARE PARKED ON OPS RAMP SPOTS 8, 9, OR 10
7/11/240023Z CAUTION: AIRCRAFT ARE UNABLE TO TAXI ON THE SOUTHERN TAXILANE ON GOLD RAMP WHEN AN AIRCRAFT LARGER THEN A C-130 IS PARKED ON GOLD RAMP. THE SOUTHERN TAXILANE ON GOLD RAMP IS RESTRICTED TO FIGHTER TYPE AIRCRAFT OR SMALLER WHEN THE OTHER FIGHTERS ARE PARKED ON GOLD RAMP.
7/2/241701Z RWY 16/34 CLSD 01 JUN 2023 1400Z/0600L - 01 JUN 2025. RWY 16/34 APPROVED FOR TAXIWAY CROSSINGS AS DIRECTED BY ATC
6/27/241632Z WHEN FIGHTERS ARE HOLDING ON THE ELBOW, THE AREA IS RESTRICTED TO FIGHTERS ONLY.
Yes
ALL
U S GOVT USAF
30SS/DOFJ
ELMENDORF AFB, AK 99506
Phone: 907-552-2107
AIRFIELD MGR
300SS/DOFJ
ELMENDORF AFB, AK 99506
Phone: 907-552-2444
KENAI FSS (ENA)
Toll Free: 1-866-864-1737
PAED
--
--
N/A
Yes
No
No
None
NOT a Landing Rights Airport
NOT an Airport of Entry
14
1
0
0
69
0
None
None
None
None
Cargo Handling

Runway 06/24

10000 ft. x 200 ft.

ASPH
NONE
HIGH
58 /R/B/W/T
--
--
--
--
  Runway 06 Runway 24
True Heading 80°260°
Traffic Pattern Left Right
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 61° 14' 55"N 61° 15' 12"N
Longitude 149° 50' 39"W 149° 47' 18"W
Elevation 174' 201'
Threshold Crossing Height 77 ft. AGL 63 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights ALSF1
Centerline Lights Yes Yes
Runway End Identifier Lights No No

Runway 16/34

7493 ft. x 150 ft.

