4/18/231527Z
|
!FDC 3/3249 PVU PART 1 OF 5 ODP PROVO MUNI, PROVO, UT.
PROVO FOUR DEPARTURE ...
CHANGE TAKEOFF MINIMUMS TO READ: RWY 31: STANDARD WITH A MINIMUM
CLIMB OF 445 FT PER NM TO 9000 OR 3100-3 FOR VCOA.
RWY 36: STANDARD WITH A MINIMUM CLIMB OF 400 FT PER NM TO 9000 OR
3100-3 FOR VCOA.
DELETE AND HOLD FROM ALL DEPARTURE ROUTE DESCRIPTIONS.
TAKEOFF OFF OBSTACLE NOTES:
NOTE: RWY 13: TREES BEGINNING 45 FT FROM DER, 454 FT RIGHT OF
CENTERLINE, UP TO 10 FT AGL/4499 FT MSL.
TREE 419 FT FROM DER, 603 FT RIGHT OF CENTERLINE, 22 FT AGL/4517 FT
MSL.
TREE 538 FT FROM DER, 595 FT RIGHT OF CENTERLINE, 30 FT AGL/4522 FT
MSL.
TREES BEGINNING 653 FT FROM DER, 602 FT RIGHT OF CENTERLINE, UP TO
40 FT AGL/4534 FT MSL.
TREES BEGINNING 733 FT FROM DER, 593 FT LEFT OF CENTERLINE, UP TO
42 FT AGL/4536 FT MSL.
TREES BEGINNING 1162 FT FROM DER, 599 FT RIGHT OF CENTERLINE, UP TO
46 FT AGL/4540 FT MSL
NOTE: RWY 18: TREES BEGINNING 171 FT FROM DER, 225 FT LEFT OF
ALL OTHER DATA REMAINS AS PUBLISHED. 2304181527-2504181527EST
END PART 1 OF 5
!FDC 3/3249 PVU PART 2 OF 5 ODP PROVO MUNI, PROVO, UT.
CENTERLINE, UP TO 11 FT AGL/4502 FT MSL.
TREES, TRAVERSE WAYS BEGINNING 381 FT FROM DER, 14 FT LEFT OF
CENTERLINE, UP TO 31 FT AGL/4526 FT MSL.
TREE 729 FT FROM DER, 48 FT RIGHT OF CENTERLINE, 17 FT AGL/4512 FT
MSL.
TRAVERSE WAYS BEGINNING 757 FT FROM DER, 2 FT RIGHT OF CENTERLINE,
UP TO 4518 FT MSL.
TREE 837 FT FROM DER, 206 FT RIGHT OF CENTERLINE, 37 FT AGL/4532 FT
MSL.
TREES BEGINNING 885 FT FROM DER, 307 FT RIGHT OF CENTERLINE, UP TO
46 FT AGL/4539 FT MSL.
TREES BEGINNING 1184 FT FROM DER, 590 FT RIGHT OF CENTERLINE, UP TO
51 FT AGL/4547 FT MSL
NOTE: RWY 31: LIGHT POLE 9 FT FROM DER, 55 FT RIGHT OF CENTERLINE,
2 FT AGL/4498 FT MSL.
TRAVERSE WAYS BEGINNING 554 FT FROM DER, 630 FT LEFT OF CENTERLINE,
UP TO 4519 FT MSL.
TRAVERSE WAY 852 FT FROM DER, 630 FT LEFT OF CENTERLINE, 4520 FT
MSL.
TREE 1203 FT FROM DER, 380 FT RIGHT OF CENTERLINE, 42 FT AGL/4540
ALL OTHER DATA REMAINS AS PUBLISHED. 2304181527-2504181527EST
END PART 2 OF 5
!FDC 3/3249 PVU PART 3 OF 5 ODP PROVO MUNI, PROVO, UT.
FT MSL.
TREE 1435 FT FROM DER, 416 FT RIGHT OF CENTERLINE, 51 FT AGL/4543
FT MSL.
TREE 1550 FT FROM DER, 398 FT RIGHT OF CENTERLINE, 51 FT AGL/4547
FT MSL.
