No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KPDX
PORTLAND INTL
PublicPUB

4 miles NE of PORTLAND, OR
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
45° 35' 19"N 122° 35' 49"W
31' MSL
1031' MSL
16E
JET A, 100LL
MC MINNVILLE (MMV)
SEATTLE
SEATTLE (ZSE)
10/31/24-11/28/24
KPDX VFR
3:53 AM PST
Broken 18,000'
10sm
48°F
40°F
30.00"Hg
110° 7kts
AO2 SLP157 T00890044 10106 20089 58009
KPDX 091153Z 11007KT 10SM BKN180 09/04 A3000 RMK AO2 SLP157 T00890044 10106 20089 58009
Add Your Business

KPDX FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Terminal Area Forecast

KPDX
Sat, 11/9 3:24 AM PST
Sat, 11/9 4:00 AM PST - Sun, 11/10 4:00 AM PST
VFR
4:00 AM PST - 12:00 PM PST
Broken 18,000'
6sm
130° 5kts
VFR
12:00 PM PST - 4:00 PM PST
Broken 6,000'
6sm
160° 6kts
VFR
4:00 PM PST - 12:00 AM PST
Light Rain
Overcast 4,500'
Scattered 3,500'
6sm
160° 6kts
MVFR
12:00 AM PST - 4:00 AM PST
Showers in vicinity
Overcast 3,500'
Broken 2,500'
6sm
130° 5kts
KPDX 091124Z 0912/1012 13005KT P6SM BKN180
   FM092000 16006KT P6SM BKN060
   FM100000 16006KT P6SM -RA SCT035 OVC045
   FM100800 13005KT P6SM VCSH BKN025 OVC035
KPDX
Domestic
11/7/240801Z !PDX 11/001 PDX RWY 10R/28L CLSD 2411070801-2411071100
11/6/242200Z !PDX 11/003 PDX RWY 10R/28L CLSD WED 2200-2300 2411062200-2502262300
11/6/241700Z !PDX 11/002 PDX RWY 10L/28R CLSD WED 1700-1800 2411061700-2502261800
11/6/240127Z !PDX 11/004 PDX OBST TOWER LGT (ASN 2022-ANM-3573-OE) 453642N1223308W (2.3NM NE PDX) 386FT (104FT AGL) U/S 2411060127-2412062300
9/18/242309Z !PDX 09/066 PDX OBST RIG (ASN 2023-ANM-414-NRA) 453459N1223436W (0.9NM ESE PDX) 100FT (80FT AGL) FLAGGED AND LGTD 2409182309-2510012359
9/18/242306Z !PDX 09/065 PDX OBST RIG (ASN 2023-ANM-417-NRA) 453512N1223510W (0.5NM ESE PDX) 103FT (80FT AGL) FLAGGED AND LGTD 2409182306-2509302359
9/18/242204Z !PDX 09/064 PDX RWY 03 DECLARED DIST: TORA 0FT TODA 0FT ASDA 0FT LDA 3000FT. 2409182204-2601010801
9/18/242203Z !PDX 09/063 PDX RWY 03 CLSD TO TKOF 2409182203-2601010801
9/4/242109Z !PDX 09/019 PDX RWY 21 CLSD TO LDG AND TKOF 2409042109-2601010801
5/10/240133Z !PDX 05/015 PDX OBST CRANE (ASN 2023-ANM-416-NRA) 453514N1223514W (0.4NM ESE PDX) 106FT (80FT AGL) FLAGGED AND LGTD 2405100133-2505311500
1/1/240501Z !PDX 01/003 PDX TWY G BTN RWY 03/21 AND SOUTHWEST RAMP CLSD 2401010501-2412312359
1/1/240459Z !PDX 01/002 PDX OBST CRANE (ASN UNKNOWN) 453539N1223623W (0.72NM E APCH END RWY 10R)
UNKNOWN (100FT AGL) FLAGGED AND LGTD 2401010459-2412310100
12/18/231754Z !PDX 12/031 PDX NAV ILS RWY 21 LOC/DME U/S 2312181754-2512312000EST
12/18/231753Z !PDX 12/030 PDX RWY 21 PAPI U/S 2312181753-2512312000
12/18/231753Z !PDX 12/029 PDX RWY 21 RWY END ID LGT U/S 2312181753-2512312000
FDC
11/6/241400Z !FDC 4/9559 PDX SID PORTLAND INTL, PORTLAND, OR.
PORTLAND TWO DEPARTURE...
DESCHUTES TRANSITION NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
DSD VORTAC OUT OF SERVICE. 2411061400-2506180212EST
10/31/241328Z !FDC 4/7002 PDX IAP PORTLAND INTL, PORTLAND, OR.
RNAV (RNP) Z RWY 10L, AMDT 2...
