KTNX
TONOPAH TEST RANGE
PrivatePVT

27 miles SE of TONOPAH, NV
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
37° 47' 56"N 116° 46' 51"W
5550' MSL
6550' MSL
16E
JET A+, CILI
RENO (RNO)
LAS VEGAS
LOS ANGELES (ZLA)
4/17/25-5/15/25
KTPH (21nm) VFR
11:56 PM PST
No Clouds
N/A
32°F
32°F
30.37"Hg
Calm
AO2 SLPNO PWINO $
METAR KTPH 270756Z AUTO A3037 RMK AO2 SLPNO PWINO $
+ Add Your Business

KTNX FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- --

Ground

GND/P
 127.25

Tower

LCL/P
 124.75

Other

PTD
 119.45

Terminal Area Forecast

KTPH (21nm)
Wed, 11/26 9:20 PM PST
Wed, 11/26 10:00 PM PST - Thu, 11/27 10:00 PM PST
VFR
10:00 PM PST - 10:00 AM PST
Scattered 15,000'
6sm
360° 7kts
VFR
10:00 AM PST - 10:00 PM PST
Scattered 20,000'
6sm
210° 6kts
TAF KTPH 270520Z 2706/2806 36007KT P6SM SCT150
   FM271800 21006KT P6SM SCT200 AMD NOT SKED
KTNX
EffectiveExpiresCategoryNOTAM
Military
11/28/25
0800Z
11/29/25
0300Z
TOWER UNMANNED
11/28/25
0800Z
11/29/25
0300Z
AMOPS UNMANNED
11/25/25
2147Z
11/28/25
2147Z
M0081/25 NOTAMC M0080/25
11/24/25
1404Z
12/31/26
2359Z
Aerodrome!KTNX V0088/25 TNX AERODROME STANDARD INSTRUMENT DEPARTURE (SID) COMPLETELY WITHDRAWN TUMBE 1 (RNAV) DEPARTURE 2511241404-2612312359
11/3/25
1545Z
5/31/26
2359Z
Aerodrome!KTNX V0087/25 TNX AERODROME INSTRUMENT APPROACH PROCEDURE CHANGED VOR/DME Z RWY 32 PROCEDURE NAME TO VOR/DME Z RWY 33 2511031545-2605312359
11/3/25
1544Z
5/31/26
2359Z
Aerodrome!KTNX V0086/25 TNX AERODROME INSTRUMENT APPROACH PROCEDURE CHANGED VOR/DME Z RWY 14 PROCEDURE NAME TO VOR/DME Z RWY 15 2511031544-2605312359
11/3/25
1542Z
5/31/26
2359Z
Aerodrome!KTNX V0085/25 TNX AERODROME INSTRUMENT APPROACH PROCEDURE CHANGED VOR/DME OR TACAN RWY 32 PROCEDURE NAME TO VOR/DME OR TACAN RWY 33 2511031542-2605312359
11/3/25
1539Z
5/31/26
2359Z
Aerodrome!KTNX V0084/25 TNX AERODROME INSTRUMENT APPROACH PROCEDURE CHANGED VOR/DME OR TACAN RWY 14 PROCEDURE NAME TO VOR/DME OR TACAN RWY 15 2511031539-2605312359
11/3/25
1538Z
5/31/26
2359Z
Aerodrome!KTNX V0083/25 TNX AERODROME INSTRUMENT APPROACH PROCEDURE CHANGED RNAV (GPS) RWY 32 PROCEDURE NAME TO RNAV (GPS) RWY 33 2511031538-2605312359
11/3/25
1537Z
5/31/26
2359Z
Aerodrome!KTNX V0082/25 TNX AERODROME INSTRUMENT APPROACH PROCEDURE CHANGED RNAV (GPS) RWY 14 PROCEDURE NAME TO RNAV (GPS) RWY 15. 2511031537-2605312359
11/3/25
1535Z
5/31/26
2359Z
Aerodrome!KTNX V0081/25 TNX AERODROME INSTRUMENT APPROACH PROCEDURE CHANGED ILS OR LOC/DME RWY 32 PROCEDURE NAME TO ILS OR LOC/DME RWY 33 2511031535-2605312359
11/3/25
1534Z
5/31/26
2359Z
Aerodrome!KTNX V0080/25 TNX AERODROME INSTRUMENT APPROACH PROCEDURE CHANGED ILS OR LOC/DME RWY 14 PROCEDURE NAME TO ILS OR LOC/DME RWY 15. 2511031534-2605312359
11/3/25
1120Z
1/23/26
2359Z
AerodromeAERODROME TOWER UNMANNED DAILY MONDAY THROUGH FRIDAY, 0345Z TO 1145Z, UNLESS COORDINATED AT LEASE 7 DAYS IN ADVANCE, AIRFIELD MANAGEMENT, FIRE DEPT, AND TRANSIENT ALERT SERVICES ARE AVAILABLE FOR EMERGENCY AIRCRAFT ONLY. CONTACT AIRFIELD MANAGEMENT ON PTD FREQ 119345 OR 233.95 WITH EMERGENCY INFORMATION
10/29/25
1420Z
1/26/26
2359Z
USE CAUTION BIRD ACTIVITY EXIST IN THE VICINITY, BASH MIGRATORY ACT OCT-MAR (PHASE II)
10/29/25
1414Z
1/26/26
2359Z
RunwayRWY 14/32 HAS BEEN RE-DESIGNATED TO RWY 15/33. ALL PILOTS ARE ADVISED TO USE UPDATED RWY NUMBERS EFFECTIVE IMMEDIATELY. EXISTING INSTRUMENT PROCEDURES FOR RWY 14/32 REMAIN VALID.
10/28/25
1626Z
1/23/26
2359Z
RunwayRWY 15/33 NAVAID BOTH ILS OTS
Yes
ALL
1300Z++ MON - 0305Z++ FRI; CLSD WKEND & HOL; OTR TIMES BY NOTAM.
US AIR FORCE
HQ AIR COMBAT COMMAND
LANGLEY AFB, VA 23665
Phone: 804-764-3120
VERNON GABBARD JR
SANDIA LAB PO BOX 871
TONOPAH, NV 89049
Phone: 702-295-8313
RENO FSS (RNO)
Toll Free: 1-800-WX-BRIEF
RNO
--
ACTVT ALSF-1 RWY 14 & 32; PAPI RWY 14 & 32; HIRL RWY 14/32 - 257.95. ALSF-1 RWY 14 & 32 HI INTST ONLY.
N/A
Yes
Yes
No
None
No
None
None
None
None
None

