KTPA
TAMPA INTL
PublicPUB

6 miles W of TAMPA, FL
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
27° 58' 32"N 82° 31' 60"W
26' MSL
1026' MSL
05W
JET A, 100LL
SAINT PETERSBURG (PIE)
MIAMI
JACKSONVILLE (ZJX)
10/31/24-11/28/24
KTPA VFR
6:53 AM EST
Few 25,000'
9sm
72°F
71°F
30.02"Hg
070° 5kts
AO2 SLP163 T02220217 10239 20217 53010 $
KTPA 091153Z 07005KT 9SM FEW250 22/22 A3002 RMK AO2 SLP163 T02220217 10239 20217 53010 $

KTPA FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 --

ATIS

D-ATIS
ARR
126.45
D-ATIS
DEP
128.475

ASOS

ASOS
813-873-7228
126.45

Approach

APCH/DEP/P
151-219
134.25
APCH/P IC
118.5

Departure

DEP/P IC
220-360
118.8

Approach/Departure

APCH/P DEP/P
001-150
118.15

Clearance Delivery

CD/P
133.6

Emergency

EMERG
121.5

Ground

GND/P
121.7
GND/S
121.35

Tower

LCL/P
119.5
LCL/S
119.05

Other

BAYPO DP
118.8
BLFRG STAR
119.65
BRDGE STAR
119.65
CLASS B
151-219
119.65
CLASS B
001-150
119.9
CLASS B
220-360
125.3
CROWD DP
135.5
DADES STAR
135.5
DORMR DP
118.8
ENDED DP
118.8
GANDY DP
119.65
KNOST DP
118.8
LGTNG DP
118.8
MAATY STAR
118.8
RAYZZ STAR
118.8
TAMPA DP
134.25

