No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KSJC
NORMAN Y MINETA SAN JOSE INTL
PublicPUB

2 miles NW of SAN JOSE, CA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
37° 21' 47"N 121° 55' 43"W
62' MSL
1062' MSL
13E
JET A, 100LL
OAKLAND (OAK)
SAN FRANCISCO
OAKLAND (ZOA)
4/17/25-5/15/25
KSJC VFR
11:53 PM PDT
Few 4,000'
10sm
58°F
52°F
29.98"Hg
360° 3kts
AO2 SLP152 T01440111
KSJC 030653Z 36003KT 10SM FEW040 14/11 A2998 RMK AO2 SLP152 T01440111
+ Add Your Business

KSJC FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Terminal Area Forecast

KSJC
Mon, 6/2 10:20 PM PDT
Mon, 6/2 11:00 PM PDT - Tue, 6/3 11:00 PM PDT
VFR
11:00 PM PDT - 8:00 AM PDT
Few 1,000'
6sm
310° 5kts
IFR
Temporary 4:00 AM PDT - 8:00 AM PDT
Broken 900'
N/A
Calm
MVFR
8:00 AM PDT - 11:00 AM PDT
Broken 1,000'
6sm
170° 4kts
VFR
11:00 AM PDT - 2:00 PM PDT
Sky Clear
6sm
VRB° 4kts
VFR
2:00 PM PDT - 8:00 PM PDT
Sky Clear
6sm
300° 12kts
VFR
8:00 PM PDT - 11:00 PM PDT
Sky Clear
6sm
310° 8kts
KSJC 030520Z 0306/0406 31005KT P6SM FEW010
   TEMPO 0311/0315 BKN009
   FM031500 17004KT P6SM BKN010
   FM031800 VRB04KT P6SM SKC
   FM032100 30012KT P6SM SKC
   FM040300 31008KT P6SM SKC
KSJC
Domestic
5/22/251500Z !SJC 05/071 SJC AIRSPACE UAS WI AN AREA DEFINED AS 0.2NM RADIUS OF
374139N1214250W (5.1NM ENE LVK) SFC-200FT AGL 2505221500-2505222300
5/21/251300Z !SJC 05/079 SJC RWY 12R/30L CLSD TO TGL DLY 1300-2100 2505211300-2506062100
5/21/251300Z !SJC 05/078 SJC RWY 12L/30R CLSD TO TGL DLY 1300-2100 2505211300-2506062100
5/19/251415Z !SJC 05/068 SJC TWY V BTN TWY V5 AND ATLANTIC AVIATION NORTH RAMP CLSD 2505191415-2508172359
5/19/250621Z !SJC 05/066 SJC TWY W TWY DIRECTION SIGN FOR TWY J LGT U/S 2505190621-2510310800
5/15/250408Z !SJC 05/048 SJC OBST TOWER LGT (ASR 1044718) 372957.00N1215220.00W (8.6NM NNE SJC) 3048.9FT (442.9FT AGL) U/S 2505150408-2505300308
5/9/251908Z !SJC 05/024 SJC OBST CRANE (ASN 2024-AWP-12963-OE) 372411N1215811W (3.1NM NW SJC) 435FT (420FT AGL) FLAGGED AND LGTD 2505091908-2505230100
5/2/252133Z !SJC 05/008 SJC OBST TOWER LGT (ASR 1019291) 372917.00N1215203.00W (8.0NM NNE SJC) 3044.0FT (605.0FT AGL) U/S 2505022133-2506022359
3/27/251800Z !SJC 03/093 SJC TWY W1 BTN TWY D AND TWY V5 CLSD 2503271800-2510310800
3/27/251800Z !SJC 03/092 SJC TWY G BTN TWY W AND TWY V CLSD 2503271800-2510310800
12/6/240000Z !SJC 12/012 SJC AIRSPACE UAS WI AN AREA DEFINED AS
374205.20N1214249.30W (5.1NM ENE LVK) TO 374201.40N1214244.30W