RNP 0.30 DA 465/HAT 435 ALL CATS. VISIBILITY ALL CATS RVR 4000. TEMPORARY CRANE 266FT MSL 2509FT SW OF RWY 10L (2021-ANM-3198-NRA).
2410311328-2412311328EST
10/31/240500Z !FDC 4/6021 PDX SID PORTLAND INTL, PORTLAND, OR.
CASCADE THREE DEPARTURE (RNAV) ...
DESCHUTES TRANSITION: CHANGE CHISM TO DSD VORTAC COURSE FROM 124.88 TO 126.88. 2410310500-2610310500EST
9/20/241435Z !FDC 4/8655 PDX IAP U.S. DOD PORTLAND INTL, PORTLAND, OR.
HI - ILS OR LOC RWY 28R, AMDT 4...
DME REQUIRED EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
UBG VOR/DME OUT OF SERVICE. 2409201435-2412041435EST
9/20/241435Z !FDC 4/8646 PDX IAP PORTLAND INTL, PORTLAND, OR.
ILS OR LOC RWY 28L, AMDT 5A...
MISSED APPROACH: CLIMB TO 2100 THEN CLIMBING LEFT TURN TO 4000 ON BTG R-194 TO ENDZZ/BTG 23.00 DME AND HOLD (DME REQUIRED),
UBG VOR/DME OUT OF SERVICE. 2409201435-2412041435EST
9/20/241435Z !FDC 4/8641 PDX IAP PORTLAND INTL, PORTLAND, OR.
ILS OR LOC RWY 10R, AMDT 35A...
ILS RWY 10R (SA CAT I), AMDT 35A...
ILS RWY 10R (CAT II AND III), AMDT 35A...
DME REQUIRED EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
UBG VOR/DME OUT OF SERVICE. 2409201435-2412041435EST
9/3/241103Z !FDC 4/9053 PDX IAP PORTLAND INTL, PORTLAND, OR.
RNAV (GPS) Y RWY 10L, AMDT 2C...
LPV DA 372/HAT 342 ALL CATS. LNAV/VNAV DA 477/HAT 447 ALL CATS. LNAV MDA 860/HAT 830 ALL CATS. LPV VISIBILITY ALL CATS RVR 3000. LNAV VISIBILITY CAT C/D 1 7/8. CIRCLING CAT A/B MDA 860/HAA 829. VISIBILITY CAT A/B 1 1/4. FOR INOPERATIVE MALSR, INCREASE LPV VISIBILITY ALL CATS TO RVR 5500. TEMPORARY CRANE 236 MSL 1410FT SE OF RWY 10L (2021-ANM-1482-NRA). TEMPORARY CRANE 266FT MSL 2509FT SOUTHWEST OF RWY 10L (2021-ANM-3198-NRA).
2409031103-2412301103EST
9/3/241103Z !FDC 4/9051 PDX IAP PORTLAND INTL, PORTLAND, OR.
ILS OR LOC RWY 10L, AMDT 4C...
S-ILS DA 372/HAT 342 ALL CATS. S-LOC MDA 560/HAT 530 ALL CATS. S-ILS VISIBILITY ALL CATS RVR 3000. S-LOC VISIBILITY CATS C/D/E RVR 5500. FOR INOPERATIVE MALSR, INCREASE S-ILS VISIBILITY ALL CATS TO RVR 5500. INCREASE S-LOC CAT E VISIBILITY TO 1 1/2 SM. TEMPORARY CRANE 266FT MSL 2509FT SOUTHWEST OF RWY 10L (2021-ANM-3198-NRA).
2409031103-2412301103EST
6/11/241324Z !FDC 4/6618 PDX IAP U.S. DOD PORTLAND INTL, PORTLAND, OR.
HI - TACAN RWY 10R, AMDT 1B...
CIRCLING CAT C/D MDA 1060/HAA 1029.
2406111324-2606111324EST
3/5/241852Z !FDC 4/3213 PDX IAP PORTLAND INTL, PORTLAND, OR.
ILS RWY 10R (SA CAT I), AMDT 35A ...
ILS RWY 10R (CAT II AND III), AMDT 35A ...
PROCEDURE NA, EXCEPT WHEN ADVISED BY ATC THAT THIS CRANE IS LOWERED. TEMPORARY CRANE 266FT MSL 3671FT NORTHWEST OF RWY 10R DEPARTURE END. (2021-ANM-3200-NRA) 2403051852-2501101852EST
Yes
ALL
THE PORT OF PORTLAND
BOX 3529
PORTLAND, OR 97208
Phone: 503-415-6000
STEPHEN NAGY
7200 NE AIRPORT WAY
PORTLAND, OR 97218
Phone: 503-415-6195
MC MINNVILLE FSS (MMV)
Toll Free: 1-800-WX-BRIEF
PDX
Sunset to Sunrise
--
N/A
Yes - Lighted
No
Yes
Hanger, Tie-Down
Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
High & Low Pressure
High & Low Pressure
Air Freight
Air Ambulance
Avionics
Cargo Handling
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 03/21

