KSEA
SEATTLE-TACOMA INTL
PublicPUB

10 miles S of SEATTLE, WA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
47° 26' 60"N 122° 18' 42"W
432' MSL
1432' MSL
16E
JET A, JET A-1
SEATTLE (SEA)
SEATTLE
SEATTLE (ZSE)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

KSEA FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Terminal Area Forecast

No TAF is available for this location.
KSEA
Domestic
1/21/250800Z !SEA 01/157 SEA RWY 16C/34C CLSD EXC XNG DLY 0800-1300 2501210800-2501241300
1/15/251800Z !SEA 01/141 SEA NAV ILS RWY 34C U/S 2501151800-2501152100
1/15/251800Z !SEA 01/140 SEA NAV ILS RWY 16C U/S 2501151800-2501152100
1/15/251700Z !SEA 01/116 SEA AIRSPACE FLTCK ACFT OPS WI AN AREA DEFINED AS 472445N1221247W (4.6NM ESE SEA) TO 472039N1220200W (13NM ESE SEA) TO 471407N1220724W (15NM SE SEA) TO 471353N1222924W (15NM SSW SEA) TO 472018N1223506W (13NM SW SEA) TO 472444N1222416W (4.4NM SW SEA) TO 472325N1222259W (4.6NM SSW SEA) TO 472223N1222040W (4.8NM S SEA) TO 471956N1222045W (7.2NM S SEA) TO 471957N1221557W (7.3NM SSE SEA) TO 472206N1221606W (5.2NM SE SEA) TO POINT OF ORIGIN 1000FT-2000FT AGL INCLUDING SEA RWY 34C FINAL AND 60DEG EITHER SIDE, ACFT CS FLC76 2501151700-2501152100EST
1/9/250143Z !SEA 01/090 SEA OBST TOWER LGT (ASR 1060076) 472723.00N1221659.90W (1.2NM ENE SEA) 617.1FT (125.0FT AGL) U/S 2501090143-2505090143
1/3/251522Z !SEA 01/025 SEA OBST TOWER LGT (ASR 1317403) 484010.30N1183923.40W (2.92NM SSE R49) 3373FT (120FT AGL) U/S 2501031522-2502062300
1/2/251447Z !SEA 01/012 SEA OBST TOWER LGT (ASR 1315039) 481718.00N1181139.00W (18.0NM W 1S9) 2080FT (295FT AGL) U/S 2501021447-2502022300
1/2/251426Z !SEA 01/011 SEA OBST TOWER LGT (ASN 2021-ANM-3098-OE) 464840N1174059W (11.4NM WSW S94) 2042FT (190FT AGL) U/S 2501021426-2502022300
1/1/251555Z !SEA 01/001 SEA AIRSPACE UAS WI AN AREA DEFINED AS .5NM RADIUS OF 473227N1214820W (17NM E RNT) SFC-400FT AGL DLY SR-SS 2501011555-2504010336
12/29/240919Z !SEA 12/360 SEA RWY 16R LEAD OFF CL MARKINGS AT TWY Q OBSC 2412290919-2503310759
12/29/240917Z !SEA 12/359 SEA RWY 34L LEAD OFF CL MARKINGS AT TWY Z OBSC 2412290917-2503310759
12/29/240736Z !SEA 12/358 SEA TWY A CARGO SIGN FOR AIR CARGO 5 RAMP MISSING 2412290736-2503310759
12/20/240700Z !SEA 12/278 SEA OBST CRANE (ASN 2024-ANM-4517-NRA) 472630N1221817W (0.6NM SSE SEA) 536FT (155FT AGL) FLAGGED AND LGTD 2412200700-2501171230
12/20/240700Z !SEA 12/277 SEA OBST CRANE (ASN 2024-ANM-4516-NRA) 472630N1221815W (0.6NM SSE SEA) 536FT (155FT AGL) FLAGGED AND LGTD 2412200700-2501171230
11/2/241240Z !SEA 11/042 SEA TWY B GEOGRAPHIC PSN MARKING 9 NORTH SIDE NOT STD 2411021240-2501312359
10/2/241539Z !SEA 10/036 SEA TWY D HLDG PSN SIGN NORTH SIDE FOR RWY 16L/34R NOT STD 2410021539-2501311800
10/2/241538Z !SEA 10/035 SEA TWY C HLDG PSN SIGN SOUTH SIDE FOR RWY 16C/34C NOT STD 2410021538-2501311800
