iFlightPlanner



...
No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KSLN
SALINA RGNL
PublicPUB

3 miles SW of SALINA, KS
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
38° 47' 26"N 97° 39' 08"W
1288' MSL
2288' MSL
07E
JET A, 100LL
WICHITA (ICT)
WICHITA
KANSAS CITY (ZKC)
4/17/25-5/15/25
KSLN VFR
1:53 AM CDT
Light Thunderstorm and Rain in vicinity
Broken 12,000'
Broken 10,000'
10sm
70°F
64°F
29.78"Hg
200° 23kts
Gusts 36kts
AO2 PK WND 21036/0644 LTG DSNT ALQDS SLP068 P0005 T02110178
KSLN 030653Z AUTO 20023G36KT 10SM VCTS -RA BKN100 BKN120 21/18 A2978 RMK AO2 PK WND 21036/0644 LTG DSNT ALQDS SLP068 P0005 T02110178
+ Add Your Business

KSLN FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 119.3

ATIS

ATIS
 120.15

ASOS

ASOS
785-823-3402
 120.15

Ground

GND/P
 121.9

Tower

LCL/P
 119.3
LCL/S
 124.35

Other

NG OPS
 41.7

FAA A/FD Pages

Airport Diagrams

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KSLN
Tue, 6/3 12:20 AM CDT
Tue, 6/3 1:00 AM CDT - Wed, 6/4 1:00 AM CDT
VFR
1:00 AM CDT - 3:00 AM CDT
Light Showers and Rain
Broken 4,000'
Scattered 1,500'
6sm
190° 13kts
VFR
3:00 AM CDT - 7:00 AM CDT
Showers in vicinity
Broken 5,000'
Scattered 1,500'
6sm
190° 8kts
MVFR
7:00 AM CDT - 11:00 AM CDT
Showers in vicinity
Broken 2,500'
6sm
180° 8kts
MVFR
11:00 AM CDT - 3:00 PM CDT
Thunderstorm in vicinity
Broken 2,000'
Scattered 900'
6sm
340° 14kts
IFR
Temporary 11:00 AM CDT - 3:00 PM CDT
Overcast 2,000'
Broken 900'
N/A
Calm
MVFR
3:00 PM CDT - 1:00 AM CDT
Broken 2,000'
6sm
360° 14kts
KSLN 030520Z 0306/0406 19013KT 6SM -SHRA SCT015 BKN040
   FM030800 19008KT P6SM VCSH SCT015 BKN050
   FM031200 18008KT P6SM VCSH BKN025
   FM031600 34014KT P6SM VCTS SCT009 BKN020CB
   TEMPO 0316/0320 BKN009 OVC020CB
   FM032000 36014KT P6SM BKN020
KSLN
Domestic
5/15/251900Z !SLN 05/016 SLN TWY B BTN APCH END RWY 36 AND RWY 17/35 CLSD 2505151900-2506072200
5/7/252010Z !SLN 05/010 SLN RWY 30 PAPI U/S 2505072010-2506092000EST
5/7/252009Z !SLN 05/009 SLN RWY 12 PAPI U/S 2505072009-2506092300EST
5/7/251542Z !SLN 05/006 SLN TWY E BTN RWY 17/35 AND APCH END RWY 12 CLSD 2505071542-2506072200
5/7/251541Z !SLN 05/005 SLN RWY 18/36 CLSD 2505071541-2506072200
5/7/251540Z !SLN 05/004 SLN RWY 04/22 CLSD 2505071540-2506072200
5/7/251539Z !SLN 05/003 SLN RWY 12/30 CLSD 2505071539-2506072200
4/11/251640Z !SLN 04/025 SLN OBST TOWER LGT (ASR 1236445) 385231.40N0974602.00W (7.4NM NW SLN) 1597.8FT (259.8FT AGL) U/S 2504111640-2507110400
4/1/251559Z !SLN 04/001 SLN OBST TOWER LGT (ASR 1329300) 385256.80N0973852.90W (5.5NM N SLN) 1472FT (250FT AGL) U/S 2504011559-2506012359
3/27/251826Z !SLN 03/019 SLN OBST TOWER LGT (ASR 1032981) 384556.00N0973237.00W (5.3NM ESE SLN) 1610.9FT (262.5FT AGL) U/S 2503271826-2506272359
FDC
5/12/251907Z !FDC 5/9571 SLN IAP SALINA RGNL, SALINA, KS.
RNAV (GPS) RWY 12, ORIG-A...
LNAV HAT 432 ALL CATS.
2505121907-2705121907EST
Yes
ALL
SALINA ARPT AUTH
3237 ARNOLD AVENUE
SALINA, KS 67401
Phone: 785-827-3914
MR. PIETER MILLER
3237 ARNOLD AVENUE
SALINA, KS 67401
Phone: 785-827-3914
WICHITA FSS (ICT)
Toll Free: 1-800-WX-BRIEF
SLN
--
WHEN ATCT CLSD ACTVT MIRL RY 12/30; PAPI RYS 12 & 30; HIRL RY 17/35; MALS & PAPI RYS 17 & 35; MALSR RY 35 - CTAF.
N/A
Yes
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Major
Major
None
High Pressure
Air Ambulance
Cargo Handling
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 04/22