6000 ft. x 150 ft.
ASPH
Excellent
GRVD
MED
82 /F/D/X/T
120,000lbs
250,000lbs
380,000lbs
--
  Runway 03 Runway 21
True Heading 45°225°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 45° 34' 57"N 45° 35' 39"N
Longitude 122° 37' 01"W 122° 36' 01"W
Elevation 22' 26'
Threshold Crossing Height 60 ft. AGL 32 ft. AGL
Visual Glide Path Angle 3.3° 3.6°
Visual Slope Indicator P4L P4R
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes

Runway 10L/28R

9825 ft. x 150 ft.
ASPH
Excellent
GRVD
HIGH
133/F/D/W/T
200,000lbs
200,000lbs
400,000lbs
--
  Runway 10L Runway 28R
True Heading 119°299°
Traffic Pattern Left Right
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 45° 35' 47"N 45° 35' 00"N
Longitude 122° 36' 00"W 122° 33' 59"W
Elevation 30' 31'
Threshold Crossing Height 51 ft. AGL 70 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4R
Approach Lights MALSR MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway 10R/28L

11000 ft. x 150 ft.
CONC
Good
GRVD
HIGH
89 /R/D/W/T
200,000lbs
200,000lbs
360,000lbs
--
  Runway 10R Runway 28L
True Heading 119°299°
Traffic Pattern Right Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 45° 35' 43"N 45° 34' 50"N
Longitude 122° 37' 17"W 122° 35' 02"W
Elevation 23' 23'
Threshold Crossing Height 71 ft. AGL 72 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4R P4L
Approach Lights ALSF2 MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights
A110-14UNCONTROLLED TFC AT PEARSON FIELD VANCOUVER WA 3 NM W OF RY 10L THLD ON EXTDD CNTRLN.
A110-22(E94) WSFO/WSO/FW/RFC.
A110-23AREA OF TWY T BTN M & E3 NOT VSB FM TWR.
A110-28ACFT AUTHORIZED TO UTILIZE THE NORTHWEST RAMP WILL BE TOWED TO/FROM THIS RAMP.
A110-29AT THE WEST END ARM/DEARM AREA ON TWY C NO ACFT OF ANY TYPE MAY TAXI PAST THE ARM/DEARM AREA WHILE IT IS BEING USED.
A110-3ARPT CLSD TO NON-POWERED ACFT EXCP IN EMERG.
A110-34BEARING STRENGTH: RWY 03-21 ST 175, RY 10L-28R ST175, RY 10R-28L ST175.
A110-36JASU - 4(A/M32A-86) (MC-11) 1(MA-1A).
