iFlightPlanner



...
No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

PADQ
KODIAK
PublicPUB

4 miles SW of KODIAK, AK
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
57° 44' 59"N 152° 29' 38"W
79' MSL
1079' MSL
14E
JET A-1, 100LL
KENAI (ENA)
KODIAK
ANCHORAGE (ZAN)
7/11/24-8/8/24
PADQ VFR
2:53 AM AKDT
Clear
10sm
51°F
39°F
29.91"Hg
300° 13kts
Gusts 21kts
AO2 PK WND 30028/0958 SLP128 T01060039 TSNO
PADQ 191053Z AUTO 30013G21KT 10SM CLR 11/04 A2991 RMK AO2 PK WND 30028/0958 SLP128 T01060039 TSNO
Add Your Business

PADQ FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 119.8

ATIS

ATIS
 134.45

Emergency

EMERG
 121.5

Ground

GND/P
 121.9

Tower

LCL/P
 119.8

FAA A/FD Pages

Airport Diagrams

Airport Minimums

Departure Procedures

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

PADQ
Wed, 9/18 9:20 PM AKDT
Wed, 9/18 10:00 PM AKDT - Thu, 9/19 10:00 PM AKDT
VFR
10:00 PM AKDT - 6:00 PM AKDT
Scattered 4,500'
6sm
280° 7kts
VFR
Temporary 10:00 PM AKDT - 2:00 AM AKDT
No Clouds
N/A
280° 8kts
Gusts 20kts
VFR
6:00 PM AKDT - 10:00 PM AKDT
Scattered 20,000'
Few 4,000'
6sm
030° 6kts
PADQ 190520Z 1906/2006 28007KT P6SM SCT045
   TEMPO 1906/1910 28008G20KT
   FM200200 03006KT P6SM FEW040 SCT200
PADQ
Domestic
9/18/240218Z !ADQ 09/108 ADQ RWY 26 RWY END ID LGT U/S 2409180218-2411301500EST
9/16/241525Z !ADQ 09/095 ADQ COM REMOTE TRANS/REC 121.5 U/S 2409161525-2409281500EST
9/1/240600Z !ADQ 09/001 ADQ COM REMOTE COM OUTLET 119.8 U/S DLY 0600-1500 2409010600-2409301500EST
8/19/241742Z !ADQ 08/060 ADQ COM REMOTE TRANS/REC 121.9 U/S 2408191742-2409291500EST
8/3/231649Z !ADQ 08/006 ADQ APRON ALPHA RAMP SW EDGE IRREGULAR SFC 2308031649-2409300001
Yes
SAME AS ARPT MAINT HRS
FOR INFORMATION ON ARPT CALL 907-487-4952 MON-FRI 0700-1630.
ALASKA DOT&PF SOUTHCOAST REGION
P O BOX 112500
JUNEAU, AK 99811-2500
Phone: 907-465-4512
CLARK YATSIK
1500 ANTON LARSON RD
KODIAK, AK 99615
Phone: 907-487-4952
KENAI FSS (ENA)
Toll Free: 1-866-864-1737
ADQ
--
ACTVT REIL RWY 01 & 26; VASI RWY 01, 26, 29; HIRL RWY 01/19, 08/26, 11/29; TWY LGTS - CTAF.
N/A
Yes - Lighted
Yes
No
None
NOT a Landing Rights Airport
NOT an Airport of Entry
34
5
0
2
15
0
Minor
Minor
None
None
Air Freight
Cargo Handling
Charter Service

Runway 01/19

5010 ft. x 150 ft.
ASPH
Good
GRVD
HIGH
48 /F/B/X/U
53,000lbs
110,000lbs
150,000lbs
--
  Runway 01 Runway 19
True Heading 22°202°
Traffic Pattern Right Left
Markings PIR BSC
Markings Condition GOOD GOOD
Latitude 57° 44' 23"N 57° 45' 08"N
Longitude 152° 29' 35"W 152° 28' 60"W
Elevation 36' 22'
Threshold Crossing Height 57 ft. AGL --
Visual Glide Path Angle 3.75° --
Visual Slope Indicator V2L --
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes

Runway 08/26

7534 ft. x 150 ft.
ASPH
Good
GRVD
HIGH
70 /F/B/Y/T
53,000lbs
110,000lbs
150,000lbs
--
  Runway 08 Runway 26
True Heading 92°272°
Traffic Pattern Left Right
Markings BSC PIR
Markings Condition GOOD GOOD
Latitude 57° 45' 08"N 57° 45' 05"N
Longitude 152° 31' 08"W 152° 28' 50"W
Elevation 79' 21'
Threshold Crossing Height -- 54 ft. AGL
Visual Glide Path Angle -- 2.05°
Visual Slope Indicator -- V2L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes

