iFlightPlanner



...
No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KTMK
TILLAMOOK
PublicPUB

3 miles S of TILLAMOOK, OR
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
45° 25' 06"N 123° 48' 52"W
39' MSL
1039' MSL
20E
JET A, 100LL
MC MINNVILLE (MMV)
SEATTLE
SEATTLE (ZSE)
10/31/24-11/28/24
KTMK VFR
3:35 AM PST
Scattered 12,000'
10sm
46°F
45°F
29.99"Hg
Calm
AO2
KTMK 091135Z AUTO 00000KT 10SM SCT120 08/07 A2999 RMK AO2
Add Your Business

KTMK FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

AWOS-3PT

AWOS-3PT
503-842-8792
 120.0

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KHIO (37nm)
Sat, 11/9 3:24 AM PST
Sat, 11/9 4:00 AM PST - Sun, 11/10 4:00 AM PST
VFR
4:00 AM PST - 12:00 PM PST
Broken 15,000'
6sm
VRB° 2kts
VFR
12:00 PM PST - 4:00 PM PST
Showers in vicinity
Broken 6,000'
6sm
190° 4kts
VFR
4:00 PM PST - 10:00 PM PST
Light Rain
Broken 4,500'
6sm
160° 3kts
MVFR
10:00 PM PST - 4:00 AM PST
Showers in vicinity
Overcast 3,500'
Broken 2,500'
6sm
VRB° 2kts
KHIO 091124Z 0912/1012 VRB02KT P6SM BKN150
   FM092000 19004KT P6SM VCSH BKN060
   FM100000 16003KT P6SM -RA BKN045
   FM100600 VRB02KT P6SM VCSH BKN025 OVC035
KTMK
Domestic
9/26/240101Z !TMK 09/001 TMK SVC AUTOMATED WX BCST SYSTEM DP/PRESENT WX UNREL 2409260101-2412052359EST
No
0900-1700
PORT OF TILLAMOOK BAY
4000 BLIMP BLVD
TILLAMOOK, OR 97141
Phone: (503) 842-7152
JAMES PEAK
4000 BLIMP BLVD
TILLAMOOK, OR 97141
Phone: 503-842-2413
MC MINNVILLE FSS (MMV)
Toll Free: 1-800-WX-BRIEF
TMK
--
ACTVT REIL RWY 13; MIRL RWY 13/31 AND RWY 01/19- CTAF. PAPI RWYS 13 & 31 AND RWYS 01 & 19 OPER CONT.
N/A
Yes - Lighted
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
Cargo Handling
Charter Service

Runway 01/19

2911 ft. x 75 ft.
ASPH
Good
NONE
MED

40,000lbs
46,000lbs
67,000lbs
--
  Runway 01 Runway 19
True Heading 30°210°
Traffic Pattern Left Right
Markings BSC BSC
Markings Condition FAIR FAIR
Latitude 45° 24' 55"N 45° 25' 19"N
Longitude 123° 48' 59"W 123° 48' 38"W
Elevation 29' 36'
Threshold Crossing Height 45 ft. AGL 40 ft. AGL
Visual Glide Path Angle 4° 3°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 13/31

5001 ft. x 75 ft.
ASPH
Good
NONE
MED

60,000lbs
75,000lbs
125,000lbs
--
  Runway 13 Runway 31
True Heading 155°335°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition FAIR FAIR
Latitude 45° 25' 27"N 45° 24' 42"N
Longitude 123° 49' 08"W 123° 48' 39"W
Elevation 20' 39'
Threshold Crossing Height 42 ft. AGL 40 ft. AGL
Visual Glide Path Angle 3° 3.5°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes
A110-1OCNL FLOCKS OF BIRDS ON OR NEAR ARPT.
A110-3(E94) SAWRS
A110-5ULTRALIGHT ACFT ON AND INVOF ARPT.
A110-6FOR CD CTC SEATTLE ARTCC AT 253-351-3694.
TILLAMOOK (ICAO: KTMK, IATA: TMK) is a public airport located in TILLAMOOK, OR.