10/2/241538Z !SEA 10/034 SEA TWY C HLDG PSN SIGN SOUTH SIDE FOR RWY 16C/34C LGT U/S 2410021538-2501311800
10/2/241537Z !SEA 10/033 SEA TWY D HLDG PSN SIGN NORTH SIDE FOR RWY 16L/34R LGT U/S 2410021537-2501311800
3/29/241300Z !SEA 03/469 SEA OBST CRANE (ASN 2023-ANM-2030-NRA) 472642N1221811W (0.5NM SE SEA) 616FT (225FT AGL) FLAGGED AND LGTD 2403291300-2705020030
FDC
11/21/241333Z !FDC 4/7311 SEA IAP SEATTLE-TACOMA INTL, SEATTLE, WA.
ILS RWY 16L (CAT II - III), AMDT 8A ...
S-ILS 16L CAT II VISIBILITY ALL CATS RVR 1600. S-ILS 16L CAT III MINIMUMS NA. TEMPORARY CRANE 616 MSL 1.2NM SE OF RWY 16L (2023-ANM-2030-NRA). 2411211333-2604101333EST
7/31/241436Z !FDC 4/0720 SEA IAP SEATTLE-TACOMA INTL, SEATTLE, WA.
ILS OR LOC RWY 34C, AMDT 3E...
CHANGE EQUIPMENT NOTE TO READ: DME REQUIRED. DISREGARD RADAR DESCRIPTION FOR RYBKA STEPDOWN AND UFMOP MISSED APPROACH FIX.
2407311436-2607311436EST
4/19/242002Z !FDC 4/3198 SEA IAP SEATTLE-TACOMA INTL, SEATTLE, WA.
RNAV (GPS) Y RWY 34L, AMDT 1C...
LNAV/VNAV DA 827/HAT 448 ALL CATS. LNAV MDA 920/HAT 541 ALL CATS. VDP NA. TEMPORARY CRANE 616 MSL 5163FT NE OF RWY 34R (2023-ANM-2030-NRA).
2404192002-2604102002EST
4/19/242002Z !FDC 4/3197 SEA IAP SEATTLE-TACOMA INTL, SEATTLE, WA.
ILS OR LOC RWY 34C, AMDT 3E...
S-ILS 34C DA 660/HAT 273 ALL CATS. VDP NA. TEMPORARY CRANE 616 MSL 5163FT NE OF RWY 34R (2023-ANM-2030-NRA).
2404192002-2604102002EST
4/19/242002Z !FDC 4/3195 SEA IAP SEATTLE-TACOMA INTL, SEATTLE, WA.
ILS RWY 34C (SA CAT I AND II), AMDT 3E ...
PROCEDURE NA. TEMPORARY CRANE 616 MSL 5163FT NE OF RWY 34R (2023-ANM-2030-NRA). 2404192002-2604102002EST
4/19/242002Z !FDC 4/3194 SEA IAP SEATTLE-TACOMA INTL, SEATTLE, WA.
RNAV (GPS) Y RWY 34C, AMDT 2D...
LPV DA 660/HAT 273 ALL CATS. VDP NA. TEMPORARY CRANE 616 MSL 5163FT NE OF RWY 34R (2023-ANM-2030-NRA).
2404192002-2604102002EST
4/19/242002Z !FDC 4/3193 SEA IAP SEATTLE-TACOMA INTL, SEATTLE, WA.
ILS OR LOC RWY 34R, AMDT 3...
S-LOC 34R MDA 800/HAT 428 ALL CATS, VIS CAT C/D RVR 4000. SIDESTEP 34C MDA 800/HAT 413 ALL CATS. VDP NA. TEMPORARY CRANE 616 MSL 5163FT NE OF RWY 34R (2023-ANM-2030-NRA).
2404192002-2604102002EST
4/19/242002Z !FDC 4/3189 SEA IAP SEATTLE-TACOMA INTL, SEATTLE, WA.
ILS RWY 34R (SA CAT I AND II), AMDT 3 ...
S-ILS 34R SA CAT I VIS ALL CATS RVR 1800. S-ILS 34R SA CAT II VIS ALL CATS RVR 1800. TEMPORARY CRANE 616 MSL 5163FT NE OF RWY 34R (2023-ANM-2030-NRA). 2404192002-2604102002EST
Yes
ALL
PORT OF SEATTLE
BOX 1209
SEATTLE, WA 98111
Phone: 206-787-3000
LANCE LYTTLE
BOX 68727
SEATTLE, WA 98168
Phone: (206) 787-5229
SEATTLE FSS (SEA)
Toll Free: 1-800-WX-BRIEF
SEA
Sunset to Sunrise
--
N/A
Yes - Lighted
No
Yes
Tie-Down
Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
Air Freight
Cargo Handling
Charter Service