Terminal Area Forecast

KTPA
Sat, 11/9 6:33 AM EST
Sat, 11/9 7:00 AM EST - Sun, 11/10 1:00 PM EST
VFR
7:00 AM EST - 7:00 AM EST
Scattered 25,000'
Few 3,000'
6sm
080° 7kts
VFR
7:00 AM EST - 1:00 PM EST
Scattered 25,000'
Few 3,000'
6sm
100° 8kts
KTPA 091133Z 0912/1018 08007KT P6SM FEW030 SCT250
   FM101200 10008KT P6SM FEW030 SCT250
KTPA
Domestic
11/12/241800Z !TPA 11/048 TPA NAV ILS RWY 19L CAT II NA 2411121800-2411122100
11/12/241800Z !TPA 11/047 TPA RWY 19L ALS U/S 2411121800-2411122100
11/7/241500Z !TPA 11/018 TPA RWY 10/28 CLSD 2411071500-2411071700
11/7/241300Z !TPA 11/045 TPA NAV ILS RWY 19L U/S 2411071300-2411071900
11/7/241300Z !TPA 11/044 TPA NAV ILS RWY 01R U/S 2411071300-2411071900
11/7/241300Z !TPA 11/034 TPA OBST CRANE (ASN UNKNOWN) 275801N0823105W (1NM SE TPA)
123FT (100FT AGL) FLAGGED 2411071300-2411071700
11/7/241300Z !TPA 11/020 TPA TWY E2, E1, C7, C6, C5, C4, C3, C2, C1, D3, D2, D1, TWY E BTN AIRBORNE NORTH RAMP AND TWY E2, TWY D BTN TWY D1 AND TWY F1 CLSD 2411071300-2411071900
11/7/241300Z !TPA 11/017 TPA RWY 01R/19L CLSD 2411071300-2411071900
11/6/241800Z !TPA 11/050 TPA NAV ILS RWY 01L UNUSABLE DA TO TDZ 2411061800-2411062100
11/6/241800Z !TPA 11/049 TPA NAV ILS RWY 19R U/S 2411061800-2411062100
11/6/241300Z !TPA 11/019 TPA TWY N2, N4, TWY N BTN TWY L AND TWY N4 CLSD 2411061300-2411061900
11/6/241300Z !TPA 11/016 TPA RWY 10/28 CLSD 2411061300-2411061900
11/6/241200Z !TPA 11/053 TPA RWY 28 PAPI U/S 2411061200-2411061800
11/6/241200Z !TPA 11/052 TPA RWY 10 PAPI U/S 2411061200-2411061800
11/6/241200Z !TPA 11/051 TPA OBST CRANE (ASN UNKNOWN) 275833N0823125W (.5NM E TPA)
UNKNOWN (80FT AGL) FLAGGED 2411061200-2411062000
11/6/241200Z !TPA 11/035 TPA APRON NORTH REMOTE ACFT PRKG RAMP CLSD DLY 1200-2030 2411061200-2411082030
11/6/240906Z !TPA 11/056 TPA NAV ILS RWY 19L UNUSABLE DA TO TDZ 2411060906-2411082000EST
11/6/240906Z !TPA 11/055 TPA NAV ILS RWY 01R LOC U/S 2411060906-2411082000EST
11/5/241200Z !TPA 11/002 TPA OBST CRANE (ASN UNKNOWN) 275758N0823113W (0.9NM SE TPA)
114FT (90FT AGL) FLAGGED AND LGTD 2411051200-2411080001
11/4/241044Z !TPA 11/023 TPA OBST TOWER LGT (ASR 1030544) 280043.00N0822952.00W (2.9NM NE TPA) 275.9FT (232.9FT AGL) U/S 2411041044-2412040001
11/4/241043Z !TPA 11/022 TPA OBST TOWER LGT (ASR 1040049) 280041.00N0822952.00W (2.9NM NE TPA) 275.6FT (232.6FT AGL) U/S 2411041043-2412040001
11/4/241043Z !TPA 11/021 TPA OBST TOWER LGT (ASR 1040048) 280044.00N0822953.00W (2.9NM NE TPA) 275.6FT (232.6FT AGL) U/S 2411041043-2412040001
11/2/241645Z !TPA 11/004 TPA OBST TOWER LGT (ASR 1046091) 280113.00N0823630.00W (4.7NM NW TPA) 473.8FT (465.9FT AGL) U/S 2411021645-2412171645
11/1/241100Z !TPA 10/311 TPA OBST CRANE (ASN UNKNOWN) 275707N0823159W (1.4NM S TPA)
