iFlightPlanner



...
No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KVEL
VERNAL RGNL
PublicPUB

1 miles SE of VERNAL, UT
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
40° 26' 10"N 109° 30' 41"W
5274' MSL
6274' MSL
10E
JET A, 100LL
CEDAR CITY (CDC)
SALT LAKE CITY
SALT LAKE CITY (ZLC)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

KVEL FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.7 122.7

ASOS

ASOS
435-781-1224
 118.125

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

No TAF is available for this location.
KVEL
Domestic
5/7/241125Z !VEL 05/001 VEL COM REMOTE COM OUTLET 122.3 U/S 2405071125-2505072000EST
FDC
1/13/251700Z !FDC 5/2897 VEL IAP VERNAL RGNL, VERNAL, UT.
VOR RWY 35, ORIG-B...
DME REQUIRED EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
MTU VOR OUT OF SERVICE. 2501131700-2502131700EST
11/25/241552Z !FDC 4/8490 VEL IAP VERNAL RGNL, VERNAL, UT.
VOR RWY 35, ORIG-B...
ALTERNATE MINIMUMS NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
VEL VOR/DME UNMONITORED. 2411251552-2507071552EST
No
DAWN-DUSK
AFT HR OPS CTC 435-789-8494 OR 435-261-9000.
UINTAH CO AND VERNAL CITY
152 E 100 N.
VERNAL, UT 84078
Phone: (435) 781-0770
KEN CAMPBELL
730 EAST 800 S.
VERNAL, UT 84078
Phone: (435) 789-3400
CEDAR CITY FSS (CDC)
Toll Free: 1-800-WX-BRIEF
VEL
--
ACTVT REIL RWY 17 & 35; MIRL RWY 17/35 - CTAF. PAPI RWY 17 & 35 ON CONSLY.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
None
High & Low Pressure
Air Freight
Pilot Instruction
Aircraft Rental

Runway 17/35

7000 ft. x 100 ft.
ASPH
Excellent
GRVD
MED
18 /F/C/X/T
45,000lbs
55,000lbs
--
--
  Runway 17 Runway 35
True Heading 179°359°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 40° 26' 44"N 40° 25' 35"N
Longitude 109° 30' 42"W 109° 30' 40"W
Elevation 5,268' 5,274'
Threshold Crossing Height 48 ft. AGL 48 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes
A110-1RWY 07/25 DECOMMISSIONED.
A110-3FOR CD IF UNA TO CTC ON FSS FREQ, CTC SALT LAKE ARTCC AT 801-320-2568.
A110-4COLD TEMPERATURE AIRPORT. ALTITUDE CORRECTION REQUIRED AT OR BELOW -26C.
VERNAL RGNL (ICAO: KVEL, IATA: VEL) is a public airport located in VERNAL, UT.
