KSET
ST CHARLES COUNTY RGNL/SMARTT FLD
PublicPUB

9 miles NE of ST CHARLES, MO
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
38° 55' 47"N 90° 25' 48"W
437' MSL
1437' MSL
01E
100LL
SAINT LOUIS (STL)
ST LOUIS
KANSAS CITY (ZKC)
4/17/25-5/15/25
KSET VFR
1:54 AM CDT
Clear
10sm
61°F
56°F
30.16"Hg
060° 3kts
AO2 SLP207 T01610133
METAR KSET 140654Z AUTO 06003KT 10SM CLR 16/13 A3016 RMK AO2 SLP207 T01610133
+ Add Your Business

KSET FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.7 122.7

ASOS

ASOS
636-250-4590
 118.075

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KSTL (11nm)
Tue, 10/14 12:20 AM CDT
Tue, 10/14 1:00 AM CDT - Wed, 10/15 7:00 AM CDT
VFR
1:00 AM CDT - 7:00 AM CDT
Broken 12,000'
6sm
110° 4kts
TAF KSTL 140520Z 1406/1512 11004KT P6SM BKN120
KSET
EffectiveExpiresCategoryNOTAM
Domestic
10/3/25
0021Z
12/3/25
2359Z
!SET 10/001 SET OBST TOWER LGT (ASR UNKNOWN) 385340.83N0903005.26W (4NM SW SET) UNKNOWN (237FT AGL) U/S 2510030021-2512032359
9/29/25
2233Z
3/31/26
2300Z
!SET 09/018 SET OBST TOWER LGT (ASR 1252525) 390201.60N0901527.30W (10.2NM NE SET) 865.5FT (259.8FT AGL) U/S 2509292233-2603312300
9/19/25
1506Z
11/21/25
2359Z
!SET 09/012 SET OBST TOWER LGT (ASR 1009094) 390615.00N0901555.00W (13.0NM NE SET) 991.1FT (365.2FT AGL) U/S 2509191506-2511212359
9/18/25
1919Z
12/18/25
2359Z
!SET 09/011 SET OBST TOWER LGT (ASR 1291806) 391454.40N0903224.50W (19.8NM NNW SET) 919.9FT (257.9FT AGL) U/S 2509181919-2512182359
9/18/25
1748Z
11/20/25
2359Z
!SET 09/010 SET OBST TOWER LGT (ASR 1291694) 390157.60N0902757.20W (6.4NM NNW SET) 984.9FT (257.9FT AGL) U/S 2509181748-2511202359
9/18/25
0833Z
11/18/25
2359Z
!SET 09/008 SET OBST TOWER LGT (ASR 1008887) 390632.00N0903827.00W (14.5NM NW SET) 1054.8FT (259.8FT AGL) U/S 2509180833-2511182359
9/18/25
0805Z
11/17/25
2359Z
!SET 09/007 SET OBST TOWER LGT (ASR 1291692) 390153.60N0903848.10W (11.8NM WNW SET) 991.1FT (308.1FT AGL) U/S 2509180805-2511172359
9/12/25
0742Z
10/27/25
0741Z
!SET 09/004 SET OBST TOWER LGT (ASR 1324036) 390805.82N0901844.91W (13.5NM NNE SET) 887FT (275FT AGL) U/S 2509120742-2510270741
9/2/25
1730Z
10/17/25
1729Z
!SET 09/001 SET OBST TOWER LGT (ASR 1309249) 390645.16N0903058.36W (11.7NM NNW SET) 971FT (274FT AGL) U/S 2509021730-2510171729
No
NOV-MAR 0800-1700
APR-OCT 0800-DUSK
ST CHARLES COUNTY
201 N. 2ND ST.
ST CHARLES, MO 63301
Phone: 636-949-7500
DENNIS WISS
6390 GRAFTON FERRY RD
PORTAGE DES SIOUX, MO 63373
Phone: 636-949-1893
SAINT LOUIS FSS (STL)
Toll Free: 1-800-WX-BRIEF
SET
--
ACTVT MIRL RWY 18/36 AND RWY 09/27 & REIL RWY 18, PAPI RWY 18, VASI RWY 36 - CTAF. DUSK TO DAWN ONLY.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Major
Major
None
None
Crop Dusting
Charter Service
Pilot Instruction
Aircraft Rental

Runway 09/27

2000 ft. x 75 ft.
ASPH
Good
NONE
MED

12,000lbs
--
--
--
  Runway 09 Runway 27
True Heading 91°271°
Traffic Pattern Left Left
Markings BSC BSC
Markings Condition GOOD FAIR
Latitude 38° 55' 57"N 38° 55' 56"N
Longitude 90° 25' 54"W 90° 25' 29"W
Elevation 434' 436'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 18/36

3800 ft. x 75 ft.
ASPH
Good
NONE
MED

12,000lbs
--
--
--
  Runway 18 Runway 36
True Heading 181°1°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD FAIR
Latitude 38° 56' 01"N 38° 55' 23"N
Longitude 90° 25' 51"W 90° 25' 52"W
Elevation 433' 436'
Threshold Crossing Height 40 ft. AGL 41 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L V4L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes
A110-2HEAVY STUDENT TRNG.
A110-3ARPT CONDS NOT REPORTED MON-FRI 1630L-0800L DLY, FRI 1630L THRU MON 0800L.
A110-4FOR CD CTC ST LOUIS APCH AT 314-890-1017.
ST CHARLES COUNTY RGNL/SMARTT FLD (ICAO: KSET, IATA: SET) is a public airport located in ST CHARLES, MO.
