KSLI
LOS ALAMITOS AAF
PrivatePVT

1 miles SE of LOS ALAMITOS, CA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
33° 47' 24"N 118° 03' 05"W
36' MSL
1036' MSL
12E
JET A-1+, JP-8
HAWTHORNE (HHR)
LOS ANGELES
LOS ANGELES (ZLA)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

KSLI FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 123.85

ATIS

ATIS
 118.875

Ground

GND/P
 126.95

Tower

LCL/P
 123.85

Other

AR OPS
 139.05
OPS
ARNG AASF
 41.5
OPS
AFLD OPS ADVSY SVC
 126.2

FAA A/FD Pages

Airport Diagrams

Airport Minimums

Departure Procedures

Hotspot

  • No Documents

Standard Term. Arrival

Instrument Approach

Terminal Area Forecast

No TAF is available for this location.
KSLI
No NOTAM Available
Yes
FRI-SUN 1400-0000Z++
MON-THU 1400-0600Z++
CLSD ALL FEDERAL HOL. EXP CLOSURE OR RDCD SVC PER NOTAM. RSTD: PPR CTC AFLD OPS, RCMD UNITS ASK FOR CURRENT CPBLTY WHEN REQG PPR DSN 972-2571, C562-795-2571; NG.CA.CAARNG.MBX.KSLIOPERATIONS@ARMY.MIL FOR PPR REQ FORM.
US ARMY
AASF, CAARNG, 4612 DOOLITTLE AVE
LOS ALAMITOS, CA 90720
Phone: 562-795-2571
BASE OPS

LOS ALAMITOS, CA 90720
Phone: 562-795-1351
HAWTHORNE FSS (HHR)
Toll Free: 1-800-WX-BRIEF
SLI
Sunset to Sunrise
--
N/A
N/A
No
No
None
No
0
0
0
0
0
0
None
None
None
None
None

Runway 04L/22R

5901 ft. x 150 ft.

PEM
NONE
MED
36 /F/C/W/T
--
--
--
--
  Runway 04L Runway 22R
True Heading 55°235°
Traffic Pattern
Markings
Markings Condition
Latitude 33° 47' 07"N 33° 47' 41"N
Longitude 118° 03' 43"W 118° 02' 46"W
Elevation 20' 27'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights

