KSTP
ST PAUL DOWNTOWN HOLMAN FLD
PublicPUB

1 miles S of ST PAUL, MN
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
44° 56' 05"N 93° 03' 37"W
705' MSL
1905' MSL
00E
JET A, 100LL
PRINCETON (PNM)
TWIN CITIES
MINNEAPOLIS (ZMP)
7/11/24-8/8/24
KSTP VFR
5:53 AM CDT
Broken 7,500'
Broken 6,000'
10sm
71°F
61°F
29.78"Hg
140° 6kts
AO2 LTG DSNT N AND E AND W SLP079 T02170161
KSTP 191053Z 14006KT 10SM BKN060 BKN075 22/16 A2978 RMK AO2 LTG DSNT N AND E AND W SLP079 T02170161
Add Your Business

KSTP FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 119.1

ATIS

ATIS
 118.35

ASOS

ASOS
651-312-8888
 118.35

Clearance Delivery

CD/P
 121.675

Ground

GND/P
 121.675

Tower

LCL/P
 119.1

Other

NG OPS
FM
 49.65
OPS
 41.5
OPS
 126.2
OPS
 139.2

Terminal Area Forecast

KMSP (8nm)
Thu, 9/19 3:33 AM CDT
Thu, 9/19 4:00 AM CDT - Fri, 9/20 7:00 AM CDT
VFR
4:00 AM CDT - 1:00 PM CDT
Broken 10,000'
6sm
150° 10kts
VFR
5:00 AM CDT - 8:00 AM CDT
Light Thunderstorm and Rain
Broken 5,000'
N/A
Calm
VFR
1:00 PM CDT - 8:00 PM CDT
Scattered 5,000'
6sm
200° 13kts
Gusts 21kts
MVFR
Temporary 4:00 PM CDT - 7:00 PM CDT
Thunderstorm and Rain and Mist
Overcast 3,000'
3sm
Calm
VFR
8:00 PM CDT - 1:00 AM CDT
Sky Clear
6sm
200° 6kts
VFR
1:00 AM CDT - 7:00 AM CDT
Sky Clear
6sm
230° 4kts
KMSP 190833Z 1909/2012 15010KT P6SM BKN100
   PROB30 1910/1913 -TSRA BKN050CB
   FM191800 20013G21KT P6SM SCT050
   TEMPO 1921/1924 3SM TSRA BR OVC030CB
   FM200100 20006KT P6SM SKC
   FM200600 23004KT P6SM SKC
KSTP
Domestic
9/17/241510Z !STP 09/008 STP OBST TOWER LGT (ASR 1063782) 445440.60N0925910.70W (3.4NM ESE STP) 1228.0FT (240.2FT AGL) U/S 2409171510-2412160400
8/26/241438Z !STP 08/026 STP OBST TOWER LGT (ASN 2017-AGL-10859-OE) 445413N0930445W (2.0NM SSW STP) 1095FT (109FT AGL) U/S 2408261438-2410101437
8/8/240500Z !STP 08/013 STP OBST TOWER LGT (ASR 1028311) 445730.00N0930432.00W (1.6NM NNW STP) 971.8FT (155.8FT AGL) U/S 2408080500-2412060500
7/3/240504Z !STP 07/002 STP OBST TOWER LGT (ASR 1212317) 445808.90N0930307.80W (2.1NM NE STP) 1078.4FT (204.7FT AGL) U/S 2407030504-2410310504
4/25/241200Z !STP 04/012 STP OBST CRANE (ASN 2023-AGL-20090-OE) 445715N0930618W (2.2NM WNW STP) 1070FT (200FT AGL) FLAGGED AND LGTD 2404251200-2604242200
FDC
12/20/231634Z !FDC 3/8113 STP SID ST PAUL DOWNTOWN HOLMAN FLD, ST PAUL, MN.
COULT SEVEN DEPARTURE...
TAKE-OFF MINIMUMS RWY 13: STANDARD WITH MINIMUM CLIMB OF 235 FT PER NM TO 1500.
MINIMUM ALTITUDE AT TAXEE 4600. EAU VORTAC RESTRICTED. 2312201634-2512201634EST
Yes
ALL
METRO ARPT COMMSN
6040 28TH AVE, SO
MINNEAPOLIS, MN 55450
Phone: 651-726-8100
BLAINE PETERSON
644 BAYFIELD
ST PAUL, MN 55107
Phone: 651-224-4306
PRINCETON FSS (PNM)
Toll Free: 1-800-WX-BRIEF
STP
--
WHEN ATCT CLSD, TO INCR INTST & ACTVT MALSR RWY 14; REIL RWY 31; PAPI RWY 13, 27, & 31; HIRL RWY 14/32 & 13/31; MIRL RWY 09/27; - CTAF. RWY 14 & 32 PAPI OPS CONSLY.
N/A
AIRPORT BEACON ON WEST EDGE OF ARPT.
Yes - Lighted
No
Yes
Hanger, Tie-Down
Landing Rights Airport
NOT an Airport of Entry
11
7
20
2
35
0
Major
Major
None
High & Low Pressure
Air Ambulance
Avionics
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 09/27

