KTCY
TRACY MUNI
PublicPUB

3 miles SW of TRACY, CA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
37° 41' 20"N 121° 26' 30"W
194' MSL
994' MSL
15E
JET A, 100LL
RANCHO MURIETA (RIU)
SAN FRANCISCO
OAKLAND (ZOA)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

KTCY FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
123.075 123.075

AWOS-3

AWOS-3
209-831-4335
 118.375

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

No TAF is available for this location.
KTCY
Domestic
11/4/241437Z !TCY 11/002 TCY RWY 26 PAPI U/S 2411041437-2505052111EST
11/4/241437Z !TCY 11/001 TCY RWY 12 PAPI U/S 2411041437-2505052111EST
5/15/241600Z !TCY 05/012 TCY AIRSPACE SEE MOD 05/010 PJE DLY 1600-0100 2405151600-2505140100
FDC
4/17/241142Z !FDC 4/1913 TCY IAP TRACY MUNI, TRACY, CA.
RNAV (GPS) RWY 12, AMDT 2B...
RNAV (GPS) RWY 26, AMDT 1C...
RNAV (GPS) RWY 30, AMDT 1B...
CIRCLING CAT A MDA 640/HAA 447. WATER TANK 275 MSL 1.4NM NE OF TCY AIRPORT (2024-AWP-696-OE).
2404171142-2604201142EST
8/2/231650Z !FDC 3/6940 TCY IAP TRACY MUNI, TRACY, CA.
RNAV (GPS) RWY 26, AMDT 1C...
LNAV/VNAV DA 504/HAT 318 ALL CATS. LNAV MDA 640/HAT454 ALL CATS. CIRCLING CAT A MDA 640/HAA 447.
2308021650-2608021650EST
7/5/232014Z !FDC 3/1701 TCY IAP TRACY MUNI, TRACY, CA.
RNAV (GPS) RWY 12, AMDT 2B...
LNAV MDA 540/HAT 347 ALL CATS.
2307052014-2507052014EST
No
0800-1800
CITY OF TRACY
333 CIVIC CENTER PLAZA
TRACY, CA 95376-4917
Phone: (209) 831-6200
PAULA JESSUP
5749 SOUTH TRACY BLVD
TRACY, CA 95376-4917
Phone: (209) 831-6215
RANCHO MURIETA FSS (RIU)
Toll Free: 1-800-WX-BRIEF
TCY
--
ACTVT REIL RWY 08, 26, 12, & 30; PAPI RWY 08, 12 & 26; MIRL RWY 08/26 & 12/30 - CTAF. PAPI RWY 30 IS OPRD AT NGT BY CTAF FROM SS TO SR AND IS ON DRG DALGT HRS.
N/A
Yes - Lighted
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
Low Pressure
None
Pilot Instruction
Aircraft Rental

Runway 08/26

3438 ft. x 75 ft.
ASPH
Good
NONE
MED

50,000lbs
70,000lbs
120,000lbs
--
  Runway 08 Runway 26
True Heading 90°270°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 37° 41' 26"N 37° 41' 26"N
Longitude 121° 26' 54"W 121° 26' 11"W
Elevation 190' 173'
Threshold Crossing Height 26 ft. AGL 20 ft. AGL
Visual Glide Path Angle 3.4° 3°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes Yes

Runway 12/30

4001 ft. x 75 ft.
ASPH
Good
NONE
MED

50,000lbs
70,000lbs
120,000lbs
--
  Runway 12 Runway 30
True Heading 132°312°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 37° 41' 28"N 37° 41' 02"N
Longitude 121° 26' 46"W 121° 26' 09"W
Elevation 181' 194'
Threshold Crossing Height 41 ft. AGL 35 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes Yes
A110-1BALLOON AND PARAPLANE ACTIVITY ON THE AIRPORT.
A110-3AEROBATIC AREA ADJ/WI 1 SMR FROM 500 AGL - 3000 MSL SR-SS.
A110-5TWO 150 FT PWR PLANT STACKS APPROX 3 NM NW OF ARPT. WATCH FOR PSBL TURB.
A110-6FOR CD CTC NORCAL APCH AT 916-361-0516.
TRACY MUNI (ICAO: KTCY, IATA: TCY) is a public airport located in TRACY, CA.
