10/13/23 1422Z | 10/13/25 1422Z | | !FDC 3/5393 PNE PART 1 OF 8 ODP NORTHEAST PHILADELPHIA,
PHILADELPHIA, PA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF MINIMUMS: RWY 33: 300-1 1/8 WITH MINIMUM CLIMB OF 250 FT/NM
TO 400, OR ALTERNATIVELY, WITH STANDARD TAKEOFF MINIMUMS AND A
NORMAL 200 FT/NM CLIMB GRADIENT, TAKEOFF MUST OCCUR NO LATER THAN
2100 FEET PRIOR TO DER. TAKEOFF OBSTACLE NOTES: RWY 6, LIGHT
POLES, VERTICAL STRUCTURES BEGINNING 3 FT FROM DER, 10 FT LEFT OF
CENTERLINE, UP TO 2 FT AGL/115 FT MSL.
VERTICAL STRUCTURE, LIGHT POLE BEGINNING 5 FT FROM DER, 10 FT RIGHT
OF CENTERLINE, UP TO 2 FT AGL/115 FT MSL.
TREE 753 FT FROM DER, 653 FT LEFT OF CENTERLINE, 158 FT MSL.
TREES BEGINNING 780 FT FROM DER, 645 FT LEFT OF CENTERLINE, UP TO
168 FT MSL.
TREE 963 FT FROM DER, 697 FT LEFT OF CENTERLINE, 172 FT MSL.
TREE 1069 FT FROM DER, 737 FT LEFT OF CENTERLINE, 177 FT MSL.
TREES BEGINNING 1327 FT FROM DER, 803 FT LEFT OF CENTERLINE, UP TO
188 FT MSL.
TREES BEGINNING 1557 FT FROM DER, 688 FT RIGHT OF CENTERLINE, UP TO
175 FT MSL.
TREE 1925 FT FROM DER, 996 FT RIGHT OF CENTERLINE, 186 FT MSL.
TREES BEGINNING 2021 FT FROM DER, 772 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2310131422-2510131422EST
END PART 1 OF 8
!FDC 3/5393 PNE PART 2 OF 8 ODP NORTHEAST PHILADELPHIA,
PHILADELPHIA, PA.
190 FT MSL.
TREES BEGINNING 2052 FT FROM DER, 486 FT LEFT OF CENTERLINE, UP TO
191 FT MSL.
TREE 3571 FT FROM DER, 918 FT LEFT OF CENTERLINE, 205 FT MSL.
RWY 15, TERRAIN 34 FT FROM DER, 489 FT LEFT OF CENTERLINE, 110 FT
MSL.
POLE, FENCES BEGINNING 322 FT FROM DER, 324 FT LEFT OF CENTERLINE,
UP TO 34 FT AGL/141 FT MSL.
TREE 440 FT FROM DER, 528 FT LEFT OF CENTERLINE, 145 FT MSL.
TREES BEGINNING 588 FT FROM DER, 474 FT LEFT OF CENTERLINE, UP TO
158 FT MSL.
TREES BEGINNING 716 FT FROM DER, 574 FT LEFT OF CENTERLINE, UP TO
163 FT MSL.
TREES BEGINNING 887 FT FROM DER, 20 FT LEFT OF CENTERLINE, UP TO
171 FT MSL.
TREES BEGINNING 901 FT FROM DER, 63 FT RIGHT OF CENTERLINE, UP TO
138 FT MSL.
TREE 1317 FT FROM DER, 209 FT RIGHT OF CENTERLINE, 141 FT MSL.
TREE 1369 FT FROM DER, 27 FT RIGHT OF CENTERLINE, 144 FT MSL.
TREES BEGINNING 1412 FT FROM DER, 15 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2310131422-2510131422EST
END PART 2 OF 8
!FDC 3/5393 PNE PART 3 OF 8 ODP NORTHEAST PHILADELPHIA,
PHILADELPHIA, PA.
188 FT MSL.
TREE 3537 FT FROM DER, 588 FT LEFT OF CENTERLINE, 205 FT MSL.
TREES BEGINNING 3625 FT FROM DER, 528 FT LEFT OF CENTERLINE, UP TO
212 FT MSL.
TREE 3776 FT FROM DER, 659 FT LEFT OF CENTERLINE, 219 FT MSL.
TREE 4254 FT FROM DER, 1160 FT LEFT OF CENTERLINE, 220 FT MSL.
