No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KUNV
STATE COLLEGE RGNL
PublicPUB

3 miles N of STATE COLLEGE, PA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
40° 51' 00"N 77° 50' 51"W
1231' MSL
2231' MSL
11W
JET A, 100LL
ALTOONA (AOO)
DETROIT
NEW YORK (ZNY)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

KUNV FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 128.475

ATIS

D-ATIS
 127.65

AWOS-3

AWOS-3
814-865-8799
 127.65

Clearance Delivery

CD/P
 125.725

Ground

GND/P
 125.725

Tower

LCL/P
 128.475

FAA A/FD Pages

Airport Diagrams

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

No TAF is available for this location.
KUNV
Domestic
11/15/240749Z !UNV 11/010 UNV NAV ILS RWY 24 NOT MNT 2411150749-2501221100
FDC
12/16/242024Z !FDC 4/7533 UNV IAP STATE COLLEGE RGNL,
STATE COLLEGE, PA.
RNAV (GPS) RWY 24, AMDT 2...
CIRCLING CAT C MDA 1980/HAA 749. CIRCLING CAT C VISIBILITY 2 1/4.
ALTERNATE MINIMUMS: STANDARD - CAT C 800-2 1/4, CAT D 1400-3; NA
WHEN LOCAL WEATHER NOT AVAILABLE.
THIS IS RNAV (GPS) RWY 24, AMDT 2A. 2412162024-PERM
12/16/242022Z !FDC 4/7532 UNV IAP STATE COLLEGE RGNL,
STATE COLLEGE, PA.
ILS OR LOC RWY 24, AMDT 10...
CIRCLING CAT C MDA 1980/HAA 749. CIRCLING CAT C VISIBILITY 2 1/4.
CHANGE MISSED APPROACH INSTRUCTION TO READ: CLIMB TO 2600, THEN
CLIMBING LEFT TURN TO 4100 ON HEADING 112, AND PSB VORTAC R-142 TO
RASHE/21.42 DME AND HOLD. ALTERNATE MINIMUMS: ILS: STANDARD - NA
WHEN LOCAL WEATHER NOT AVAILABLE.; LOC: STANDARD - CAT C 800-2 1/4,
CAT D 1400-3, NA WHEN LOCAL WEATHER NOT AVAILABLE.
THIS IS ILS OR LOC RWY 24, AMDT 10A. 2412162022-PERM
Yes
ALL
PENN STATE UNIVERSITY
2535 FOX HILL RD
STATE COLLEGE, PA 16803
Phone: 814-865-4042
BRYAN RODGERS
2535 FOX HILL RD
STATE COLLEGE, PA 16803
Phone: 814-865-4042
ALTOONA FSS (AOO)
Toll Free: 1-800-WX-BRIEF
UNV
--
WHEN ATCT CLSD ACTVT MALSR RWY 24; REIL RWY 06; HIRL RWY 06/24 & TWY LGTS - CTAF.
N/A
Yes - Lighted
Yes
Yes
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Minor
Low Pressure
None
Air Ambulance
Cargo Handling
Charter Service
Pilot Instruction
Aircraft Rental

Runway 06/24

6701 ft. x 150 ft.
ASPH
Good
GRVD
HIGH

50,000lbs
110,000lbs
--
--
  Runway 06 Runway 24
True Heading 53°233°
Traffic Pattern Right Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 40° 50' 40"N 40° 51' 20"N
Longitude 77° 51' 26"W 77° 50' 17"W
Elevation 1,231' 1,192'
Threshold Crossing Height 45 ft. AGL 55 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4R
Approach Lights MALSR
Centerline Lights
Runway End Identifier Lights Yes
A110-1035 FT AGL LGT POLES ON THE N EDGE OF DEICE APN.
A110-11AIR CGO APRN RSTD TO ACFT LESS THAN 12500 LBS.
A110-3ACFT ON EITHER END RWY 06/24 CANNOT BE SEEN ON OTHER END DUE TO RWY GRADE.
A110-4STUDENT TRAINING 2.5 NM NE AT BELLEFONTE ARPT.
A110-5DEICING EQUIP AVBL ON APN ADJ TO TWY B BTN TWYS D & B3.
A110-7(A76) SAWRS.
STATE COLLEGE RGNL (ICAO: KUNV, IATA: UNV) is a public airport located in STATE COLLEGE, PA.