Runway 11/29

5400 ft. x 150 ft.
ASPH
Good
GRVD
HIGH
44 /F/B/Y/T
53,000lbs
110,000lbs
150,000lbs
--
  Runway 11 Runway 29
True Heading 127°307°
Traffic Pattern Left Right
Markings NPI NPI
Markings Condition FAIR FAIR
Latitude 57° 45' 18"N 57° 44' 46"N
Longitude 152° 30' 08"W 152° 28' 49"W
Elevation 37' 26'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- V2L
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1JASU-5(A/M32A-86); 1(MA-1A). AVAILABLE USCG ONLY.
A110-10ALL TRANSIENT MILITARY ACFT CONTACT MAINTENANCE ON 164.550 OR KODIAK AIR ON 345.0 FOR MARSHALLER.
A110-11HIGH TERRAIN AROUND ARPT IS NOT OBST LGTD.
A110-12MOUNTAIN ON APCH TO RWY 08. RECOMMEND USE OF RWY 08 ONLY BY PILOTS FAMILIAR WITH TERRAIN.
A110-13PERSONNEL AND EQUIPMENT MAY BE WORKING ON THE RY AT ANY TIME.
A110-1572 HOUR ADVANCE PPR REQUIRED FOR ACCESS TO CG RAMP. TRANSIENT CREW MUST PROVIDE TECHNICAL/DIREC/ASSISTANCE IN SVC/MAINT. EXPECT DELAYS OTHER TIMES EXCEPT SAR AND MEDEVAC V487-5889 C907-487-5889.
A110-16ALL ARR ACFT CTC KODIAK AIR ON 345.0 OR 164.55 FOR CLEARANCE ONTO CG RAMP, MARSHALLER AND PARKING SVCS. BE ALERT: TXY TO CG RAMP CROSSES TWO ROADWAYS, ACTIVATE CROSSING LIGHTS KEY 122.8 5 TIMES-ON 7 TIMES-OFF. BE ALERT: NON-STANDARD TAXI LINE OBST CLEARANCE ON CG RAMP.
A110-17CG RAMP UNSUITABLE FOR AIRCRAFT LARGER THEN A C130 WINGSPAN (132.5 FT).
A110-18WX CAMERA AVBL ON INTERNET AT HTTPS://WEATHERCAMS.FAA.GOV.
A110-19ARPT SAND LARGER GRADATION THAN FAA RECOMMENDED/SEE AC150/5200-30.
A110-2FIRST 3000 FT RWY 08 & FIRST 2000 FT RWY 01, & ASSOCIATED TXYS NOT VISIBLE FROM TWR.
A110-20ACFT OPS DURING ATCT CLOSURE: ALL PILOTS MUST BE ALERT WHEN LANDING RWY 26 OR DEPARTING RWY 08 DUE TO POSSIBLE TALL VESSELS CROSSING THE RWY 26 APCH CORRIDOR 3200 TO 5000 FT FROM APCH END OF RWY 26. SHIPS OVER 120 FT ABOVE WATER CROSS CHANNEL BTWN PUFFIN ISLAND/ADQ. CAN OCCUR ANYTIME.
A110-22NWS WEATHER BALLOON LAUNCH FACILITY LOCATED ON AIRPORT, SEE INSIDE BACK COVER FOR OPERATION DETAILS.
A110-23ALL LIFEFLIGHT/MEDEVAC AIRCRAFT MUST USE RAMP AREA IN OR ADJACENT TO TRANSIENT PARKING ON EAST SIDE OF COMMERCIAL RAMP, OUTSIDE OF SIDA MARKINGS.
A110-24HEAVY LIFT CARGO ACFT RESTRICTED FROM FULL POWER TAKEOFF ON RWY 8 UNLESS PRIOR AUTHORIZATION FROM ARPT MGMT.
A110-25LOCKED WHEEL TURNS PROHIBITED ON ALL SURFACES.
A110-26ACFT WEIGHING MORE THAN 200000 GROSS TAKEOFF AND LANDING, PPR FOR ALL OPERATIONS.
A110-27TSA REGULATED AIRPORT. SEE 49 CFR 1542. ALL GATES AND DOORS MUST BE SECURED AT ALL TIMES. TRANSIENT OR UNFAMILIAR PILOTS CONTACT AIRPORT MGR WITH QUESTIONS.
A110-3DEER NUMEROUS SEABIRDS AND MIGRATORY WATERFOWL ON AND INVOF OF ARPT.
A110-4NO SNOW REMOVAL OR DEICING FOR RWY, TXY, AND RAMP, DAILY 1830-0500 LOCAL.
A110-7ARPT SVC ROAD WITHIN 50 FT OF THLD ON ALL RWYS.
A110-8TAKEOFF RWY 26 OR RWY 29 OR LNDG RWY 8 OR RWY 11 NOT RECOMMENDED DRG HRS OF DARKNESS OR WHEN MTN PEAKS ARE OBSCD.
A110-9PORTIONS OF ALL TXYS NOT VISIBLE FROM TOWER DUE TO TERRAIN.
KODIAK (ICAO: PADQ, IATA: ADQ) is a public airport located in KODIAK, AK.