3648 ft. x 75 ft.
ASPH
Good
NONE

5 /F/C/Y/U
100,000lbs
135,000lbs
230,000lbs
--
  Runway 04 Runway 22
True Heading 49°229°
Traffic Pattern Left Left
Markings BSC BSC
Markings Condition FAIR FAIR
Latitude 38° 47' 10"N 38° 47' 34"N
Longitude 97° 39' 22"W 97° 38' 47"W
Elevation 1,271' 1,256'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 12/30

6510 ft. x 100 ft.
ASPH
Excellent
NONE
MED
23 /R/C/X/U
55,000lbs
68,000lbs
125,000lbs
--
  Runway 12 Runway 30
True Heading 132°312°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 38° 47' 37"N 38° 46' 54"N
Longitude 97° 40' 01"W 97° 39' 00"W
Elevation 1,258' 1,272'
Threshold Crossing Height 45 ft. AGL 45 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 17/35

12301 ft. x 150 ft.
ASPH CONC
Good
NONE
HIGH
75 /R/C/W/U
75,000lbs
200,000lbs
360,000lbs
600,000lbs
  Runway 17 Runway 35
True Heading 180°360°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 38° 48' 37"N 38° 46' 36"N
Longitude 97° 38' 45"W 97° 38' 45"W
Elevation 1,246' 1,271'
Threshold Crossing Height 52 ft. AGL 48 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4R
Approach Lights MALS MALSR
Centerline Lights
Runway End Identifier Lights

Runway 18/36

4301 ft. x 75 ft.
ASPH
Excellent
NONE

11 /F/C/Y/U
30,000lbs
--
--
--
  Runway 18 Runway 36
True Heading 180°360°
Traffic Pattern
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 38° 47' 38"N 38° 46' 55"N
Longitude 97° 39' 41"W 97° 39' 41"W
Elevation 1,254' 1,288'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway H1

57 ft. x 57 ft.
CONC
Good
NONE


--
--
--
--
  Runway H1 Runway
True Heading 85°265°
Traffic Pattern
Markings
Markings Condition
Latitude 38° 47' 19"N N/A
Longitude 97° 38' 35"W N/A
Elevation 1,260' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway H2

29 ft. x 28 ft.
ASPH
Good
NONE


--
--
--
--
  Runway H2 Runway
True Heading 85°265°
Traffic Pattern
Markings
Markings Condition
Latitude 38° 47' 51"N N/A
Longitude 97° 38' 38"W N/A
Elevation 1,260' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway H3

30 ft. x 30 ft.
CONC
Good
NONE


--
--
--
--
  Runway H3 Runway
True Heading 85°265°
Traffic Pattern
Markings
Markings Condition
Latitude 38° 47' 47"N N/A
Longitude 97° 39' 08"W N/A
Elevation 1,250' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway H4