RWY 24, TREE 95 FT FROM DER, 345 FT RIGHT OF CENTERLINE, 121 FT
MSL.
TREE 197 FT FROM DER, 540 FT LEFT OF CENTERLINE, 129 FT MSL.
TREE 215 FT FROM DER, 416 FT RIGHT OF CENTERLINE, 134 FT MSL.
TREES BEGINNING 434 FT FROM DER, 444 FT RIGHT OF CENTERLINE, UP TO
137 FT MSL.
TREE 473 FT FROM DER, 439 FT LEFT OF CENTERLINE, 135 FT MSL.
TREES BEGINNING 475 FT FROM DER, 448 FT LEFT OF CENTERLINE, UP TO
139 FT MSL.
TREES BEGINNING 582 FT FROM DER, 304 FT LEFT OF CENTERLINE, UP TO
147 FT MSL.
BUILDING 741 FT FROM DER, 571 FT RIGHT OF CENTERLINE, 31 FT AGL/138
FT MSL.
TREES BEGINNING 749 FT FROM DER, 598 FT LEFT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2310131422-2510131422EST
END PART 3 OF 8
!FDC 3/5393 PNE PART 4 OF 8 ODP NORTHEAST PHILADELPHIA,
PHILADELPHIA, PA.
157 FT MSL.
BUILDING 770 FT FROM DER, 516 FT RIGHT OF CENTERLINE, 31 FT AGL/139
FT MSL.
TREE 774 FT FROM DER, 516 FT LEFT OF CENTERLINE, 161 FT MSL.
TREES BEGINNING 818 FT FROM DER, 347 FT LEFT OF CENTERLINE, UP TO
163 FT MSL.
TREES BEGINNING 868 FT FROM DER, 435 FT LEFT OF CENTERLINE, UP TO
172 FT MSL.
TREES BEGINNING 1162 FT FROM DER, 506 FT LEFT OF CENTERLINE, UP TO
174 FT MSL.
TREE 1230 FT FROM DER, 674 FT LEFT OF CENTERLINE, 175 FT MSL.
TREES BEGINNING 1253 FT FROM DER, 15 FT LEFT OF CENTERLINE, UP TO
179 FT MSL.
TREES BEGINNING 1325 FT FROM DER, 86 FT RIGHT OF CENTERLINE, UP TO
163 FT MSL.
TREES BEGINNING 1531 FT FROM DER, 35 FT RIGHT OF CENTERLINE, UP TO
170 FT MSL.
TREES BEGINNING 1844 FT FROM DER, 47 FT RIGHT OF CENTERLINE, UP TO
171 FT MSL.
TREE 1955 FT FROM DER, 306 FT RIGHT OF CENTERLINE, 174 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2310131422-2510131422EST
END PART 4 OF 8
!FDC 3/5393 PNE PART 5 OF 8 ODP NORTHEAST PHILADELPHIA,
PHILADELPHIA, PA.
TREES BEGINNING 1991 FT FROM DER, 19 FT RIGHT OF CENTERLINE, UP TO
176 FT MSL.
TREES BEGINNING 2077 FT FROM DER, 140 FT RIGHT OF CENTERLINE, UP TO
181 FT MSL.
TREES BEGINNING 2224 FT FROM DER, 182 FT RIGHT OF CENTERLINE, UP TO
184 FT MSL.
TREE 2421 FT FROM DER, 293 FT RIGHT OF CENTERLINE, 187 FT MSL.
TREE 2525 FT FROM DER, 606 FT LEFT OF CENTERLINE, 182 FT MSL.
TREE 2615 FT FROM DER, 909 FT LEFT OF CENTERLINE, 184 FT MSL.
TREES BEGINNING 2642 FT FROM DER, 580 FT LEFT OF CENTERLINE, UP TO
195 FT MSL.
TREE 3280 FT FROM DER, 1081 FT LEFT OF CENTERLINE, 200 FT MSL.
TREE 3345 FT FROM DER, 582 FT LEFT OF CENTERLINE, 203 FT MSL.
RWY 33, TREES BEGINNING 330 FT FROM DER, 283 FT RIGHT OF
CENTERLINE, UP TO 152 FT MSL.
ELECTRICAL SYSTEM, TREES BEGINNING 726 FT FROM DER, 44 FT RIGHT OF
CENTERLINE, UP TO 38 FT AGL/160 FT MSL.
TREE 823 FT FROM DER, 163 FT LEFT OF CENTERLINE, 141 FT MSL.
