5/21/241811Z
|
!FDC 4/7499 RCZ PART 1 OF 4 ODP RICHMOND COUNTY, ROCKINGHAM, NC.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
TAKEOFF OBSTACLE NOTES: RWY 14, TREES BEGINNING 3 FT FROM DER, 442
FT RIGHT OF CENTERLINE, UP TO 62 FT AGL/412 FT MSL.
TRAVERSE WAYS, FENCE BEGINNING 5 FT FROM DER, 178 FT LEFT OF
CENTERLINE, UP TO 371 FT MSL.
TREES, TRAVERSE WAYS, POLE BEGINNING 100 FT FROM DER, 5 FT LEFT OF
CENTERLINE, UP TO 58 FT AGL/402 FT MSL.
TREES BEGINNING 521 FT FROM DER, 604 FT RIGHT OF CENTERLINE, UP TO
83 FT AGL/424 FT MSL.
TREES BEGINNING 927 FT FROM DER, 660 FT LEFT OF CENTERLINE, UP TO
70 FT AGL/418 FT MSL.
TREE 1054 FT FROM DER, 715 FT RIGHT OF CENTERLINE, 79 FT AGL/430 FT
MSL.
TREES, CRANE, POLES, CATENARY WIRES BEGINNING 1249 FT FROM DER, 21
FT RIGHT OF CENTERLINE, UP TO 86 FT AGL/441 FT MSL.
TREES, POLES BEGINNING 1275 FT FROM DER, 224 FT LEFT OF CENTERLINE,
UP TO 64 FT AGL/420 FT MSL.
TREES BEGINNING 2140 FT FROM DER, 21 FT LEFT OF CENTERLINE, UP TO
71 FT AGL/428 FT MSL.
TREE 2469 FT FROM DER, 197 FT RIGHT OF CENTERLINE, 82 FT AGL/442 FT
2405211811-2605211811EST
END PART 1 OF 4
!FDC 4/7499 RCZ PART 2 OF 4 ODP RICHMOND COUNTY, ROCKINGHAM, NC.
MSL.
TREES BEGINNING 2476 FT FROM DER, 159 FT RIGHT OF CENTERLINE, UP TO
83 FT AGL/443 FT MSL.
TREES BEGINNING 2497 FT FROM DER, 128 FT RIGHT OF CENTERLINE, UP TO
85 FT AGL/445 FT MSL.
TREES BEGINNING 2531 FT FROM DER, 219 FT RIGHT OF CENTERLINE, UP TO
86 FT AGL/446 FT MSL.
TREES BEGINNING 2535 FT FROM DER, 74 FT RIGHT OF CENTERLINE, UP TO
88 FT AGL/448 FT MSL.
TREE 2767 FT FROM DER, 216 FT LEFT OF CENTERLINE, 68 FT AGL/430 FT
MSL.
TREES BEGINNING 4081 FT FROM DER, 970 FT LEFT OF CENTERLINE, UP TO
95 FT AGL/466 FT MSL.
RWY 32, TREES BEGINNING 9 FT FROM DER, 359 FT LEFT OF CENTERLINE,
UP TO 31 FT AGL/367 FT MSL.
TREE 33 FT FROM DER, 479 FT RIGHT OF CENTERLINE, 43 FT AGL/368 FT
MSL.
TREE 41 FT FROM DER, 345 FT RIGHT OF CENTERLINE, 48 FT AGL/387 FT
MSL.
TREES BEGINNING 86 FT FROM DER, 15 FT LEFT OF CENTERLINE, UP TO 31
2405211811-2605211811EST
END PART 2 OF 4
!FDC 4/7499 RCZ PART 3 OF 4 ODP RICHMOND COUNTY, ROCKINGHAM, NC.
FT AGL/379 FT MSL.
TREES BEGINNING 145 FT FROM DER, 2 FT RIGHT OF CENTERLINE, UP TO 71
FT AGL/392 FT MSL.
TREES BEGINNING 266 FT FROM DER, 87 FT LEFT OF CENTERLINE, UP TO 61
FT AGL/383 FT MSL.
TREES BEGINNING 328 FT FROM DER, 14 FT LEFT OF CENTERLINE, UP TO 63
FT AGL/391 FT MSL.
TREES BEGINNING 434 FT FROM DER, 2 FT RIGHT OF CENTERLINE, UP TO 81
FT AGL/395 FT MSL.
TREES BEGINNING 604 FT FROM DER, 2 FT RIGHT OF CENTERLINE, UP TO 87
FT AGL/401 FT MSL.
TREES BEGINNING 772 FT FROM DER, 314 FT LEFT OF CENTERLINE, UP TO
100 FT AGL/397 FT MSL.
TREES BEGINNING 810 FT FROM DER, 12 FT LEFT OF CENTERLINE, UP TO
107 FT AGL/406 FT MSL.
TREES BEGINNING 893 FT FROM DER, 2 FT RIGHT OF CENTERLINE, UP TO 70
FT AGL/403 FT MSL.
TREES BEGINNING 1007 FT FROM DER, 1 FT RIGHT OF CENTERLINE, UP TO
72 FT AGL/405 FT MSL.
TREES BEGINNING 1010 FT FROM DER, 3 FT LEFT OF CENTERLINE, UP TO
2405211811-2605211811EST
END PART 3 OF 4
!FDC 4/7499 RCZ PART 4 OF 4 ODP RICHMOND COUNTY, ROCKINGHAM, NC.
107 FT AGL/407 FT MSL.
TREES BEGINNING 1209 FT FROM DER, 2 FT LEFT OF CENTERLINE, UP TO
114 FT AGL/418 FT MSL.
TREES BEGINNING 1399 FT FROM DER, 1 FT LEFT OF CENTERLINE, UP TO
110 FT AGL/419 FT MSL.
TREES BEGINNING 1431 FT FROM DER, 38 FT RIGHT OF CENTERLINE, UP TO
100 FT AGL/411 FT MSL.
TREES BEGINNING 1452 FT FROM DER, 10 FT RIGHT OF CENTERLINE, UP TO
106 FT AGL/416 FT MSL.
TREES BEGINNING 1914 FT FROM DER, 3 FT RIGHT OF CENTERLINE, UP TO
76 FT AGL/418 FT MSL.
TREE 2182 FT FROM DER, 499 FT RIGHT OF CENTERLINE, 87 FT AGL/428 FT
MSL.
TREES BEGINNING 2187 FT FROM DER, 515 FT RIGHT OF CENTERLINE, UP TO
82 FT AGL/430 FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED.
2405211811-2605211811EST
END PART 4 OF 4
|
