3/14/251253Z
|
!FDC 5/3222 N03 PART 1 OF 7 ODP CORTLAND COUNTY/CHASE FLD,
CORTLAND, NY.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 3...
TAKEOFF OBSTACLE NOTES: NOTE: RWY 6: POLE, LIGHT POLES BEGINNING 20
FT FROM DER, 77 FT LEFT OF CENTERLINE, UP TO 1191 FT MSL.
LIGHT POLES 38 FT FROM DER, 77 FT RIGHT OF CENTERLINE, 5 FT
AGL/1167 FT MSL.
BUILDING BEGINNING 43 FT FROM DER, 277 FT RIGHT OF CENTERLINE, UP
TO 27 FT AGL/1176 FT MSL.
TREE, VEHICLE ON ROAD BEGINNING 92 FT FROM DER, 117 FT LEFT OF
CENTERLINE, UP TO 73 FT AGL/1235 FT MSL.
TREE, BUILDING BEGINNING 176 FT FROM DER, 355 FT RIGHT OF
CENTERLINE, UP TO 1182 FT MSL.
POLE 530 FT FROM DER, 461 FT RIGHT OF CENTERLINE, 1188 FT MSL.
TREES BEGINNING 788 FT FROM DER, 99 FT LEFT OF CENTERLINE, UP TO
1238 FT MSL.
POLE BEGINNING 946 FT FROM DER, 468 FT RIGHT OF CENTERLINE, UP TO
1192 FT MSL.
POLE, TRANSMISSION LINE BEGINNING 1071 FT FROM DER, 691 FT RIGHT OF
CENTERLINE, UP TO 43 FT AGL/1195 FT MSL.
POLE 1304 FT FROM DER, 144 FT RIGHT OF CENTERLINE, 32 FT AGL/1197
FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2503141253-2703141253EST
END PART 1 OF 7
!FDC 5/3222 N03 PART 2 OF 7 ODP CORTLAND COUNTY/CHASE FLD,
CORTLAND, NY.
POLE 1359 FT FROM DER, 285 FT RIGHT OF CENTERLINE, 41 FT AGL/1200
FT MSL.
TREES BEGINNING 1371 FT FROM DER, 24 FT RIGHT OF CENTERLINE, UP TO
39 FT AGL/1204 FT MSL.
TREE 1510 FT FROM DER, 130 FT RIGHT OF CENTERLINE, 43 FT AGL/1206
FT MSL.
TREE, POLE BEGINNING 1542 FT FROM DER, 227 FT RIGHT OF CENTERLINE,
UP TO 51 FT AGL/1209 FT MSL.
TREES BEGINNING 1567 FT FROM DER, 215 FT LEFT OF CENTERLINE, UP TO
1258 FT MSL.
TREES BEGINNING 1627 FT FROM DER, 49 FT LEFT OF CENTERLINE, UP TO
1259 FT MSL.
TREES BEGINNING 1666 FT FROM DER, 33 FT RIGHT OF CENTERLINE, UP TO
56 FT AGL/1212 FT MSL.
TREES BEGINNING 1768 FT FROM DER, 131 FT LEFT OF CENTERLINE, UP TO
1261 FT MSL.
TREES BEGINNING 2064 FT FROM DER, 86 FT RIGHT OF CENTERLINE, UP TO
75 FT AGL/1232 FT MSL.
TREES BEGINNING 2088 FT FROM DER, 54 FT LEFT OF CENTERLINE, UP TO
1267 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2503141253-2703141253EST
END PART 2 OF 7
!FDC 5/3222 N03 PART 3 OF 7 ODP CORTLAND COUNTY/CHASE FLD,
CORTLAND, NY.
TREES BEGINNING 2140 FT FROM DER, 133 FT LEFT OF CENTERLINE, UP TO
1285 FT MSL.
TREES BEGINNING 2181 FT FROM DER, 57 FT LEFT OF CENTERLINE, UP TO
1289 FT MSL.
TREE 2241 FT FROM DER, 89 FT RIGHT OF CENTERLINE, 86 FT AGL/1249 FT
MSL.
