ROSWELL AIR CENTER - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KROW
ROSWELL AIR CENTER
PublicPUB

3 miles S of ROSWELL, NM
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
33° 17' 60"N 104° 31' 46"W
3671' MSL
4671' MSL
07E
JET A, JET A-1+, 100LL
ALBUQUERQUE (ABQ)
ALBUQUERQUE
ALBUQUERQUE (ZAB)
4/17/25-5/15/25
KROW VFR
3:51 PM MST
Clear
10sm
62°F
24°F
29.73"Hg
270° 16kts
Gusts 24kts
AO2 SLP034 T01671044
METAR KROW 082251Z 27016G24KT 10SM CLR 17/M04 A2973 RMK AO2 SLP034 T01671044
+ Add Your Business

KROW FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Weather and Advisory

ATIS 128.45
ASOS 128.45
575-286-1096

Clearance

CD/P 132.875

Ground

GND/P 121.9

Tower

LCL/P 118.5

Emergency

EMERG 121.5

Terminal Area Forecast

KROW
Thu, 1/8 10:35 AM MST
Thu, 1/8 11:00 AM MST - Fri, 1/9 11:00 AM MST
VFR
11:00 AM MST - 4:00 PM MST
Sky Clear
6sm
270° 20kts
Gusts 30kts
VFR
4:00 PM MST - 6:00 PM MST
Sky Clear
6sm
270° 12kts
Gusts 18kts
VFR
6:00 PM MST - 2:00 AM MST
Few 8,000'
6sm
240° 8kts
VFR
2:00 AM MST - 11:00 AM MST
Showers in vicinity
Scattered 6,000'
6sm
250° 11kts
TAF KROW 081735Z 0818/0918 27020G30KT P6SM SKC
   FM082300 27012G18KT P6SM SKC
   FM090100 24008KT P6SM FEW080
   FM090900 25011KT P6SM VCSH SCT060
KROW
EffectiveExpiresCategoryNOTAM
Domestic
1/4/26
1206Z
5/2/26
2359Z
!ROW 01/006 ROW OBST TOWER LGT (ASR 1296110) 334502.10N1043422.40W (27.12NM NNW ROW) 4377FT (202FT AGL) U/S 2601041206-2605022359
12/28/25
1359Z
1/28/26
2359Z
!ROW 12/019 ROW OBST TOWER LGT (ASR 1213408) 332147.30N1043812.80W (6.6NM NW ROW) 4308.7FT (337.9FT AGL) U/S 2512281359-2601282359
12/6/25
1157Z
4/4/26
2359Z
!ROW 12/007 ROW OBST TOWER LGT (ASR 1324696) 333523.50N1045053.90W (23.64NM NW ROW) 4497FT (255FT AGL) U/S 2512061157-2604042359
12/2/25
1849Z
3/2/26
2359Z
!ROW 12/001 ROW TWY PARL TWY BTN TWY J AND TWY H CLSD LGTD AND BARRICADED 2512021849-2603022359
11/28/25
1454Z
1/12/26
2359Z
!ROW 11/018 ROW OBST TOWER LGT (ASR 1029648) 334001.10N1035539.10W
(37.4NM NE ROW) 4659FT (460FT AGL) U/S 2511281454-2601122359
5/15/25
1735Z
!ROW 05/020 ROW TWY S CLSD 2505151735-PERM
2/19/25
1523Z
!ROW 02/017 ROW AD AP ALL SFC WIP CONST W SIDE MEN AND EQUIPMENT 2502191523-PERM
1/29/25
2257Z
1/29/26
2359Z
!ROW 01/035 ROW AIRSPACE SEE CME 01/034 UAS 2501292257-2601292359
Yes
0600-2100
AFT HR - 575-347-2054 OR 575-626-3697.
CITY OF ROSWELL
425 N RICHARDSON AVE
ROSWELL, NM 88201-4730
Phone: 575-624-6700
BOBBI THOMPSON
1 JERRY SMITH CIR
ROSWELL, NM 88203-8427
Phone: 239-980-5114
ALBUQUERQUE FSS (ABQ)
Toll Free: 1-800-WX-BRIEF
ROW
--
ACTVT MALSR RWY 21; MIRL RWY 17/35 - CTAF. VASI RWY 03; PAPI RWY 17 & 35 - ON CONSLY. WHEN ATCT CLSD MIRL RWY 03/21 ON MED INTST.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
Landing Rights Airport
NOT an Airport of Entry
Minor
Minor
None
Low Pressure
Air Freight
Air Ambulance
Pilot Instruction

Runway 03/21

13000 ft. x 150 ft.
CONC
Excellent
NONE
MED

100,000lbs
200,000lbs
400,000lbs
--
  Runway 03 Runway 21
True Heading 45°225°
Traffic Pattern Right Left
Markings NPI PIR
Markings Condition GOOD GOOD
Latitude 33° 17' 10"N 33° 18' 41"N
Longitude 104° 32' 13"W 104° 30' 24"W
Elevation 3,667' 3,624'
Threshold Crossing Height 48 ft. AGL --
Visual Glide Path Angle 3° --
Visual Slope Indicator V6L --
Approach Lights MALSR
Centerline Lights
Runway End Identifier Lights

Runway 17/35

10008 ft. x 100 ft.
ASPH
Good
GRVD
MED

77,000lbs
104,000lbs
165,000lbs
--
  Runway 17 Runway 35
True Heading 180°0°
Traffic Pattern Right Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 33° 18' 55"N 33° 17' 16"N
Longitude 104° 32' 21"W 104° 32' 21"W
Elevation 3,662' 3,671'
Threshold Crossing Height 49 ft. AGL 49 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway H1

55 ft. x 55 ft.

ASPH
NONE


--
--
--
--
  Runway H1 Runway
True Heading 82°262°
Traffic Pattern
Markings
Markings Condition
Latitude 33° 18' 27"N N/A
Longitude 104° 31' 49"W N/A
Elevation 3,660' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway H2

55 ft. x 55 ft.

ASPH
NONE


--
--
--
--
  Runway H2 Runway
True Heading 82°262°
Traffic Pattern
Markings
Markings Condition
Latitude 33° 18' 19"N N/A
Longitude 104° 31' 35"W N/A
Elevation 3,653' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A11J GRIEGO.
A110-1AFT HR EXIT RAMP/FBO AREA USE LGTD PEDESTRIAN GATE - 575-347-2054.
A110-3BIRDS ON & INVOF ARPT.
A110-6LRG ACFT LONG TERM STORAGE AVBL.
A110-7FOR CD IF UNA TO CTC ON FSS FREQ, CTC ALBUQUERQUE ARTCC AT 505-856-4561.
A17AFT HR - 575-347-2054 OR 575-626-3697.
A39-03/21PCR VALUE: 1140/R/C/W/T
A39-17/35PCR VALUE: 150/R/C/W/T
A40-03/21NSTD 75 FT FM RWY EDGE.
A43-17PAPI UNUSBL BYD 8 DEG RIGHT OF CNTRLN.
A70-FUEL-100LL AFT HR - 575-347-2054.
A81-APTACTVT MALSR RWY 21; MIRL RWY 17/35 - CTAF. VASI RWY 03; PAPI RWY 17 & 35 - ON CONSLY. WHEN ATCT CLSD MIRL RWY 03/21 ON MED INTST.
ROSWELL AIR CENTER (ICAO: KROW, IATA: ROW) is a public airport located in ROSWELL, NM.