TREES BEGINNING 1711 FT FROM DER, 363 FT RIGHT OF CENTERLINE, UP TO
69 FT AGL/4562 FT MSL.
TREE 1845 FT FROM DER, 563 FT RIGHT OF CENTERLINE, 77 FT AGL/4570
FT MSL.
TREE 1938 FT FROM DER, 499 FT RIGHT OF CENTERLINE, 84 FT AGL/4581
FT MSL.
TREE 1939 FT FROM DER, 632 FT RIGHT OF CENTERLINE, 90 FT AGL/4583
FT MSL.
TREES BEGINNING 1940 FT FROM DER, 292 FT RIGHT OF CENTERLINE, UP TO
100 FT AGL/4593 FT MSL.
NOTE: RWY 36: TREE 80 FT FROM DER, 335 FT RIGHT OF CENTERLINE, 9 FT
AGL/4502 FT MSL.
TREE 85 FT FROM DER, 416 FT LEFT OF CENTERLINE, 7 FT AGL/4497 FT
MSL.
TREE, TRAVERSE WAYS, TANK BEGINNING 90 FT FROM DER, 238 FT RIGHT OF
ALL OTHER DATA REMAINS AS PUBLISHED. 2304181527-2504181527EST
END PART 3 OF 5
!FDC 3/3249 PVU PART 4 OF 5 ODP PROVO MUNI, PROVO, UT.
CENTERLINE, UP TO 17 FT AGL/4511 FT MSL.
TREE 139 FT FROM DER, 164 FT LEFT OF CENTERLINE, 15 FT AGL/4505 FT
MSL.
TREES, TRAVERSE WAY BEGINNING 164 FT FROM DER, 247 FT LEFT OF
CENTERLINE, UP TO 16 FT AGL/4509 FT MSL.
TRAVERSE WAY 204 FT FROM DER, 301 FT LEFT OF CENTERLINE, 4511 FT
MSL.
TREE, TRAVERSE WAYS BEGINNING 222 FT FROM DER, 405 FT LEFT OF
CENTERLINE, UP TO 16 FT AGL/4515 FT MSL.
TREE 977 FT FROM DER, 109 FT RIGHT OF CENTERLINE, 4534 FT MSL.
TREE 1326 FT FROM DER, 18 FT RIGHT OF CENTERLINE, 4541 FT MSL.
TREE 1343 FT FROM DER, ON CENTERLINE, 56 FT AGL/4550 FT MSL.
TREE 2140 FT FROM DER, 1050 FT LEFT OF CENTERLINE, 72 FT AGL/4564
FT MSL.
TREE 2791 FT FROM DER, 885 FT RIGHT OF CENTERLINE, 74 FT AGL/4572
FT MSL.
TREES BEGINNING 2817 FT FROM DER, 1079 FT LEFT OF CENTERLINE, UP TO
85 FT AGL/4580 FT MSL.
TREE 3046 FT FROM DER, 1030 FT RIGHT OF CENTERLINE, 75 FT AGL/4574
FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2304181527-2504181527EST
END PART 4 OF 5
!FDC 3/3249 PVU PART 5 OF 5 ODP PROVO MUNI, PROVO, UT.
TREES BEGINNING 3069 FT FROM DER, 953 FT LEFT OF CENTERLINE, UP TO
89 FT AGL/4586 FT MSL.
TREE 3110 FT FROM DER, 883 FT RIGHT OF CENTERLINE, 87 FT AGL/4585
FT MSL.
TREE 3213 FT FROM DER, 1175 FT LEFT OF CENTERLINE, 91 FT AGL/4588
FT MSL.
TREE 3620 FT FROM DER, 1218 FT LEFT OF CENTERLINE, 98 FT AGL/4595
FT MSL.
TREE 3805 FT FROM DER, 1269 FT LEFT OF CENTERLINE, 101 FT AGL/4598
FT MSL.
TERRAIN BEGINNING 2.2 NM FROM DER, 4027 FT RIGHT OF CENTERLINE, UP
TO 200 FT AGL/4918 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2304181527-2504181527EST
END PART 5 OF 5
|
