No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KUDD
BERMUDA DUNES
PublicPUB

13 miles E of PALM SPRINGS, CA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
33° 44' 54"N 116° 16' 29"W
73' MSL
1073' MSL
14E
JET A, JET A (FSII), 100LL
RIVERSIDE (RAL)
LOS ANGELES
LOS ANGELES (ZLA)
10/31/24-11/28/24
KTRM (9nm) VFR
3:52 AM PST
Clear
10sm
38°F
27°F
30.00"Hg
290° 3kts
AO2 SLP158 T00331028 10089 20022 56005 $
KTRM 091152Z AUTO 29003KT 10SM CLR 03/M03 A3000 RMK AO2 SLP158 T00331028 10089 20022 56005 $
Add Your Business

KUDD FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

Hotspot

  • No Documents

Standard Term. Arrival

Instrument Approach

Terminal Area Forecast

KTRM (9nm)
Sat, 11/9 3:20 AM PST
Sat, 11/9 4:00 AM PST - Sun, 11/10 4:00 AM PST
VFR
4:00 AM PST - 4:00 AM PST
Sky Clear
6sm
VRB° 5kts
KTRM 091120Z 0912/1012 VRB05KT P6SM SKC
KUDD
FDC
9/7/231342Z !FDC 3/6903 UDD IAP BERMUDA DUNES, PALM SPRINGS, CA.
RNAV (GPS) RWY 10, ORIG-D...
LNAV MDA CAT A/B/C 500/HAT 427.
2309071342-2509071342EST
No
SEE RMKS
ATNDD OCT 1 THRU MAY 31 0600- 2000; JUNE 1 THRU SEPT 30 0600-1900.
CPF BDA, LLC
3000 AIRWAY AVE, SUITE 200
COSTA MESA, CA 92626
Phone: 949-476-2200
ANN GOODWYN
79880 AVE. 42
BERMUDA DUNES, CA 92203
Phone: 760-345-2558
RIVERSIDE FSS (RAL)
Toll Free: 1-800-WX-BRIEF
RAL
--
VASI RWY 28; MIRL RWY 10/28 ON UNTIL 2200; AFTER 2200 ACTVT - CTAF.
N/A
Yes - Lighted
Yes
Yes
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
Low Pressure
None
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 10/28

5002 ft. x 70 ft.
ASPH
Good
NONE
MED

--
70,000lbs
--
--
  Runway 10 Runway 28
True Heading 116°296°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 33° 45' 05"N 33° 44' 44"N
Longitude 116° 16' 56"W 116° 16' 03"W
Elevation 73' 51'
Threshold Crossing Height -- 33 ft. AGL
Visual Glide Path Angle -- 3°
Visual Slope Indicator -- V2L
Approach Lights
Centerline Lights
Runway End Identifier Lights No Yes
A110-1NO AGRI FLIGHTS EXCP BY PPR ARPT MGR.
A110-10FOR CD CTC SOCAL APCH AT 800-448-3724.
A110-2FOR NOISE ABATEMENT PROCEDURES CALL AMGR (760) 345-2558.
A110-3ARPT CLSD TO TURBINE PWRD ACFT 2300-0600 LCL; EXCP MIL, LAW ENFORCEMENT, EMS ACFT.
A110-5PARL TWY CLSD ACFT WING SPAN GREATER THAN 68 FT.
A110-624 HR EMERG NR 760-609-4414.
A110-7FUEL AVBL 0600-2000.
A110-9ARINC FREQ 129.7 AVBL TO CTC FBO FOR SVCS ONLY
BERMUDA DUNES (ICAO: KUDD, IATA: UDD) is a public airport located in PALM SPRINGS, CA.
