| Domestic |
|
10/20/240435Z
|
!MKL 10/191 SNH OBST TOWER LGT (ASR 1205872) 350700.30N0881517.90W (3.7NM SSW SNH) 779.9FT (274.9FT AGL) U/S 2410200435-2501180400
|
|
10/13/241451Z
|
!MKL 10/112 SNH OBST TOWER LGT (ASN 2018-ASO-793-OE) 350344N0881519W (6.8NM SSW SNH) 661FT (259FT AGL) U/S 2410131451-2504132359
|
|
5/27/240426Z
|
!MKL 05/407 SNH OBST TOWER LGT (ASN 2018-ASO-794-OE) 350401N0881531W (6.6NM SSW SNH) 649FT (259FT AGL) U/S 2405270426-2411292359
|
|
12/22/201723Z
|
!MKL 12/169 SNH TWY B RELOCATED 1500FT EAST OF RWY 01/19 2012221723-PERM
|
|
12/22/201317Z
|
!MKL 12/163 SNH TWY C RELOCATED 1500FT EAST OF RWY 01/19 2012221317-PERM
|
| FDC |
|
8/7/241921Z
|
!FDC 4/4789 SNH IAP SAVANNAH-HARDIN COUNTY,
SAVANNAH, TN.
RNAV (GPS) RWY 19, ORIG-A...
CHART PROFILE NOTE: VGSI AND RNAV GLIDEPATH NOT COINCIDENT (VGSI
ANGLE 3.00/TCH 31)..
NOTE: CIRCLING RWY 1 NA AT NIGHT..
THIS IS RNAV (GPS) RWY 19, ORIG-B. 2408071921-PERM
|
|
6/29/232008Z
|
!FDC 3/9837 SNH IAP SAVANNAH-HARDIN COUNTY, SAVANNAH, TN.
RNAV (GPS) RWY 19, ORIG-A...
CIRCLING CAT B MDA 1120/HAA 647.
PROFILE NOTE: VGSI AND RNAV GLIDEPATH NOT COINCIDENT (VGSI ANGLE (3.00)/TCH (31)).
NOTE: CIRCLING RWY 1 NA AT NIGHT.
2306292008-2506292008EST
|
|
6/29/232008Z
|
!FDC 3/9835 SNH IAP SAVANNAH-HARDIN COUNTY, SAVANNAH, TN.
RNAV (GPS) RWY 1, ORIG-A...
LPV DA NA; LNAV/VNAV DA NA; CIRCLING CAT B MDA 1120/HAA 647.
NOTE: STRAIGHT-IN RWY 1 NA AT NIGHT, CIRCLING RWY 1 NA AT NIGHT.
2306292008-2506292008EST
|
|
6/26/231651Z
|
!FDC 3/6689 SNH PART 1 OF 2 ODP SAVANNAH-HARDIN COUNTY,
SAVANNAH, TN.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 3...
TAKE-OFF MINIMUMS RWY 01, 300-1 OR STANDARD WITH A MINIMUM CLIMB OF
415 FEET PER NM TO 700.
TAKEOFF OBSTACLE NOTES: NOTE: RWY 01, LIGHT POLES 19 FT FROM DER,
88 FT RIGHT OF CENTERLINE, 2 FT AGL/455 FT MSL. TREE, POLE
BEGINNING 30 FT FROM DER, 493 FT LEFT OF CENTERLINE, UP TO 534 FT
MSL. TREE 34 FT FROM DER, 412 FT RIGHT OF CENTERLINE, 489 FT MSL.
TREES BEGINNING 99 FT FROM DER, 188 FT RIGHT OF CENTERLINE, UP TO
500 FT MSL. TREES BEGINNING 153 FT FROM DER, 420 FT LEFT OF
CENTERLINE, UP TO 541 FT MSL. TREES BEGINNING 545 FT FROM DER, 183
FT LEFT OF CENTERLINE, UP TO 542 FT MSL. TREES BEGINNING 1176 FT
FROM DER, 679 FT RIGHT OF CENTERLINE, UP TO 518 FT MSL. TREES
BEGINNING 2588 FT FROM DER, 501 FT RIGHT OF CENTERLINE, UP TO 591
FT MSL. TREES BEGINNING 2843 FT FROM DER, 867 FT RIGHT OF
CENTERLINE, UP TO 596 FT MSL. TREE 2980 FT FROM DER, 1178 FT RIGHT
OF CENTERLINE, 607 FT MSL. TREES BEGINNING 3102 FT FROM DER, 92 FT
RIGHT OF CENTERLINE, UP TO 607 FT MSL. NOTE: RWY 19, RWY 19:
TERRAIN 7 FT FROM DER, 178 FT RIGHT OF CENTERLINE, 474 FT MSL.
FENCE, TERRAIN BEGINNING 36 FT FROM DER, 298 FT RIGHT OF
CENTERLINE, UP TO 7 FT AGL/483 FT MSL. POLE 247 FT FROM DER, 548 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2306261651-2506261651EST
END PART 1 OF 2
!FDC 3/6689 SNH PART 2 OF 2 ODP SAVANNAH-HARDIN COUNTY,
SAVANNAH, TN.
LEFT OF CENTERLINE, 39 FT AGL/503 FT MSL. TREE 345 FT FROM DER, 527
FT LEFT OF CENTERLINE, 533 FT MSL. TREES BEGINNING 391 FT FROM DER,
418 FT LEFT OF CENTERLINE, UP TO 543 FT MSL. TREE, POLE BEGINNING
637 FT FROM DER, 24 FT LEFT OF CENTERLINE, UP TO 546 FT MSL. TREE,
LIGHT POLES, VERTICALSTRUCTURE, POLE BEGINNING 687 FT FROM DER, 1
FT RIGHT OF CENTERLINE, UP TO 541 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2306261651-2506261651EST
END PART 2 OF 2
|