(5.2NM ENE LVK) TO 374204.60N1214215.30W (5.5NM ENE LVK) TO
374215.90N1214201.10W (5.8NM ENE LVK) TO 374220.10N1214151.90W
(5.9NM ENE LVK) TO 374209.90N1214149.30W (5.9NM ENE LVK) TO
374158.10N1214201.50W (5.7NM ENE LVK) TO 374148.70N1214304.10W
(4.9NM ENE LVK) TO 374158.50N1214305.10W (4.9NM ENE LVK) TO POINT OF
ORIGIN SFC-400FT AGL DLY 0000-2359 2412060000-2512052359
12/6/240000Z !SJC 12/011 SJC AIRSPACE UAS WI AN AREA DEFINED AS
374205.20N1214249.30W (5.1NM ENE LVK) TO 374201.40N1214244.30W
(5.2NM ENE LVK) TO 374204.60N1214215.30W (5.5NM ENE LVK) TO
374215.90N1214201.10W (5.8NM ENE LVK) TO 374220.10N1214151.90W
(5.9NM ENE LVK) TO 374209.90N1214149.30W (5.9NM ENE LVK) TO
374158.10N1214201.50W (5.7NM ENE LVK) TO 374148.70N1214304.10W
(4.9NM ENE LVK) TO 374158.50N1214305.10W (4.9NM ENE LVK) TO POINT OF
ORIGIN SFC-400FT AGL DLY 0000-2359 2412060000-2512052359
10/31/240000Z !SJC 10/068 SJC AIRSPACE UAS WI AN AREA DEFINED AS 371830N1220006W
(4.8NM SW SJC) TO 371830N1215600W (3.3NM S SJC) TO 371800N1215600W
(3.8NM S SJC) TO 371800N1215500W (3.8NM SSE SJC) TO 371700N1215500W
(4.8NM SSE SJC) TO 371700N1215254W (4.2NM SSW RHV) TO
371541N1215330W (5.5NM SSW RHV) TO 371437N1215500W (7.1NM SSW RHV)
TO 371421N1215600W (7.4NM SSE SJC) TO 371419N1215630W (7.5NM S SJC)
TO 371430N1215800W (7.5NM S SJC) TO 371500N1215900W (7.3NM S SJC) TO
371522N1215930W (7.1NM SSW SJC) TO 371700N1220022W (6.0NM SSW SJC)
TO 371730N1220024W (5.7NM SSW SJC) TO 371800N1220018W (5.3NM SSW
SJC) TO POINT OF ORIGIN SFC-400FT AGL DLY 0000-2359
2410310000-2510012359
6/5/231300Z !SJC 05/136 SJC OBST CRANE (ASN 2022-AWP-19767-OE) 371757N1215551W (3.83NM S OF SJC) 520FT (350FT AGL) FLAGGED AND LGTD 2306051300-2508112359
FDC
5/3/251300Z !FDC 5/4759 SJC IAP NORMAN Y MINETA SAN JOSE INTL, SAN JOSE, CA.
RNAV (GPS) Y RWY 12R, AMDT 3A...
LNAV MDA 740/HAT 694 ALL CATS, VIS CATS C/D 1 1/2. SIDESTEP 12L MDA 740/HAT 696 ALL CATS. VDP 1.96NM TO RW12R. TEMPORARY CRANE 435 MSL 3.1NM NW OF SJC AIRPORT (2024-AWP-12963-OE), TEMPORARY CRANE 298 MSL 2.4NM NW OF RWY 12R (2025-AWP-2698-OE).
2505031300-2506232216EST
5/3/251300Z !FDC 5/4756 SJC IAP NORMAN Y MINETA SAN JOSE INTL, SAN JOSE, CA.
RNAV (GPS) Y RWY 12L, AMDT 3A...
LNAV MDA 740/HAT 696 ALL CATS, VIS CATS C/D 1 1/2. VDP AT 1.97NM TO RW12L. TEMPORARY CRANE 435 MSL 3.1NM NW OF SJC AIRPORT (2024-AWP-12963-OE), TEMPORARY CRANE 298 MSL 2.4NM NW OF RWY 12L (2025-AWP-2698-OE).
2505031300-2506232216EST