142FT (130FT AGL) FLAGGED AND LGTD 2411011100-2507012000
11/1/241007Z !TPA 11/001 TPA RWY 01R PAPI U/S 2411011007-2412062000EST
10/28/240825Z !TPA 10/305 TPA AD AP WINDCONE PRI LGT U/S 2410280825-2411292359
10/26/241316Z !TPA 10/299 TPA RWY 19L LEAD OFF CL MARKING AT TWY E1 OBSC 2410261316-2412310400
10/25/241838Z !TPA 10/298 TPA RWY 10 PAPI U/S 2410251838-2411082000EST
10/25/241835Z !TPA 10/297 TPA RWY 19L RVRR U/S 2410251835-2412122000EST
10/25/241834Z !TPA 10/296 TPA RWY 01R RVRT U/S 2410251834-2412122000EST
10/25/241138Z !TPA 10/291 TPA OBST TOWER LGT (ASR 1250319) 280226.30N0822850.80W (4.9NM NE TPA) 192.9FT (145.0FT AGL) U/S 2410251138-2411091038
10/25/241057Z !TPA 10/290 TPA OBST CRANE (ASN 2023-ASO-6965-OE) 275824N0823245W (0.7NM W TPA) 103FT (90FT AGL) FLAGGED AND LGTD 2410251057-2412311100
10/25/241050Z !TPA 10/289 TPA OBST CRANE (ASN 2023-ASO-6960-OE) 275820N0823247W (0.7NM WSW TPA) 107FT (90FT AGL) FLAGGED AND LGTD 2410251050-2412311100
10/23/241532Z !TPA 10/279 TPA OBST TOWER LGT (ASR 1258458) 280711.40N0823243.70W (8.6NM N TPA) 253.6FT (200.8FT AGL) U/S 2410231532-2411070400
10/22/241100Z !TPA 10/225 TPA OBST CRANE (ASN 2023-ASO-11002-NRA) 275823N0823101W (0.9NM E TPA) 212FT (180FT AGL) FLAGGED 2410221100-2412312200
10/14/242257Z !TPA 10/217 TPA OBST CRANE (ASN 2023-ASO-6946-OE) 275748N0823246W (1.0NM SW TPA) 101FT (90FT AGL) FLAGGED AND LGTD 2410142257-2412312100
10/14/242256Z !TPA 10/216 TPA OBST CRANE (ASN 2023-ASO-6947-OE) 275746N0823246W (1.0NM SW TPA) 101FT (90FT AGL) FLAGGED AND LGTD 2410142256-2412312100
10/11/241108Z !TPA 10/168 TPA RWY 19L ALSF-2 NOW SSALR 2410111108-2411152000EST
10/5/241351Z !TPA 10/054 TPA RWY 01R LEAD OFF CL MARKINGS AT TWY C5 OBSC 2410051351-2411300400
10/4/241639Z !TPA 10/046 TPA NAV ILS RWY 01L CAT II NA 2410041639-2411142000EST
10/4/241637Z !TPA 10/045 TPA RWY 01L ALS U/S 2410041637-2411142000EST
10/2/241947Z !TPA 10/018 TPA OBST TOWER LGT (ASR 1221149) 275643.80N0822948.30W (2.6NM SE TPA) 256.9FT (232.9FT AGL) U/S 2410021947-2412022359
9/29/241914Z !TPA 09/263 TPA TWY W1 CL MARKINGS BTN APCH END RWY 01L AND TWY W NOT STD 2409291914-2501012200
9/23/240040Z !TPA 09/209 TPA OBST TOWER LGT (ASR 1011299) 275919.80N0823055.60W (1.3NM NE TPA) 169.0FT (140.1FT AGL) U/S 2409230040-2412210400
9/16/241100Z !TPA 09/091 TPA OBST CRANE (ASN 2024-ASO-709-NRA) 275852N0823203W (0.3NM N TPA) 279FT (253FT AGL) FLAGGED AND LGTD 2409161100-2501010100
8/28/240400Z !TPA 08/203 TPA OBST CRANE (ASN UNKNOWN) 275748N0823050W (1.3NM SE TPA)
UNKNOWN (180FT AGL) FLAGGED AND LGTD 2408280400-2509300401
8/27/241100Z !TPA 08/205 TPA OBST CRANE (ASN UNKNOWN) 275306N0823144W (5.4NM S TPA)
271FT (260FT AGL) FLAGGED AND LGTD DLY 1100-2200 2408271100-2411222200
