iFlightPlanner



...
No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KSLE
MCNARY FLD
PublicPUB

2 miles SE of SALEM, OR
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
44° 54' 34"N 123° 00' 09"W
213' MSL
1213' MSL
17E
JET A, 100LL
MC MINNVILLE (MMV)
SEATTLE
SEATTLE (ZSE)
10/31/24-11/28/24
KSLE LIFR
3:56 AM PST
Fog
Obscured
0.5sm
44°F
41°F
29.98"Hg
Calm
AO2 SLP154 60000 T00670050 10078 20050 56007
KSLE 091156Z AUTO 00000KT 1/2SM R31/2200V4000FT FG VV002 07/05 A2998 RMK AO2 SLP154 60000 T00670050 10078 20050 56007
Add Your Business

KSLE FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 119.1

ATIS

ATIS
 124.55

ASOS

ASOS
503-371-1062
 124.55

Emergency

EMERG
 121.5

Ground

GND/P
 121.9

Tower

LCL/P
 119.1

Other

NG OPS
FM
 40.9
NG OPS
 142.8

FAA A/FD Pages

Airport Diagrams

Airport Minimums

Departure Procedures

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KSLE
Sat, 11/9 3:24 AM PST
Sat, 11/9 4:00 AM PST - Sun, 11/10 4:00 AM PST
IFR
4:00 AM PST - 10:00 AM PST
Mist
Broken 15,000'
Scattered 700'
2sm
VRB° 2kts
VFR
10:00 AM PST - 5:00 PM PST
Broken 10,000'
6sm
180° 5kts
VFR
5:00 PM PST - 1:00 AM PST
Light Rain
Overcast 4,500'
6sm
190° 4kts
MVFR
1:00 AM PST - 4:00 AM PST
Showers in vicinity
Overcast 3,500'
Broken 2,500'
6sm
160° 4kts
KSLE 091124Z 0912/1012 VRB02KT 2SM BR SCT007 BKN150
   FM091800 18005KT P6SM BKN100
   FM100100 19004KT P6SM -RA OVC045
   FM100900 16004KT P6SM VCSH BKN025 OVC035
KSLE
Domestic
11/1/242339Z !SLE 11/001 SLE AD AP WDI FOR RWY 31 LGT U/S 2411012339-2411080001EST
10/3/240350Z !SLE 10/001 SLE OBST TOWER LGT (ASR 1040824) 444660.00N1225949.00W (7.7NM S SLE) 1169.0FT (109.9FT AGL) U/S 2410030350-2412310400
FDC
9/20/241435Z !FDC 4/8652 SLE SID MCNARY FLD, SALEM, OR.
SALEM FOUR DEPARTURE...
LOST COMMUNICATIONS PROCEDURE: TAKEOFF RUNWAY 31 AND 34 NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
UBG VOR/DME OUT OF SERVICE. 2409201435-2412041435EST
6/15/231218Z !FDC 3/1161 SLE ODP MCNARY FLD, SALEM, OR.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 10...
TAKE-OFF MINIMUMS: RWY 13, STANDARD WITH MINIMUM CLIMB OF 330 FT PER NM TO 1100, OR 1500 - 2 1/2 FOR VCOA.
TAKE-OFF MINIMUMS: RWY 16, 400 - 2 1/2 WITH MINIMUM CLIMB OF 260 FT PER NM TO 1100, OR 1500 - 2 1/2 FOR VCOA.
ALL OTHER DATA REMAINS AS PUBLISHED. 2306151218-2506151218EST
3/29/231457Z !FDC 3/3698 SLE SID MCNARY FLD, SALEM, OR.
SALEM FOUR DEPARTURE...
TAKE-OFF MINIMUMS: RWY 13, STANDARD WITH MINIMUM CLIMB OF 330 FT PER NM TO 1100, OR 1500 - 2 1/2 FOR VCOA.
TAKE-OFF MINIMUMS: RWY 16, 400 - 2 1/2 WITH MINIMUM CLIMB OF 260 FT PER NM TO 1100, OR 1500 - 2 1/2 FOR VCOA.
ALL OTHER DATA REMAINS AS PUBLISHED. 2303291457-2503291457EST
3/20/231652Z !FDC 3/9786 SLE IAP MCNARY FLD, SALEM, OR.
RNAV (GPS) RWY 31, AMDT 3D...
LNAV VISIBILITY CAT A RVR 2400, CAT B RVR 4000.
WHEN LOCAL ALTIMETER SETTING NOT RECEIVED, USE MCMINNVILLE ALTIMETER SETTING AND INCREASE LPV DA TO 459 FEET; INCREASE LNAV/VNAV DA TO 936 FEET AND ALL VISIBILITIES 1/8 SM. INCREASE ALL MDAS 60 FEET AND LNAV VISIBILITY CAT C/D 1/8 SM, AND CIRCLING VISIBILITY CAT A AND CAT C 1/4 SM.
FOR INOPERATIVE ALS WHEN USING MCMINNVILLE ALTIMETER SETTING, INCREASE LNAV/VNAV VISIBILITY ALL CATS TO 2.
ALTERNATE MINIMUMS: CAT A/B: 900-2; CAT C: 900-2 1/2; CAT D: 1100-3.
2303201652-2503201652EST
Yes
MON-FRI 0700-1900
SAT-SUN 0700-1700
CITY OF SALEM
555 LIBERTY ST SE RM 220
SALEM, OR 97301
Phone: (503) 588-6255
JOHN PASKELL
2990 25TH ST SE
SALEM, OR 97302
Phone: (503) 589-2057
MC MINNVILLE FSS (MMV)
Toll Free: 1-800-WX-BRIEF
SLE
--
WHEN ATCT CLSD ACTVT MALSR RWY 31; ODALS RWY 13; REILS RWY 13, 16/34; HIRL RWY 13/31; MIRL RWY 16/34 - CTAF. REILS RWY 16 OTS INDEFLY: PAPI RWY 16 & 34 OTS INDEFLY; BCN OTS INDEFLY.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
High Pressure
High Pressure
Air Freight
Avionics
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 13/31