ASPH
NONE
HIGH
55 /F/A/W/T
--
--
--
--
  Runway 16 Runway 34
True Heading 180°360°
Traffic Pattern Left Right
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 61° 15' 43"N 61° 14' 30"N
Longitude 149° 47' 37"W 149° 47' 37"W
Elevation 212' 185'
Threshold Crossing Height 47 ft. AGL 53 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes No
A110-10CTN: RIDGE EXTDG FM 260-020 DEG 1-2 MI FM TWR PREVENTS FOG OBS OVR KNIK ARM. VIS MAY DROP RAPIDLY AS FOG POURS OVR RIDGE.
A110-100UNA TO MEET R2203 DEP RSTRNS ADVISE ATC PRIOR; CSDR RWY 24 DEP. SEE ATC NOTES IN GIANT RPRT.
A110-13MNTN IDLE PWR ON OUTBOARD ENG DURG TAX.
A110-14HOLD SHORT LINE SIGNS NA ON INTERSECTING RWYS.
A110-2HGR SPACE & WARM STORAGE LMTD OCT-MAY.
A110-23FQT ACT IN R2203; WHEN UNA TO AVOID CTC ATCT.
A110-25SPEC ATC RULES FAR PART 93; SEE REG NOTICES IN SUPPL.
A110-27LMTD WKEND MAINT SVC.
A110-3PREVENTIVE MAINT: TACAN WED & FRI 1600-1700Z; ILS TUE & THU 1500-1700Z; PAR SAT-SUN 1800-2000Z; ASR SAT-SUN 2000-2200.
A110-30JOAP, JOINT OIL ANALYSIS PROGRAM AVBL. LHNIT, LOW & HIGH PRES NITROGEN SVCG AVBL. JOAP & LOW & HIGH PRES NITROGEN SVC DURG DUTY HOURS; AFT HR ON REQ. DE-ICE, TYPE 1 DE-ICE LIFTOFF P-88; TYPE 4 ANTI-ICE CLARIANT SAFEWING MP-LAUNCH.
A110-31CHANGE JET ACFT STARTING UNITS (JASU) TO, (A/M32A-86), MC-1A), (MC-2A), (AM32A-60A). (AM32-95)150 +/-5 LBS/MIN (2055 +/-68CFM) AT 51 +/-02 PSIA. LASS 150 +/-5 LBS/MIN @ 49 +/-2 PSIA.
A110-33OIL: O-123, O-128, O-133, O-148, O-156, JOAP.
A110-35FLUID: PRESAIR & NITROGEN-LHNIT.
A110-5QUIET HR 0630-1400Z WKDAY; 0630-1600Z WKEND & HOL; AMC ACFT EXEMPT.
A110-57IFF SVC AVBL.
A110-59NVD OPS RWY 06/24 MON-FRI 0400-1000Z++.
A110-66CTN: IFR OPS BTW 1500-2000 MSL FM BGQ 092/10 INTO R2203-EDF 320/07 INVOF BIG LAKE, PALMER, BIRCHWOOD, GOOSEBAY & WASILLA AK; MON-SAT 0300-0800Z++ & TUES & THU 1800-2200Z++.
A110-72DV SPOTS 1 & 3 LMTD TO WINGSPANS 136 FT OR LESS.
A110-73CTN: UNLGT TRRN 0 FT AGL/341 FT MSL 1909 FT PRIOR TO THR 1914 FT R OF COURSE.
A110-75TWY N2 & N5 CLSD.
A110-76AIRFIELD MGMT COMSEC STORAGE NA; COMSEC STORAGE - COMMAND POST D317-552-3000.
A110-79CUST & AG INSP RQR TO CTC BASE OPS AT LEAST 90 MIN PRIOR TO ARR.
A110-8DURG VMC DEP/MISSED APCHS/GO AROUNDS; ACFT SHALL MNTN AT OR BLW 1200 FT MLS UNTIL DEP END OF RWY 06.
A110-80PPR NON JBER ASGND ACFT EXC LCL TRNG NON-EXPLOSIVE LADEN AMCC ACFT. NON-FUNDED USTRANSCOM, AMC, 18AF OR MOV PRIORITY 3A1 OR BLW PPR BFR ARR - AMGR.
A110-81SUBMIT PPR FORM IN THE PAED GIANT REPORT STIF TO BASEOPS3@US.AF.MIL NO EARLIER THAN 30 DAYS & NO LATER THAN 48 HR PRIOR TO ARR. PPR ISSUED NO EARLIER THAN 7 DAYS PRIOR TO ARR.
A110-83NORMAL BARRIER CONFIGURATION DURG FTR FLY WINDOW LEAVES 5675 FT BTW CABLES ON RWY 06/24, OUTSIDE OF FTR FLY WINDOWS THERE IS 7658 FT BTW CABLES.
A110-84ACFT REQ CABLES DE-RIGGED CTC BASE OPS 24 HR PRIOR TO ARR OR REQ PRIOR TO PPR ISSUED.
A110-85AMC ASGND MSN ACFT EXP MAINT SVC BY 732 AMS.
A110-86LCL SORTIES OR DEPLOYING TO OR OUT OF ELMENDORF AFB MUST HAVE MAINT PSNL REQ TO CMPLT OPS; INCLG DE-ICE PSNL DURG COLD WX. DEPLOYED ACFT TRANS ALERT SUPPORT NA BYD INITIAL BLOCK IN.
A110-88EXC ELMENDORF MAJCOM EXER, DEPLOYED OR STAGED UNITS CTC 3 WG SKED D317-552-2406 OR C907-552-2406 ASAP FOR LCL AREA BRIEFING, MAINT SPONSORSHIP & VISITING UNIT SMTN REQ FORM FOR 3 OG/CC APVL PRIOR TO LCL OPS.
A110-89TRAN ALERT SVC LMTD TO POL SVC, INTAKE, MAGNETIC CHIP DETECTOR & EOR INSP.
A110-9FTR ARR EXP RDCD SEPN; SAME TYPE ACFT & DALGT 3000 FT; DISSIMILAR ACFT &/OR NGT 6000 FT; AHD/BHND FRMN LDG 6000 FT.
A110-91NON-AMC RQRG 732 AMS MAINT SVC EXP PSBL DELAY.
A110-92RCR/RSC & FLD RCR - ATCT. RWY COND CODE & FICON NOT RPTD.
A110-94H24 WX - D317-552-4903/4397/C907-552-4903/4397.
A110-99WINGSPANS OF 145 FT OR GREATER MAY EXPERIENCE RDCD WINGTIP CLNC DOWN TO 25 FT WHEN FIGHTERS ARE IN N MOST ELBOW EOR SPOT. TWY N FM RWY 16-34 TO TWY R RSTRD TO FIGHTER ONLY WHEN ACFT ARE STAGED IN ELBOW EOR SPOT.
ELMENDORF AFB (ICAO: PAED, IATA: EDF) is a private airport located in ANCHORAGE, AK.