8/6/241012Z !TPA 08/040 TPA RWY 19R ALS U/S EXC MEDIUM INTST ON CONS 2408061012-2411112000EST
5/18/241631Z !TPA 05/102 TPA APRON TXL V BTN TWY V2 AND TWY V3 CLSD TO ACFT WINGSPAN MORE THAN 171FT EXC 1HR PPR 813-781-8212 2405181631-2512310001
2/23/241947Z !TPA 02/183 TPA RWY 10/28 SAFETY AREA NOT STD N SIDE 2402231947-2501012200
2/23/241943Z !TPA 02/182 TPA RWY 01R/19L SAFETY AREA NOT STD N END 2402231943-2501012200
2/23/241941Z !TPA 02/181 TPA RWY 01L/19R SAFETY AREA NOT STD N END 2402231941-2501012200
7/27/231654Z !TPA 07/206 TPA OBST CRANE (ASN UNKNOWN) 275621N0823321W (2.5NM SW TPA)
104FT (100FT AGL) FLAGGED AND LGTD 2307271654-2501202200
FDC
11/1/241343Z !FDC 4/7858 TPA ODP TAMPA INTL, TAMPA, FL.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 10...
ADD TAKEOFF OBSTACLE NOTES: RWY 19L, TEMPORARY CRANE 4523FT FROM DER, 1139FT RIGHT OF CENTERLINE, 130FT AGL/ 142FT MSL (2024-ASO-16250-OE). ALL OTHER DATA REMAINS AS PUBLISHED. 2411011343-2507161343EST
11/1/240400Z !FDC 4/7703 TPA IAP TAMPA INTL, TAMPA, FL.
LOC RWY 1R, AMDT 4C...
ALTERNATE MINIMUMS NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
LAL VOR UNMONITORED. 2411010400-2411080035EST
10/28/241836Z !FDC 4/5143 TPA IAP TAMPA INTL, TAMPA, FL.
ILS OR LOC RWY 19R, AMDT 6...
ILS OR LOC RWY 1L, AMDT 18...
LOC RWY 1R, AMDT 4C...
RNAV (GPS) RWY 19R, AMDT 2D...
RNAV (GPS) RWY 1L, AMDT 2D...
RNAV (GPS) RWY 28, AMDT 1C...
CIRCLING CAT A/B/C MDA 780/HAA 754. TEMPORARY CRANE 414 MSL 2.1NM SE OF TPA AIRPORT (2022-ASO-44335-OE). TEMPORARY CRANE 256 MSL 2.5NM SW OF TPA AIRPORT (2023-ASO-21531-OE). TEMPORARY CRANE 279 MSL 2929FT N OF TPA AIRPORT (2024-ASO-709-NRA).
2410281836-2502251836EST
10/22/241851Z !FDC 4/2436 TPA IAP TAMPA INTL, TAMPA, FL.
ILS OR LOC RWY 19R, AMDT 6...
MISSED APPROACH: TACAN PORTION NA,
PIE TACAN OUT OF SERVICE. 2410221851-2501081851EST
10/22/241851Z !FDC 4/2435 TPA IAP TAMPA INTL, TAMPA, FL.
ILS OR LOC RWY 19L, AMDT 41...
ILS RWY 19L (SA CAT I), AMDT 41...
ILS RWY 19L (CAT II), AMDT 41...
MISSED APPROACH: CLIMB TO 3000 ON SRQ VOR/DME R-007 TO CARIR INT/SRQ 16.76 DME AND HOLD,
PIE TACAN OUT OF SERVICE. 2410221851-2501081851EST
10/22/241851Z !FDC 4/2433 TPA IAP TAMPA INTL, TAMPA, FL.
ILS OR LOC RWY 1L, AMDT 18...
ILS RWY 1L (SA CAT I), AMDT 18...
ILS RWY 1L (CAT II - III), AMDT 18...
MISSED APPROACH: TACAN PORTION NA,
PIE TACAN OUT OF SERVICE. 2410221851-2501081851EST
10/22/241711Z !FDC 4/2230 TPA IAP TAMPA INTL, TAMPA, FL.
RNAV (GPS) RWY 1R, AMDT 3A...
CHANGE LPV VISIBILITY ALL CATS TO RVR 4500, LNAV VISIBILITY CAT A/B TO RVR 5500 CAT C/D/E TO RVR 6000.
2410221711-2610221711EST
10/10/240634Z !FDC 4/7700 TPA IAP TAMPA INTL, TAMPA, FL.
ILS OR LOC RWY 19L, AMDT 41...
ILS OR LOC RWY 19R, AMDT 6...
ILS OR LOC RWY 1L, AMDT 18...