5/3/251300Z !FDC 5/4755 SJC IAP NORMAN Y MINETA SAN JOSE INTL, SAN JOSE, CA.
ILS OR LOC RWY 12R, AMDT 8A...
S-LOC 12R MDA 740/HAT 694 ALL CATS, VIS CATS C/D 1 1/2. SIDESTEP 12L MDA 740/HAT 696 ALL CATS. DISREGARD STEPDOWN FIX JUJGE. FOR INOPERATIVE ALS, INCREASE S-LOC 12R CATS C/D VISIBILITY TO 1 7/8 SM. TEMPORARY CRANE 435 MSL 3.1NM NW OF SJC AIRPORT (2024-AWP-12963-OE), TEMPORARY CRANE 298 MSL 2.4NM NW OF RWY 12R (2025-AWP-2698-OE).
2505031300-2506232216EST
5/3/251300Z !FDC 5/4754 SJC IAP NORMAN Y MINETA SAN JOSE INTL, SAN JOSE, CA.
RNAV (GPS) Y RWY 30R, AMDT 4B...
CIRCLING CAT C/D MDA 800/HAA 738, VIS CAT C 2 1/4, CAT D 2 1/2. TEMPORARY CRANE 435 MSL 3.1NM NW OF SJC AIRPORT (2024-AWP-12963-OE).
2505031300-2506232216EST
5/3/251300Z !FDC 5/4753 SJC ODP NORMAN Y MINETA SAN JOSE INTL, SAN JOSE, CA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 6C...
RWYS 30L/R, 400-2 3/4 OR STANDARD WITH A MINIMUM CLIMB OF 238FT PER NM TO 600. TEMPORARY CRANE 435 MSL 3.1NM NW OF SJC AIRPORT (2024-AWP-12963-OE). ALL OTHER DATA REMAINS AS PUBLISHED. 2505031300-2506232216EST
4/8/251448Z !FDC 5/3515 SJC IAP NORMAN Y MINETA SAN JOSE INTL, SAN JOSE, CA.
RNAV (RNP) Z RWY 30R, AMDT 3...
RNP 0.20 DA 483/HAT 428 ALL CATS, VIS ALL CATS 1 1/4. TEMPORARY CRANES UP TO 322 MSL BEGINNING 4049FT S OF RWY 30R (2023-AWP-13471 THRU 13514-OE).
2504081448-2508161448EST
4/8/251448Z !FDC 5/3514 SJC IAP NORMAN Y MINETA SAN JOSE INTL, SAN JOSE, CA.
RNAV (RNP) Z RWY 30L, AMDT 4...
RNP 0.10 DA 476/HAT 419 ALL CATS, VIS ALL CATS RVR 4000. RNP 0.20 DA 538/HAT 481 ALL CATS, VIS ALL CATS RVR 5000. CHANGE NOTE TO READ: FOR INOP ALS, INCREASE RNP 0.10 ALL CATS VISIBILITY TO RVR 6000 AND INCREASE RNP 0.20 ALL CATS VISIBILITY AND RNP 0.30 ALL CATS VISIBILITY TO 1 3/8 SM. TEMPORARY CRANES UP TO 322 MSL BEGINNING 3584FT S OF RWY 30L (2023-AWP-13471 THRU 13514-OE).
2504081448-2508161448EST
Yes
ALL
CITY OF SAN JOSE
200 E. SANTA CLARA STREET
SAN JOSE, CA 95113
Phone: 408-277-5100
MUKESH (MOOKIE) PATEL
1701 AIRPORT BLVD., SUITE B-1130
SAN JOSE, CA 95110-1206
Phone: (408) 277-5100
OAKLAND FSS (OAK)
Toll Free: 1-800-WX-BRIEF
SJC
--
ACTVT MALSR RWY 12R, MALSR RWY 30L, HIRL RWY 12L/30R, HIRL RWY 12R/30L - FREQ 124.0 WHEN TWR CLSD.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
Landing Rights Airport
NOT an Airport of Entry
Major
Major
High & Low Pressure
High & Low Pressure
Air Freight
Avionics
Cargo Handling
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 12L/30R