Runway 16C/34C

9426 ft. x 150 ft.
CONC
Excellent
GRVD
HIGH

120,000lbs
250,000lbs
550,000lbs
1,111,000lbs
  Runway 16C Runway 34C
True Heading 180°0°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 47° 27' 50"N 47° 26' 17"N
Longitude 122° 18' 40"W 122° 18' 40"W
Elevation 429' 363'
Threshold Crossing Height 71 ft. AGL 73 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights ALSF2 MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway 16L/34R

11901 ft. x 150 ft.
CONC
Excellent
GRVD
HIGH

120,000lbs
250,000lbs
550,000lbs
1,120,000lbs
  Runway 16L Runway 34R
True Heading 180°0°
Traffic Pattern
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 47° 27' 50"N 47° 25' 52"N
Longitude 122° 18' 28"W 122° 18' 29"W
Elevation 432' 347'
Threshold Crossing Height 76 ft. AGL 81 ft. AGL
Visual Glide Path Angle 3° 2.75°
Visual Slope Indicator P4L P4L
Approach Lights ALSF2 MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway 16R/34L

8500 ft. x 150 ft.
CONC
Excellent
GRVD
HIGH

120,000lbs
250,000lbs
482,000lbs
1,007,000lbs
  Runway 16R Runway 34L
True Heading 180°0°
Traffic Pattern
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 47° 27' 50"N 47° 26' 26"N
Longitude 122° 19' 04"W 122° 19' 05"W
Elevation 415' 356'
Threshold Crossing Height 69 ft. AGL 75 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4R P4L
Approach Lights ALSF2 MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights
A110-1BIRD FLOCKS WITHIN ARPT VCNTY - CHECK LCL ADZYS.
A110-10(E94) WSO/WSFO.
A110-11TWY A SOUTH OF TWY G RSTD TO ACFT WITH WINGSPAN 225 FT OR LESS.
A110-14DO NOT MISTAKE TWY T FOR LNDG SFC.
A110-15ACES TO AIR CARGO 4 PRKG AND CARGO AREAS RSTD TO ACFT WITH WINGSPAN 170 FT OR LESS.
A110-16TWY FOR CORPORATE HNGR RAMP RSTD TO ACFT WITH WINGSPAN 62 FT OR LESS FOR TAXI OPS. GA CUST PKNG IS VERY LTD.
A110-21PPR FOR ALL GA PRKG & SVCS, CTC 206-433-5481. OP HRS 0530L - 2100L, WITH A CALL OUT AVBL UPON REQ.
A110-22TAXILANE W RSTD TO ACFT WITH WINGSPAN 135 FT OR LESS N OF TWY N AND 167 FT OR LESS SOUTH OF TWY N. SEATTLE RAMP TWR PRVDS ADZY CTL ONLY.
A110-24GA LANDING FEES PAYABLE BY MAJOR CREDIT CARDS ONLY.
A110-25TAXILANE ON N SIDE OF N STLT RSTD TO ACFT WITH WINGSPAN 118 FT OR LESS. TRI-TAXILANES AT N STLT: CNTR (GREEN) TAXILANE RSTD TO ACFT WITH WINGSPAN 135 FT OR LESS. WHEN AN ACFT IS ON THE CNTR (GREEN) OR OTR (ORANGE/BLUE) TAXILANES, NO OTR ACFT CAN SIMUL USE THE ADJ TAXILANE(S). ORANGE & BLUE TAXILANES ARE RSTD TO ACFT WITH WINGSPAN 118 FT OR LESS. TWO ACFT CAN SIMUL USE THE OUTER TAXILANES.
A110-26RY STATUS LGTS ARE IN OPN.
A110-27ACFT WITH WINGSPANS OF 171 FT. OR MORE PARKED AT PAX GATES OR CARGO 7 MUST PROVIDE 30 MIN PPR PRIOR TO PUSHBACK TO SEATTLE RAMP TWR WHEN VSBY LESS THAN 2400 RVR
A110-28TWYS J & H E OF TWY T RSTD TO ACFT WITH WINGSPAN 167 FT OR LESS.
A110-29RWY 16L/34R RSTD TO ACFT WITH WINGSPAN 260 FT OR LESS.
A110-3FLIGHT NOTIFICATION SERVICE (ADCUS) AVBL.
A110-30TWY H E OF RWY 16L/34R RSTD TO ACFT WITH WINGSPAN 118 FT OR LESS WHEN EXITING RWY 16L/34R.
A110-31TWY B S OF TWY Q RSTD TO ACFT WITH WINGSPAN 260 FT OR LESS.
A110-32TWY B SOUTH OF AIR CARGO 7 RAMP RSTD TO ACFT WITH WINGSPAN 260 FT OR LESS.
A110-33AIR CARGO 5 RAMP DUAL ENG TAX ONLY
A110-34100LL FUEL NOT AVBL.
A110-35THE USE OF REVERSE THRUST BYD WHAT IS NEC FOR OPNL OR SAFETY RSNS IS DISCOURAGED AT ALL TIMES. NOISE ABATEMENT FLT PROCS IN EFCT BTN 2200-0600. FOR FURTHER INFO CTC SEA NOISE ABATEMENT OFC AT 206-787-5393.
A110-36CONS TAXI TO TKOFS AT SEA. WHEN PRACTICAL, SAFE AND AVBL, CONS TAXI TO TKOFS ARE ENCOURAGED. CONS TAXI TO TKOFS MAY RDC ACFT NOISE WI NEARBY COMMUNITIES.
A110-37RPRT BIRD STRIKES TO 206-787-7233
A110-38TO MINIMIZE NOISE AND FUEL BURN SEA ENCOURAGES AIRLINES TO SNGL ENG TAXI WHEN SAFE AND CONDS PMT.
A110-8HELICOPTERS LANDING & DEPARTING AVOID OVERFLYING FUEL FARM LCTD AT THE SE CORNER OF THE ARPT.
A110-9(E110) CONTINUOUS POWER ARPT.
SEATTLE-TACOMA INTL (ICAO: KSEA, IATA: SEA) is a public airport located in SEATTLE, WA.