ILS RWY 1L (CAT II AND III), AMDT 18...
ILS RWY 19L (SA CAT I), AMDT 41...
ILS RWY 19L (CAT II), AMDT 41...
ILS RWY 1L (SA CAT I), AMDT 18....
ALTERNATE MINIMUMS NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
PIE VORTAC UNMONITORED. 2410100634-2411100634EST
10/1/241909Z !FDC 4/3124 TPA IAP TAMPA INTL, TAMPA, FL.
RNAV (GPS) RWY 10, AMDT 2A...
LNAV MDA 580/HAT 558 ALL CATS, VIS CAT C/D 1 5/8. CIRCLING CAT A/B/C MDA 780/HAA 754. TEMPORARY CRANE 414 MSL 2.1NM SE OF TPA AIRPORT (2022-ASO-44335-OE). TEMPORARY CRANE 256 MSL 2.5NM SW OF TPA AIRPORT (2023-ASO-21531-OE). TEMPORARY CRANE 279 MSL 3753FT N OF RWY 10 (2024-ASO-709-NRA).
2410011909-2502251909EST
9/23/241111Z !FDC 4/9099 TPA IAP TAMPA INTL, TAMPA, FL.
ILS RWY 19L (SA CAT I), AMDT 41 ...
ILS RWY 19L (CAT II), AMDT 41 ...
ILS RWY 1L (SA CAT I), AMDT 18 ...
PROCEDURE NA. TEMPORARY CRANE 279 MSL 2929FT SW OF RWY 19L (2024-ASO-709-NRA). 2409231111-2501251111EST
9/23/241110Z !FDC 4/9097 TPA IAP TAMPA INTL, TAMPA, FL.
RNAV (GPS) RWY 1R, AMDT 3A...
LNAV MDA 500/HAT 480 ALL CATS. VIS CATS C/D/E 1 3/8. CIRCLING CAT A/B/C MDA 780/HAA 754. VDP 1.3 NM TO RW01R. TEMPORARY CRANE 414 MSL 2.1NM SE OF TPA AIRPORT (2022-ASO-44335-OE). TEMPORARY CRANE 256 MSL 2.5NM SW OF TPA AIRPORT (2023-ASO-21531-OE). TEMPORARY CRANE 241 MSL 2093FT E OF RWY 1R (2024-ASO-5712-NRA). TEMPORARY CRANE 279 MSL 3753FT N OF RWY 10 (2024-ASO-709-NRA).
2409231110-2502251110EST
9/23/241110Z !FDC 4/9096 TPA IAP TAMPA INTL, TAMPA, FL.
RNAV (GPS) Z RWY 19L, AMDT 2F...
LPV DA 328/HAT 302 ALL CATS, VIS ALL CATS RVR 5000. CIRCLING CAT A/B/C MDA 780/HAA 754. DISREGARD NOTE: ** RVR 1800 AUTHORIZED WITH USE OF FD OR AP OR HUD TO DA. TEMPORARY CRANE 279 MSL 2929FT SW OF RWY 19L (2024-ASO-709-NRA). TEMPORARY CRANE 414 MSL 2.1NM SE OF TPA AIRPORT (2022-ASO-44335-OE). TEMPORARY CRANE 256 MSL 2.5NM SW OF TPA AIRPORT (2023-ASO-21531-OE)..
2409231110-2502251110EST
9/23/241110Z !FDC 4/9093 TPA IAP TAMPA INTL, TAMPA, FL.
ILS OR LOC RWY 19L, AMDT 41...
S-ILS 19L DA 328/HAT 302 ALL CATS, VIS ALL CATS RVR 5000. CIRCLING CAT A/B/C MDA 780/HAA 754. INOP TABLE DOES NOT APPLY TO S-ILS 19L ALL CATS. TEMPORARY CRANE 279 MSL 2929FT SW OF RWY 19L (2024-ASO-709-NRA). TEMPORARY CRANE 414 MSL 2.1NM SE OF TPA AIRPORT (2022-ASO-44335-OE). TEMPORARY CRANE 256 MSL 2.5NM SW OF TPA AIRPORT (2023-ASO-21531-OE).
2409231110-2502251110EST
Yes
ALL
HILLSBOROUGH CO AVN AUTHORITY
PO BOX 22287
TAMPA, FL 33622
Phone: 813-870-8700
JOHN TILIACOS
PO BOX 22287
TAMPA, FL 33622
Phone: 813-870-8700
SAINT PETERSBURG FSS (PIE)
Toll Free: 1-800-WX-BRIEF
TPA
Sunset to Sunrise
--
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
Airport of Entry
0
0
0
0
0
0
Major
Major
High & Low Pressure
High & Low Pressure
Avionics
Cargo Handling
Charter Service