Runway 04R/22L

7999 ft. x 200 ft.
ASPH
CONC
NONE
HIGH
36 /R/C/W/T
--
--
--
--
  Runway 04R Runway 22L
True Heading 55°235°
Traffic Pattern
Markings
Markings Condition
Latitude 33° 47' 02"N 33° 47' 47"N
Longitude 118° 03' 37"W 118° 02' 19"W
Elevation 21' 36'
Threshold Crossing Height -- 75 ft. AGL
Visual Glide Path Angle -- 3°
Visual Slope Indicator -- P4L
Approach Lights SALSF
Centerline Lights Yes Yes
Runway End Identifier Lights No Yes
A110-1RWY-LGTS: RWY 22L - SF.
A110-10MISC - WINDS ARE ACCURATE TO WITHIN PLUS OR MINUS 4 KNOTS.
A110-13MISC: TO EXCEED WT BRG CAP CTC AFLD OPS. SEE FLIP AP/1 RTE AND AREA RSTD AND SUPPLEMENT ARPT RMK.
A110-14ARNG AASF OPS- OPR 1530-2330Z++ MON-FRI; EXC HOL. DSN 972-2006, C562-795-2006. HTTP://WWW.CALGUARD.CA.GOV/AASF1.
A110-15RSTD: FOR SPECIAL AFTER HRS LNDG AND AFLD LIGHTING REQUESTS FOR ACFT WEIGHING UNDER 14,500 LBS, CALL AFLD OPS AT 562-795-2571.
A110-16SERVICE: TRAN ALERT - FUEL OPR MON-THU 1430-2330Z++, FRI 1430-0130Z++, CLSD WKENDS AND FEDERAL HOL. EXP CLOSURE OR RDCD SVC PER NOTAM. NO PRIORITY BASIS. EXP SVC DELAYS IF HVY ACFT ARE UTILIZING LAAAF. NO ACFT LAV SVC OR BELT LOAD, CTC AIRSERV AT KLGB 866-247-7378 OR 562-429-8062. LTD TRAN SVC. NO SHUTTLE SVC AVBL.
A110-17CLASSIFIED STOR FOR TSNT AIRCREW UNAVBL AT AFLD MGMT OPS; CTC BASE SECFOR DSN 972-2100, C562-795-2100.
A110-18AIRCREWS UTILIZING LAAAF MUST ADVS THEIR DEP TO LOCAL FSS TO INCL KSLIYXYX AS AN ADDRESSEE ON THE ORIG DD 1801 FLT PLAN AND ON ANY CHG, DELAY, DEP AND CNL MSG.
A110-19ALL TRAN AIRCREWS MUST RPT TO AFLD OPS. HIGH VIS EVENTS (VIP CODE 7 AND ABV) ARE RQRD TO NTFY AFLD OPS 30 MIN PRIOR TO ARR DUE TO POST HQ COORD.
A110-2RWY-17/35 CLSD (2500X150 ASP).
A110-20MISC: AFLD SIGNS NSTD. RWY 04R/22L THLD BARS NSTD. ALL RWY MARKINGS NSTD. TWY AND PRKG LINES NSTD AND NOT VIS IN DARKNESS OR INCLEMENT WX.
A110-21MISC: WILDLIFE HAZ EXISTS; RQRS INCRD VIGILANCE BY ALL AGENCIES AND SUPVRS AND CTN BY AIRCREWS. BASH/WASH COND ANNOUNCED ON ATIS. PILOTS SHOULD RPRT ALL LARGE BIRD AND MAMMAL SIGHTINGS TO TWR OR AFLD OPS.
A110-22FOR CD WHEN ATCT CLSD CTC SOCAL APCH AT 800-448-3724.
A110-23PAR REMOVED FROM SVC, PERMLY CLSD.
A110-24TWY B1 & TWY E LTD TO ACFT 30000 LBS OR LESS.
A110-25CAUTION: FALSE ATC INSTRNS HAVE BEEN RCVD IN THE AREA OF LOS ALAMITOS AIRFIELD; EXER EXTREME CTN ON ALL FREQS AND VFY INSTRNS.
A110-26ALL WHEELED ACFT WILL LAND TO THE RWYS AND GND TAXI TO PRKG ON ALL APCHS AND DEPS UNLESS REQD AND APVD OR DRCTD BY ATC. DSGND HOVERING AREAS ARE RWY 22R RUNUP AREA, TWY E, & TWY F.
A110-27CAUTION: AIRFIELD HAS HIGH POTENTIAL FOR FOD.
A110-28AIRFIELD FOD COND RANGES FROM MOD TO OCNL.
A110-29LAAAF AIRFIELD PROCEDURES GUIDE (APG) AND AIRFIELD OPERATIONS MANUAL (AOM) IS AVBL. IT CAN BE LCTD ON THE CALGUARD SHAREPOINT UNDER CAMP LOS ALAMITOS/JFTB SITES/LOS ALAMITOS ARMY AIRFIELD. CTC BASE OPS FOR A CURRENT COPY NG.CA.CAARNG.MBX.KSLIOPERATIONS@ARMY.MIL OR 562-795-2571.
A110-3JASU - 1(TMD150CIII) 1(AGPU).
A110-30PILOTS WILL SMT ALL DD FORM 1801 WITH A NAME IN BLOCK 19, PILOT IN COMMAND (PIC) IAW LAAAF APG, 2-2, B, 3 AND THE GENERAL PLANNER (GP), 4-3, ITEM 19. DD FORM 1801 WILL INCL A CTC NR SEPARATE FROM ANY FLT CREW FOR ANY SEARCH AND RESCUE (SAR) RELATED EMERGS.
A110-31GLARE OBSD FROM SOLAR FARM SITE ON AIRFIELD DRG MIDDAY HRS. PILOTS ARE ADVISED TO RPRT GLARE/GLINT TO ATC TWR UPON OBS.
A110-32ALL FIXED WING HIGH POWER MAINT RUN-UPS MUST BE CONDUCTED ON FAR WEST RAMP FACING TO THE EAST OR ON COMPASS ROSE FOR NOISE MITIGATION UFN. ACFT WILL CTC BASE OPS ON 126.2 PRIOR TO ACFT MOV.
A110-33LED LGTG ON AIRFIELD RWYS AND TWYS. LEDS MAY NOT BE COMPATIBLE WITH CERTAIN NGT VISION DEVICES.
A110-8NS ABTMT - PRO IN EFF. ALL DEP RQR BRIEFINGS.
LOS ALAMITOS AAF (ICAO: KSLI, IATA: SLI) is a private airport located in LOS ALAMITOS, CA.