TREES BEGINNING 3166 FT FROM DER, 719 FT LEFT OF CENTERLINE, UP TO
1303 FT MSL.
TREES BEGINNING 3298 FT FROM DER, 820 FT LEFT OF CENTERLINE, UP TO
1304 FT MSL.
TREES BEGINNING 3526 FT FROM DER, 1175 FT LEFT OF CENTERLINE, UP TO
1307 FT MSL.
TREES BEGINNING 3608 FT FROM DER, 1327 FT LEFT OF CENTERLINE, UP TO
1308 FT MSL.
TREES BEGINNING 3726 FT FROM DER, 1095 FT LEFT OF CENTERLINE, UP TO
1314 FT MSL.
TREE 1.8 NM FROM DER, 1126 FT RIGHT OF CENTERLINE, 1500 FT MSL.
TREES BEGINNING 2 NM FROM DER, 544 FT RIGHT OF CENTERLINE, UP TO 91
FT AGL/1535 FT MSL.
TOWER 2.1 NM FROM DER, 592 FT RIGHT OF CENTERLINE, 192 FT AGL/1624
ALL OTHER DATA REMAINS AS PUBLISHED. 2503141253-2703141253EST
END PART 3 OF 7
!FDC 5/3222 N03 PART 4 OF 7 ODP CORTLAND COUNTY/CHASE FLD,
CORTLAND, NY.
FT MSL.
NOTE: RWY 24: TERRAIN BEGINNING 23 FT FROM DER, 388 FT RIGHT OF
CENTERLINE, UP TO 1198 FT MSL.
FENCE 191 FT FROM DER, 460 FT RIGHT OF CENTERLINE, 7 FT AGL/1206 FT
MSL.
TREE, FENCE BEGINNING 260 FT FROM DER, 381 FT RIGHT OF CENTERLINE,
UP TO 1256 FT MSL.
TREE, BUILDING, POLE BEGINNING 358 FT FROM DER, 306 FT RIGHT OF
CENTERLINE, UP TO 1277 FT MSL.
TREE 865 FT FROM DER, 508 FT LEFT OF CENTERLINE, 1229 FT MSL.
TREES BEGINNING 920 FT FROM DER, 397 FT LEFT OF CENTERLINE, UP TO
1236 FT MSL.
TREES BEGINNING 1074 FT FROM DER, 411 FT LEFT OF CENTERLINE, UP TO
1237 FT MSL.
TREE 1225 FT FROM DER, 817 FT LEFT OF CENTERLINE, 1242 FT MSL.
TREE, POLE BEGINNING 1226 FT FROM DER, 86 FT LEFT OF CENTERLINE, UP
TO 1248 FT MSL.
TREE 1453 FT FROM DER, 788 FT RIGHT OF CENTERLINE, 1279 FT MSL.
TREES BEGINNING 1471 FT FROM DER, 47 FT RIGHT OF CENTERLINE, UP TO
1281 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2503141253-2703141253EST
END PART 4 OF 7
!FDC 5/3222 N03 PART 5 OF 7 ODP CORTLAND COUNTY/CHASE FLD,
CORTLAND, NY.
TREES BEGINNING 1559 FT FROM DER, 1 FT RIGHT OF CENTERLINE, UP TO
1284 FT MSL.
TREE, POLE BEGINNING 1593 FT FROM DER, 303 FT LEFT OF CENTERLINE,
UP TO 1250 FT MSL.
TREES BEGINNING 1653 FT FROM DER, 54 FT LEFT OF CENTERLINE, UP TO
1290 FT MSL.
TREES BEGINNING 2025 FT FROM DER, 4 FT LEFT OF CENTERLINE, UP TO
1293 FT MSL.
TREES BEGINNING 2909 FT FROM DER, 108 FT RIGHT OF CENTERLINE, UP TO
1289 FT MSL.
TREE 3033 FT FROM DER, 777 FT RIGHT OF CENTERLINE, 1292 FT MSL.