Runway 01L/19R

11002 ft. x 150 ft.
CONC
Good
GRVD
HIGH
85 /R/B/W/T
60,000lbs
210,000lbs
358,000lbs
850,000lbs
  Runway 01L Runway 19R
True Heading 182°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 27° 57' 48"N 27° 59' 37"N
Longitude 82° 32' 32"W 82° 32' 29"W
Elevation 11' 21'
Threshold Crossing Height 71 ft. AGL 71 ft. AGL
Visual Glide Path Angle
Visual Slope Indicator P4L P4L
Approach Lights ALSF2 MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights No No

Runway 01R/19L

8300 ft. x 150 ft.
ASPH CONC
Good
GRVD
HIGH
76 /R/B/W/T
60,000lbs
210,000lbs
358,000lbs
850,000lbs
  Runway 01R Runway 19L
True Heading 182°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 27° 57' 52"N 27° 59' 14"N
Longitude 82° 31' 44"W 82° 31' 42"W
Elevation 18' 26'
Threshold Crossing Height 71 ft. AGL 61 ft. AGL
Visual Glide Path Angle
Visual Slope Indicator P4L P4L
Approach Lights ALSF2
Centerline Lights Yes Yes
Runway End Identifier Lights Yes No

Runway 10/28

6999 ft. x 150 ft.
ASPH CONC
Fair
GRVD
HIGH
61 /F/A/W/T
75,000lbs
200,000lbs
280,000lbs
380,000lbs
  Runway 10 Runway 28
True Heading 92°272°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 27° 58' 15"N 27° 58' 13"N
Longitude 82° 32' 10"W 82° 30' 52"W
Elevation 14' 26'
Threshold Crossing Height 42 ft. AGL 50 ft. AGL
Visual Glide Path Angle
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights No No
A110-10RSTRS TO ADG IV OR LGR: TWY E1.
A110-11TXL K1 AND TXL K2 CLSD TO WINGSPANS GTR THAN 171 FT, TXL K1 AND TXL K2 CLSD WHILE WIDE BODY TXL K1W IS IN USE.
A110-2RWY 19L IS NOISE SENSITIVE TO TBJT DEPARTURES. RWY 01R IS NOISE SENSITIVE TO TBJT ARRIVALS. PUBLD NOISE ABATEMENT PROCS IN EFCT.
A110-3ONLY ACFT WITH PRIOR PMSN MAY USE TRML APN; ALL OTRS USE GA APN.
A110-4BIRD ACT ON AND INVOF ARPT.
A110-7TWY J BTN TWY J1 AND TWY J2; TWY N W OF TWY L; TWY E N OF TWY J; TXL Z; TXL V BTN TWY V2 AND TWY V3 ARE UNAVBL FOR GROUP V ACFT WITH A WINGSPAN GTR THAN 171 FT WO PPR FROM ARPT OPS.
A110-8TXL F AND TXL R ARE NON-MOVEMENT AREAS. BOTH LCTNS ARE UNAVBL FOR GROUP IV ACFT WITH A WINGSPAN GTR THAN 117 FT WO PPR FROM ARPT OPS. TXL T PPR FROM ARPT OPS RQRD FOR ACFT WITH A WINGSPAN GTR THAN 90 FT.
A110-9TAXILANE G WEST OF TWY B1 CLSD TO WINGSPAN GTR THAN 118 FT - PPR APT OPS.
TAMPA INTL (ICAO: KTPA, IATA: TPA) is a public airport located in TAMPA, FL.