57 ft. x 43 ft.
ASPH
Good
NONE


--
--
--
--
  Runway H4 Runway
True Heading 85°265°
Traffic Pattern
Markings
Markings Condition
Latitude 38° 47' 37"N N/A
Longitude 97° 39' 17"W N/A
Elevation 1,253' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway H5

57 ft. x 57 ft.
CONC
Good
NONE


--
--
--
--
  Runway H5 Runway
True Heading 85°265°
Traffic Pattern
Markings
Markings Condition
Latitude 38° 47' 47"N N/A
Longitude 97° 39' 26"W N/A
Elevation 1,250' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway H6

29 ft. x 29 ft.
CONC
Good
NONE


--
--
--
--
  Runway H6 Runway
True Heading 85°265°
Traffic Pattern
Markings
Markings Condition
Latitude 38° 47' 00"N N/A
Longitude 97° 39' 26"W N/A
Elevation 1,253' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-10SVC: FLUID- LPOX, HPOX, LPNIT, LOX (72HR NOTICE) DEICING SERVICE TYPE 1& TYPE 4 OIL 0-128-148 AVBL IN QUART CANS TRANS SVC AVBL AT FBO. LOGISTICAL SVC AVBL FOR DETS AND RON AT FBO (AVFLIGHT SALINA, 785-825-6739/CELL 785-819-2236.)
A110-11ARNG: RAMP SPACE AVBL TO ACCOMMODATE UP TO 80 FIGHTERS. SMOKY HILL ANG WEAPONS RANGE 16 NM TO THE SW. COORD RANGE TIME AT DSN 743-7600 EXT 148. MILITARY BILLETING AVAILABLE 888-577-8257. LOGISTIC EQPT AVBL FOR USE. ORDNANCE STORAGE FOR CLASS 1.3 THRU 1.4.
A110-12ARNG: TSNT ARMY ACFT CTC SALINA GUARD OPS ON 229.80 OR 34.10 SC RED. LIMITED UH-60 SVC AND MAINT AVBL.
A110-13100LL SELF SVC FUELING STN LOCATED SOUTH OF KANSAS ANG.
A110-14GND SUPPORT AND LOGISTICS EQUIP AVBL INCL TUGS, BOBTAILS, TOW BARS AND AIRSTAIRS.
A110-15RY 04/22 AND RY 18-36 UNAVBL FOR USE BY ACR WITH MORE THAN 9 PSGR SEATS.
A110-16H1 INGRESS/EGRESS 070 DEG THROUGH 040 DEG TO AVOID CTL TWR.
A110-17ALL HELIPADS DALGT USE ONLY.
A110-18H3, H4, H5, H6 USED EXTSVLY FOR TRNG.
A110-19H2, H3 LTD TO 6,000 LBS; H4, H5 LTD TO 25,000 LBS.
A110-2NO LINE OF SIGHT, ALL RYS DUE TO GRADIENT, TOPOGRAPHY & TREES.
A110-20NOISE ABATEMENT: HEAVY & MIL ACFT TPA AT 2,800 MSL OR ABOVE.
A110-21FOR CD IF UNA TO CTC ON FSS FREQ, CTC KANSAS CITY ARTCC AT 913-254-8508.
A110-22BTN 0001-0459L ACR OPNS INVOLVING ACFT WITH MORE THAN 9 PSGRS SEATS ARE NOT AUTH IN EXCESS OF 15 MINS BFR OR AFT SKED ARR OR DEP TIMES WO PRIOR COORD WITH AMGR TO CFM THAT ARFF SVCS ARE AVBL PRIOR TO LNDG OR TKOF. CALL AMGR 785-827-3914.
A110-5SEASONAL MOWING OPNS ADJ TO RYS & TWYS.
A110-6CALM WND RY 35.
A110-8ARNG: OPR 1300-2300Z++ TUE-FRI; OCNL SAT EXC HOL. LTD MAINT UH-60. ARNG, AR AND A CTC ARNG OPS PRIOR TO LDG OR CALL 785 827 3914 FOR LIASON.
A110-9SVC: JASU- 2(A/M32-95) 2(A/M32-60B) 1(A/M32-86D).
SALINA RGNL (ICAO: KSLN, IATA: SLN) is a public airport located in SALINA, KS.