TREE 877 FT FROM DER, 314 FT LEFT OF CENTERLINE, 142 FT MSL.
TREE 1128 FT FROM DER, 159 FT LEFT OF CENTERLINE, 149 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2310131422-2510131422EST
END PART 5 OF 8
!FDC 3/5393 PNE PART 6 OF 8 ODP NORTHEAST PHILADELPHIA,
PHILADELPHIA, PA.
TREES BEGINNING 1145 FT FROM DER, 214 FT LEFT OF CENTERLINE, UP TO
179 FT MSL.
TREES BEGINNING 1362 FT FROM DER, 141 FT RIGHT OF CENTERLINE, UP TO
161 FT MSL.
TREES BEGINNING 1463 FT FROM DER, 136 FT LEFT OF CENTERLINE, UP TO
187 FT MSL.
TREES BEGINNING 1593 FT FROM DER, 154 FT LEFT OF CENTERLINE, UP TO
192 FT MSL.
TREE 1679 FT FROM DER, 402 FT RIGHT OF CENTERLINE, 165 FT MSL.
TREE 1720 FT FROM DER, 43 FT RIGHT OF CENTERLINE, 166 FT MSL.
TREE 1811 FT FROM DER, 356 FT RIGHT OF CENTERLINE, 169 FT MSL.
TREES BEGINNING 1818 FT FROM DER, 72 FT LEFT OF CENTERLINE, UP TO
199 FT MSL.
TREE 1882 FT FROM DER, 447 FT RIGHT OF CENTERLINE, 171 FT MSL.
TREE 1951 FT FROM DER, 101 FT RIGHT OF CENTERLINE, 187 FT MSL.
TREES BEGINNING 1970 FT FROM DER, 209 FT LEFT OF CENTERLINE, UP TO
201 FT MSL.
TREES BEGINNING 1980 FT FROM DER, 30 FT RIGHT OF CENTERLINE, UP TO
197 FT MSL.
TREES BEGINNING 2142 FT FROM DER, 398 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2310131422-2510131422EST
END PART 6 OF 8
!FDC 3/5393 PNE PART 7 OF 8 ODP NORTHEAST PHILADELPHIA,
PHILADELPHIA, PA.
202 FT MSL.
TREES BEGINNING 2190 FT FROM DER, 492 FT LEFT OF CENTERLINE, UP TO
210 FT MSL.
TREES BEGINNING 2254 FT FROM DER, 30 FT LEFT OF CENTERLINE, UP TO
216 FT MSL.
TREES, ELECTRICAL SYSTEM BEGINNING 2261 FT FROM DER, 68 FT RIGHT OF
CENTERLINE, UP TO 206 FT MSL.
TREE 2293 FT FROM DER, 556 FT LEFT OF CENTERLINE, 223 FT MSL.
TREES BEGINNING 2293 FT FROM DER, 168 FT LEFT OF CENTERLINE, UP TO
224 FT MSL.
TREE 2464 FT FROM DER, 829 FT LEFT OF CENTERLINE, 231 FT MSL.
TREES, ELECTRICAL SYSTEM BEGINNING 2479 FT FROM DER, 509 FT RIGHT
OF CENTERLINE, UP TO 207 FT MSL.
TREES BEGINNING 2501 FT FROM DER, 184 FT LEFT OF CENTERLINE, UP TO
245 FT MSL.
TREES, ELECTRICAL SYSTEM BEGINNING 2657 FT FROM DER, 338 FT RIGHT
OF CENTERLINE, UP TO 224 FT MSL.
TREES, ELECTRICAL SYSTEM BEGINNING 2812 FT FROM DER, 45 FT RIGHT OF
CENTERLINE, UP TO 226 FT MSL.
TREES BEGINNING 3081 FT FROM DER, 174 FT LEFT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2310131422-2510131422EST
END PART 7 OF 8
!FDC 3/5393 PNE PART 8 OF 8 ODP NORTHEAST PHILADELPHIA,
PHILADELPHIA, PA.
246 FT MSL.
TREE 4477 FT FROM DER, 492 FT RIGHT OF CENTERLINE, 233 FT MSL.
TREE 4929 FT FROM DER, 1586 FT RIGHT OF CENTERLINE, 269 FT MSL.
TREES BEGINNING 4940 FT FROM DER, 1692 FT RIGHT OF CENTERLINE, UP
TO 271 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2310131422-2510131422EST
END PART 8 OF 8
|