11000 ft. x 150 ft.
CONC
Good
GRVD
HIGH

120,000lbs
250,000lbs
550,000lbs
1,116,000lbs
  Runway 12L Runway 30R
True Heading 139°319°
Traffic Pattern Left Right
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 37° 22' 30"N 37° 21' 08"N
Longitude 121° 56' 25"W 121° 54' 55"W
Elevation 38' 61'
Threshold Crossing Height 70 ft. AGL 69 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4R P4L
Approach Lights
Centerline Lights Yes Yes
Runway End Identifier Lights Yes No

Runway 12R/30L

11000 ft. x 150 ft.
CONC
Good
GRVD
HIGH

120,000lbs
250,000lbs
550,000lbs
1,120,000lbs
  Runway 12R Runway 30L
True Heading 139°319°
Traffic Pattern Right Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 37° 22' 25"N 37° 21' 04"N
Longitude 121° 56' 31"W 121° 55' 01"W
Elevation 38' 62'
Threshold Crossing Height 75 ft. AGL 70 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4R P4L
Approach Lights MALSR MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights No No
A110-23TWY Y WILL BE PERIODICALLY RSTRD TO ACFT WITH A WINGSPAN OF LESS THAN 171 FT (MD-11 OR SMALLER) DRG B-787 AND B-747 OPNS ON RWY 12L/30R.
A110-25TWY Z WILL BE PERIODICALLY RSTRD TO ACFT WITH A WINGSPAN OF LESS THAN 118 FT (B-737-900 OR SMALLER) DRG B-787 AND B-747 OPNS. TWY Z BTN 200 FT NW OF TWY H AND 200 FT NW OF TWY K LTD TO ACFT WITH WINGSPAN OF LESS THAN 135 FT (B-757-300 OR SMALLER).
A110-3BIRDS FREQUENTLY ON OR IN VICINITY OF AIRPORT.
A110-31TWY V LTD TO ACFT WITH WINGSPAN OF LESS THAN 118 FT (B-737-900 OR SMALLER).
A110-34UNSCHEDULED OPNS BY GROUP 5 ACFT (B747) AND LARGER NOT AUTH EXCEPT WITH PRIOR ARPT APPROVAL CTC AMGR (408) 392-3500.
A110-35NOISE ABATEMENT PROCEDURE: RY 30L/12R IS PREFERRED ARRIVAL RY FOR JET ACFT AND RY 12L/30R IS THE PREFERRED DEP RY FOR JET ACFT. ALL JET ACFT TKOFS ARE TO BE INITIATED FM EOR UNLESS DIRECTED OTHERWISE BY ATCT.
A110-38CURFEW HRS 2300-0700 FAR 36 STAGE II, 2330-0630 FAR 36 STAGE III ACFT LISTED ON THE SCHEDULE OF AUTHORIZED AIRCRAFT ISSUED BY THE DIRECTOR OF AVIATION. DELAYED SCHEDULED FLIGHTS, AND ALTERNATE/EMERGENCY OPERATIONS MAY BE EXEMPT FROM CURFEW HOUR RESTRICTIONS.
A110-39PRIOR AIRPORT NOTIFICATION IS REQUIRED FOR ALL LATE/EARLY ARRIVALS. CONTACT MANAGER ON DUTY AT (408) 392-3500.
A110-40FIRST 400 FT RY 30R & RY 30L CLSD FOR TKOF DC10, MD11, L1011.
A110-41ALL TURBINE ENGINE RUN-UPS REQUIRE PRIOR AIRPORT APPROVAL, CONTACT MGR ON DUTY (408) 392-3500.
A110-43TWY D BETWEEN TWY W AND TWY V LIMITED TO ACFT WITH A WINGSPAN OF LESS THAN 118 FT (B-737-900 OR SMALLER).
A110-44TWY W BETWEEN TWY J AND TWY L CAN SUPPORT GROUP IV ACFT.
A110-46HIGH INTENSITY LIGHT ACTIVITY: HIGH INTENSITY LIGHTS (LASERS AND LARGE MEDIA SCREENS) MAY BE VISIBLE TO ARR AND DEP ACFT TO SAN JOSE INTERNATIONAL AIRPORT DURING EVENTS AT THE LEVI STADIUM COMPLEX (37-24-15N/121-58-14W, SJC VORTAC R-303/2.1 DME). FLIGHT CREWS SHOULD USE CAUTION WHEN OPERATING IN THIS AREA DURING STADIUM EVENTS. COCKPIT ILLUMINATION AND GLARE EFFECT REDUCING VIS MAY BE INTENSIFIED DURING ARR AND DEP OPS ESPECIALLY AT NIGHT.
A110-47RRP RQRD FM FBO FOR TSNT HEL OPS.
A110-48FOR CD WHEN ATCT IS CLSD CTC NORCAL APCH AT 916-361-3748.
NORMAN Y MINETA SAN JOSE INTL (ICAO: KSJC, IATA: SJC) is a public airport located in SAN JOSE, CA.