5811 ft. x 150 ft.
ASPH
Good
GRVD
HIGH
41 /F/C/X/T
105,000lbs
147,000lbs
--
--
  Runway 13 Runway 31
True Heading 150°330°
Traffic Pattern Left Left
Markings NPI PIR
Markings Condition GOOD GOOD
Latitude 44° 55' 01"N 44° 54' 11"N
Longitude 123° 00' 26"W 122° 59' 46"W
Elevation 194' 213'
Threshold Crossing Height 50 ft. AGL --
Visual Glide Path Angle 3° --
Visual Slope Indicator V4L --
Approach Lights ODALS MALSR
Centerline Lights
Runway End Identifier Lights Yes

Runway 16/34

5146 ft. x 100 ft.
ASPH
Good
GRVD
MED
15 /F/D/X/T
40,000lbs
52,000lbs
--
--
  Runway 16 Runway 34
True Heading 181°1°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 44° 54' 58"N 44° 54' 07"N
Longitude 123° 00' 12"W 123° 00' 13"W
Elevation 196' 211'
Threshold Crossing Height 38 ft. AGL 42 ft. AGL
Visual Glide Path Angle 3° 4°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes

Runway H1

37 ft. x 37 ft.
CONC
Excellent
NONE


--
--
--
--
  Runway H1 Runway
True Heading 65°245°
Traffic Pattern
Markings BSC
Markings Condition GOOD
Latitude 44° 54' 27"N N/A
Longitude 122° 59' 45"W N/A
Elevation 213' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-10ARNG-OPR 1500-0030Z++ MON-FRI EXCP HOL. NO TSNT ALERT SVC. NO PRK. ROTARY WING NOISE ABATEMENT PROC IN EFCT. TSNT ROTARY WING MUST USE SANTIAM ARR/DEP.
A110-11ARNG-F/W PASSENGER DROP-OFF AND PICKUP POINT FOR LGT ACFT AT VIP PAD ON S END OF MIL RAMP. PPR FOR ALL TSNT ACFT (DSN 355-1401, C971-355-1401). DUR NML DUTY HR, CTC GUARD OPS, 40.90, 142.8, 248.5 10 MIN OUT. KSLE OSA OPS DSN 355-1409, C971-355-1409.
A110-12FOR CD IF UNA TO CTC ON FSS FREQ, CTC SEATTLE ARTCC AT 253-351-3694.
A110-13ACFT PRKG ON S G/A RAMP LTD TO ACFT UNDER 12,500 LBS.
A110-14AIRFIELD CONDS NOT MNTD BTN 1600-0800Z & ALL TIMES SAT & SUN.
A110-15ARPT CLSD AFT HEAVY SNWFL.
A110-3BIRD HAZARD: HVY CONCENTRATION WATERFOWL ADJ TO APT & APCHS TO ALL RYS. FLOCKS OF GEESE CONCENTRATED TRANSITING CLASS D AIRSPACE AT TPA OCT-MAY.
A110-4TWY 'A' FM TWY 'L' TO 'L9' NOT VISIBLE FM ATCT.
A110-5SELF FUELING, 100LL ONLY, AVBL 24 HRS A DAY. JET A AVBL AFT NML BUS HRS WITH ADVND NOTICE AT 503-508-4178 OR 503-364-4158.
A110-7PPR RQRD FOR PRKG ACFT ON ACR RAMP. CALL AMGR 503-588-6314.
A110-8NS ABTMT PROCS IN EFCT. AVD OVR FLT OF SRNG RESL AREAS WHEN POSS.
A110-9RSG TRRN & TREES W & S OF ARPT, INCLG EXTD CNTRLN OF RWY 34. TREES ON EXTD CNTRLN OF RWY 16. NGT OPS NOT RCMD BOTH RWYS.
MCNARY FLD (ICAO: KSLE, IATA: SLE) is a public airport located in SALEM, OR.
