ALLENTOWN QUEEN CITY MUNI - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KXLL
ICAO KXLLLocal XLL
ALLENTOWN QUEEN CITY MUNI
PublicPUB

2 miles SW of ALLENTOWN, PA, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
40° 34' 13"N 75° 29' 18"W
Elevation
399' MSL
Pattern Alt
1399' MSL
Mag Variation
12°W
Declination
12°W
Fuel
JET A, 100LL
FSS
WILLIAMSPORT (IPT)
Sectional
NEW YORK
ARTCC
NEW YORK (ZNY)
Data Effective
2/19/26-3/19/26
KXLL MVFR
3:35 AM EST
Mist
Overcast 3,000'
Scattered 1,400'
Scattered 500'
3sm
36°F
36°F
30.22"Hg
Calm
AO2 TSNO
METAR KXLL 040835Z AUTO 00000KT 3SM BR SCT005 SCT014 OVC030 02/02 A3022 RMK AO2 TSNO
+ Add Your Business

KXLL FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Weather and Advisory

AWOS-3 127.875
(610) 231-3111, UNAVBL BYD 8 NM.

Common

CTAF 122.7
ACTVT REIL RWY 07/25; MIRL RWY 07/25 & 15/33 - CTAF.
UNICOM 122.7

Clearance

Clearance Delivery 118.9

Approach

ALLENTOWN APPROACH 119.65
Initial Contact - 3000 FT & BLW
ALLENTOWN APPROACH 124.45
Initial Contact - ABV 3000 FT

Departure

ALLENTOWN DEPARTURE 119.65
Initial Contact - 3000 FT & BLW
ALLENTOWN DEPARTURE 124.45
Initial Contact - ABV 3000 FT

FAA A/FD Pages

Airport Minimums

Instrument Approach

Terminal Area Forecast

KABE (6nm)
Wed, 3/4 3:46 AM EST
Wed, 3/4 4:00 AM EST - Thu, 3/5 1:00 AM EST
VFR
4:00 AM EST - 5:00 AM EST
Mist
Overcast 3,500'
Few 1,500'
6sm
230° 4kts
LIFR
5:00 AM EST - 10:00 AM EST
Mist
Overcast 300'
3sm
VRB° 2kts
MVFR
10:00 AM EST - 2:00 PM EST
Mist
Overcast 1,500'
6sm
VRB° 3kts
MVFR
2:00 PM EST - 6:00 PM EST
Broken 2,500'
6sm
Calm
VFR
6:00 PM EST - 9:00 PM EST
Broken 3,500'
6sm
Calm
MVFR
9:00 PM EST - 11:00 PM EST
Mist
Overcast 1,500'
5sm
VRB° 3kts
IFR
11:00 PM EST - 1:00 AM EST
Mist
Overcast 800'
5sm
Calm
TAF KABE 040846Z 0409/0506 23004KT 6SM BR FEW015 OVC035
   FM041000 VRB02KT 3SM BR OVC003
   FM041500 VRB03KT 6SM BR OVC015
   FM041900 00000KT P6SM BKN025
   FM042300 00000KT P6SM BKN035
   FM050200 VRB03KT 5SM BR OVC015
   FM050400 00000KT 5SM BR OVC008
KXLL
EffectiveExpiresCategoryNOTAM
Domestic
3/3/26
1214Z
3/4/26
1214Z
!IPT 03/031 XLL TWY A, C FICON WET DEICED SOLID 35FT WID OBS AT 2603031214. 2603031214-2603041214
3/3/26
1213Z
3/4/26
1213Z
Runway!IPT 03/030 XLL RWY 25 FICON 5/5/5 100 PCT WET DEICED SOLID 75FT WID OBS AT 2603031212. 2603031213-2603041213
2/25/26
0950Z
3/15/26
2000Z
!IPT 02/331 XLL TWY B HLDG PSN SIGN FOR RWY 07/25 LGT U/S 2602250950-2603152000
2/25/26
0945Z
3/15/26
2000Z
!IPT 02/329 XLL TWY A3 HLDG PSN SIGN FOR RWY 07/25 LGT U/S 2602250945-2603152000
2/25/26
0945Z
3/15/26
2000Z
Runway!IPT 02/328 XLL RWY 25 RWY END ID LGT U/S 2602250945-2603152000
2/18/26
0952Z
3/4/26
2000Z
!IPT 02/178 XLL TWY A1 HLDG PSN SIGN FOR RWY 07/25 LGT U/S 2602180952-2603042000
No
0700-1900
LEHIGH NORTHAM ARPT AUTH
3311 AIRPORT RD
ALLENTOWN, PA 18109
Phone: 610-266-6001
THOMAS R STOUDT
1730 VULTEE ST
ALLENTOWN, PA 18109
Phone: 610-791-5193
WILLIAMSPORT FSS (IPT)
Toll Free: 1-800-WX-BRIEF
IPT
--
ACTVT REIL RWY 07/25; MIRL RWY 07/25 & 15/33 - CTAF.
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Major
Major
None
None
Air Freight
Pilot Instruction
Aircraft Rental

Runway 07/25

3950 ft. x 75 ft.
ASPH
Good
GRVD
MED

12,000lbs
--
--
--
  Runway 07 Runway 25
True Heading 58°238°
Traffic Pattern Left Left
Markings NPI BSC
Markings Condition GOOD GOOD
Latitude 40° 33' 60"N 40° 34' 20"N
Longitude 75° 29' 39"W 75° 28' 56"W
Elevation 386' 388'
Threshold Crossing Height 41 ft. AGL 40 ft. AGL
Visual Glide Path Angle 3° 3.5°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes

Runway 15/33

3160 ft. x 75 ft.
ASPH
Excellent
NONE
MED

12,000lbs
--
--
--
  Runway 15 Runway 33
True Heading 135°315°
Traffic Pattern Left Left
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 40° 34' 28"N 40° 34' 06"N
Longitude 75° 29' 33"W 75° 29' 04"W
Elevation 386' 399'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1DEER, GROUNDHOGS & BIRDS ON & INVOF ARPT.
A110-2NOISE ABATEMENT PROC IN EFCT, FOR DETAILS CTC AMGR.
A110-3FOR SVC AFT HRS CTC 610-266-6000.
A110-4FOR CD CTC ALLENTOWN APCH AT 800-728-6322.
A43-25UNUSBL BYD 3 DEG L OF CRS.
A58-074FT SHRUB, 154 FT FM RWY END, 177 FT R.
A81-APTACTVT REIL RWY 07/25; MIRL RWY 07/25 & 15/33 - CTAF.
E111EXISTED PRIOR TO 1959.
ALLENTOWN QUEEN CITY MUNI (ICAO: KXLL, IATA: XLL) is a public airport located in ALLENTOWN, PA, US.