Runway 14/32

12001 ft. x 150 ft.

CONC
NONE
HIGH
52 /R/C/W/T
--
--
--
--
  Runway 14 Runway 32
True Heading 157°337°
Traffic Pattern Left
Markings
Markings Condition
Latitude 37° 48' 51"N 37° 47' 01"N
Longitude 116° 47' 20"W 116° 46' 22"W
Elevation 5,473' 5,550'
Threshold Crossing Height 51 ft. AGL 39 ft. AGL
Visual Glide Path Angle 2.75° 2.75°
Visual Slope Indicator P4L P4L
Approach Lights ALSF1 ALSF1
Centerline Lights
Runway End Identifier Lights
A110-1RSTRD: AFLD LCTD WITHIN R4809; CTC 98 RANGE WING/XPR D348-5537/C702-653-5537; 72 HR PPR - AFLD OPS D384-5937/C702-653-5937.
A110-11MISC: TWY E VOR RCVR CK POINT UNUSBL; NO CLASSIFIED MTRL STORAGE.
A110-13CTN: HI PER MIL OPS R4809A.
A110-15BASH MIGRATORY BIRD ACT OCT- MAR PHASE II.
A110-16RSTRD: DOWNWARD THRUST JET BLAST RSTD FM FULL PWR FIRST 500 FT RWY 14 & 32.
A110-17MISC: AD VER TKOF/LDG NA.
A110-18PPR - COORD THRU POC/SPONSOR.
A110-19WX BRIEF AFT OPS HRS - 25 OWS DAVIS MONTHAN AFB D228-6598/6599/C520-228-6598/6599.
A110-20RSTD: DELTA RAMP SFC MARKING NSTD.
A110-21RSTD: ALL TRAN ACFT MUST OBTAIN PPR PRIOR TO ARR. ACFT MUST ADHERE TO PPR ARR BLOCK +/- 30 MIN OF SKED LDG.
A110-5JASU-3 (AM32A-60A).
A110-7FLUID-DE-ICE.
A110-8OIL- O-148.
A110-9TRAN ALERT: 1300-0300Z++ WKDAY; CLSD WKEND & HOL; FLEET SVC & MAINT UNAVBL.
TONOPAH TEST RANGE (ICAO: KTNX, IATA: TNX) is a private airport located in TONOPAH, NV.
