2/6/251643Z
|
!FDC 5/0834 RPD PART 1 OF 3 ODP RICE LAKE RGNL/CARL'S FLD,
RICE LAKE, WI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG-A...
UPDATE RWY 13, 19, 31 TAKEOFF OBSTACLES NOTES: RWY 13: UTILITY
BUILDING 10 FT FROM DER, 80 FT LEFT OF CENTERLINE, 3 FT AGL/1102 FT
MSL.
TREE, TRAVERSE WAY BEGINNING 404 FT FROM DER, 497 FT LEFT OF
CENTERLINE, UP TO 1139 FT MSL.
TREES, TRAVERSE WAY BEGINNING 529 FT FROM DER, 159 FT LEFT OF
CENTERLINE, UP TO 1150 FT MSL.
TREES BEGINNING 1197 FT FROM DER, 410 FT RIGHT OF CENTERLINE, UP TO
1162 FT MSL.
TREES, POLE BEGINNING 1289 FT FROM DER, 209 FT RIGHT OF CENTERLINE,
UP TO 75 FT AGL/1171 FT MSL.
TREES BEGINNING 1438 FT FROM DER, 14 FT RIGHT OF CENTERLINE, UP TO
1174 FT MSL.
TREE 2229 FT FROM DER, 133 FT LEFT OF CENTERLINE, 1160 FT MSL.
TREE 2342 FT FROM DER, 196 FT LEFT OF CENTERLINE, 1164 FT MSL.
TREE 2928 FT FROM DER, 942 FT LEFT OF CENTERLINE, 1177 FT MSL.
RWY 19: ELECTRICAL SYSTEM 14 FT FROM DER, ON CENTERLINE, 2 FT
AGL/1096 FT MSL.
TREE 905 FT FROM DER, 702 FT RIGHT OF CENTERLINE, 1127 FT MSL.
2502061643-2702061643EST
END PART 1 OF 3
!FDC 5/0834 RPD PART 2 OF 3 ODP RICE LAKE RGNL/CARL'S FLD,
RICE LAKE, WI.
TREES BEGINNING 1100 FT FROM DER, 693 FT RIGHT OF CENTERLINE, UP TO
1131 FT MSL.
TREE 1572 FT FROM DER, 831 FT RIGHT OF CENTERLINE, 1137 FT MSL.
TREE 1733 FT FROM DER, 843 FT RIGHT OF CENTERLINE, 1144 FT MSL.
RWY 31: UTILITY BUILDING 9 FT FROM DER, 80 FT LEFT OF CENTERLINE, 1
FT AGL/1093 FT MSL.
LIGHT POLE 10 FT FROM DER, 80 FT RIGHT OF CENTERLINE, 1093 FT MSL.
TREES BEGINNING 134 FT FROM DER, 84 FT LEFT OF CENTERLINE, UP TO
1149 FT MSL.
TREES BEGINNING 643 FT FROM DER, 72 FT RIGHT OF CENTERLINE, UP TO
1130 FT MSL.
TREES BEGINNING 989 FT FROM DER, 248 FT RIGHT OF CENTERLINE, UP TO
1144 FT MSL.
TREES BEGINNING 1117 FT FROM DER, 15 FT LEFT OF CENTERLINE, UP TO
1160 FT MSL.
TREES BEGINNING 1185 FT FROM DER, 268 FT RIGHT OF CENTERLINE, UP TO
1148 FT MSL.
TREES BEGINNING 1342 FT FROM DER, 38 FT LEFT OF CENTERLINE, UP TO
1165 FT MSL.
TREES BEGINNING 1460 FT FROM DER, 167 FT RIGHT OF CENTERLINE, UP TO
2502061643-2702061643EST
END PART 2 OF 3
!FDC 5/0834 RPD PART 3 OF 3 ODP RICE LAKE RGNL/CARL'S FLD,
RICE LAKE, WI.
1160 FT MSL.
TREES BEGINNING 1519 FT FROM DER, 28 FT RIGHT OF CENTERLINE, UP TO
1164 FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED.
2502061643-2702061643EST
END PART 3 OF 3
|