TREES BEGINNING 3104 FT FROM DER, 702 FT RIGHT OF CENTERLINE, UP TO
1300 FT MSL.
TREES BEGINNING 3167 FT FROM DER, 266 FT RIGHT OF CENTERLINE, UP TO
1301 FT MSL.
TREES BEGINNING 3244 FT FROM DER, 311 FT RIGHT OF CENTERLINE, UP TO
1304 FT MSL.
TREES BEGINNING 3517 FT FROM DER, 194 FT RIGHT OF CENTERLINE, UP TO
1305 FT MSL.
TREE 3649 FT FROM DER, 1339 FT RIGHT OF CENTERLINE, 1311 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2503141253-2703141253EST
END PART 5 OF 7
!FDC 5/3222 N03 PART 6 OF 7 ODP CORTLAND COUNTY/CHASE FLD,
CORTLAND, NY.
TREE 3653 FT FROM DER, 558 FT RIGHT OF CENTERLINE, 1312 FT MSL.
TREE 3669 FT FROM DER, 667 FT RIGHT OF CENTERLINE, 1321 FT MSL.
TREES BEGINNING 3673 FT FROM DER, 287 FT RIGHT OF CENTERLINE, UP TO
1344 FT MSL.
TREE, BUILDING BEGINNING 3763 FT FROM DER, 119 FT RIGHT OF
CENTERLINE, UP TO 1359 FT MSL.
TREE, BUILDING BEGINNING 3929 FT FROM DER, 116 FT RIGHT OF
CENTERLINE, UP TO 82 FT AGL/1361 FT MSL.
TREES BEGINNING 4061 FT FROM DER, 227 FT RIGHT OF CENTERLINE, UP TO
95 FT AGL/1371 FT MSL.
TREE, BUILDING, TERRAIN, FENCE BEGINNING 4087 FT FROM DER, 115 FT
RIGHT OF CENTERLINE, UP TO 1378 FT MSL.
TREES BEGINNING 4270 FT FROM DER, 203 FT RIGHT OF CENTERLINE, UP TO
1383 FT MSL.
TREES BEGINNING 4325 FT FROM DER, 631 FT RIGHT OF CENTERLINE, UP TO
1389 FT MSL.
TREES BEGINNING 4340 FT FROM DER, 315 FT RIGHT OF CENTERLINE, UP TO
1397 FT MSL.
TREE 4375 FT FROM DER, 4 FT LEFT OF CENTERLINE, 75 FT AGL/1310 FT
MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2503141253-2703141253EST
END PART 6 OF 7
!FDC 5/3222 N03 PART 7 OF 7 ODP CORTLAND COUNTY/CHASE FLD,
CORTLAND, NY.
TREES BEGINNING 4393 FT FROM DER, 76 FT RIGHT OF CENTERLINE, UP TO
1404 FT MSL.
TREE 5181 FT FROM DER, 273 FT LEFT OF CENTERLINE, 107 FT AGL/1343
FT MSL.
TREES BEGINNING 5684 FT FROM DER, 1782 FT RIGHT OF CENTERLINE, UP
TO 1405 FT MSL.
TREES BEGINNING 5878 FT FROM DER, 1991 FT RIGHT OF CENTERLINE, UP
TO 1426 FT MSL.
TREE, TERRAIN, FENCE BEGINNING 6033 FT FROM DER, 1738 FT RIGHT OF
CENTERLINE, UP TO 1434 FT MSL.
TREE, TERRAIN BEGINNING 1 NM FROM DER, 1681 FT RIGHT OF CENTERLINE,
UP TO 1518 FT MSL.
TREE, TERRAIN, FENCE, BUILDING, VEHICLE ON ROAD BEGINNING 1.1 NM
FROM DER, 1504 FT RIGHT OF CENTERLINE, UP TO 1528 FT MSL.
TREE, VEHICLE ON ROAD BEGINNING 1.3 NM FROM DER, 1474 FT RIGHT OF
CENTERLINE, UP TO 1545 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2503141253-2703141253EST
END PART 7 OF 7
|