3642 ft. x 100 ft.
ASPH
Good
NONE
MED

12,000lbs
--
--
--
  Runway 09 Runway 27
True Heading 91°271°
Traffic Pattern Right
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 44° 56' 06"N 44° 56' 05"N
Longitude 93° 04' 05"W 93° 03' 15"W
Elevation 701' 701'
Threshold Crossing Height -- 40 ft. AGL
Visual Glide Path Angle -- 4°
Visual Slope Indicator -- P4R
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 13/31

4004 ft. x 150 ft.
ASPH
Good
NONE
HIGH

97,000lbs
135,000lbs
228,000lbs
--
  Runway 13 Runway 31
True Heading 128°308°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 44° 56' 21"N 44° 55' 57"N
Longitude 93° 03' 54"W 93° 03' 10"W
Elevation 705' 701'
Threshold Crossing Height 40 ft. AGL 45 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes

Runway 14/32

6491 ft. x 150 ft.
ASPH
Good
GRVD
HIGH

83,000lbs
111,000lbs
197,000lbs
--
  Runway 14 Runway 32
True Heading 146°326°
Traffic Pattern
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 44° 56' 28"N 44° 55' 35"N
Longitude 93° 04' 04"W 93° 03' 14"W
Elevation 704' 705'
Threshold Crossing Height 50 ft. AGL 40 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4R P4L
Approach Lights MALSR
Centerline Lights
Runway End Identifier Lights No Yes
A110-1BIRD ROOSTING & FEEDING AREAS ALONG RIVER BANKS.
A110-10VOLUNTARY NOISE ABATEMENT PROCS IN EFCT. SEE ARPT WEBSITE FOR MORE INFO.
A110-11TWY A CLSD BTN A3 AND A4 EXC FOR WINGSPAN LESS THAN 101FT.
A110-12TWY B CLSD BTN MN JET RAMP AND TWY A (SOUTHERN CORNER) EXC FOR WINGSPAN LESS THAN 72FT DUE TO FLOOD WALL OBSTACLE.
A110-13RY 14 IS CALM WIND RY WHEN ATCT CLSD.
A110-14EXPECT HELICOPTER OPERATIONS ON TWY 'A' IN THE VICINITY OF THE CONTROL TWR, NORTH TO THE APPROACH END OF RY 14.
A110-3WHEN USING RYS 27 OR 31 HAZARDOUS RIVER TFC MAY EXIST.
A110-5DEER, BIRDS & WILDLIFE ON & INVOF ARPT.
A110-7SE ARR & DEP AVOID TFC PATTERN OPERATIONS AT SOUTH ST. PAUL ARPT 164 DEG 5 NM AT & BLO 1720 MSL.
A110-8PPR ACFT OVER 100,000 LBS, CTC AMGR.
A110-9COMPLEX AIRPORT GEOMETRY. VERIFY CORRECT COMPASS HEADING PRIOR TO DEPARTURE.
ST PAUL DOWNTOWN HOLMAN FLD (ICAO: KSTP, IATA: STP) is a public airport located in ST PAUL, MN.