A110-37FUEL - A (AIR BP - ATLANTIC AVIATION SVCS. C503-331-4220) J8(MIL) (NC-100LL, A)
A110-38FLUID - LHOXRB.
A110-39OIL - O-128-133-148(MIL).
A110-41MISC: FLT NOTIFICATION SVC, ADCUS, AVBL.
A110-42ANG : PPR/OFFL BUS ONLY. BASE OPS OPR 1500-2300Z++ MON-FRI EXC HOL.; DSN 638-4390, C503-335-4390. CTC BASE OPS 15 MIN PRIOR TO LDG AND AFTER DEP ON 281.2. TRAN QUARTERS NOT AVBL. CAUTION: OBST LIGHTING IS NOT NVD COMPATIBLE. NVD NOT AUTHORIZED WHILE AIRBORNE IN VCNTY OF AFLD.
A110-43TWY V CLSD TO ACFT WITH WINGSPAN GREATER THAN 168 FT. ACFT WITH WINGSPAN GREATER THAN 118 FT PROHIBITED FM TURNING WB ONTO TWY A FM TWY V UNLESS UNDER TOW.
A110-46ANG: SEE FLIP AP/1 FOR SUPPLEMENTARY ARPT INFO. HAZARDOUS BIRD COND EXIST. PHASE 1 MAY-OCT, PHASE II NOV-APR. CURRENT BIRD WATCH CONDITIONS ARE NOT REPORTED ON ATIS.
A110-47TWY W CLSD TO ACFT WITH WINGSPAN GTR THAN 118 FT UNLESS UNDER TOW.
A110-5TWY T BTN EXITS B5 & B6 CLSD TO ACFT WITH WINGSPAN GTR THAN 118 FT.
A110-50NSTD YELLOW PRK SPOT DESIGNATORS AND EQPT TOOL BOX LCTN PAINTED ON RAMP. PLEASE CTC BASE OPS OR REQ FOLLOW ME IF NOT FAMILIAR WITH PANGB PRK PROCEDURES.
A110-51TWY C3 CLSD TO ACFT WITH WINGSPAN EQUAL TO OR GTR THAN 79 FT.
A110-52PDX HAS FAC CONSTRAINTS THAT LMT ITS ABILITY TO ACCOMMODATE DIVD FLTS & MNTN THE ARPT SAFE OPN DUR IREG OPS. ACFT OPRS SHUD CTC THE ARPT DUTY MGR AT (503) 460-4236 TO COORD DIVD FLTS EXC IN THE CASE OF A DECLARED IN-FLT EMERG.
A110-53ACFT WITH WINGSPAN GREATER THAN 118 FEET ARE PROHIBITED FROM TURNING EASTBOUND ON TWY C FROM SOUTHWESTBOUND ON TWY F UNLESS UNDER TOW.
A110-54TWY A3 BTN TWY A & THE GA RAMP CLSD TO ACFT WITH WINGSPAN GTR THAN 135 FEET UNLESS UNDER TOW.
A110-57TWY C BTN TWY C6 AND TWY C8 CLSD TO ACFT WITH WINGSPAN GTR THAN 200 FT.
A110-59TWY K BTN TWY A5 & TWY V CLSD TO ACFT WINGSPAN MORE THAN 168 FT.
A110-6MIGRATORY & WINTERING FLOCKS OF LRG WATERFOWL ON & INVOF APRT. HEAVY SEAGULL ACTIVITY SEP THRU APR; EXPECT HIGH NMBR OF BIRDS YEAR AROUND; CK LCL ADVISORIES.
A110-62TWY K BTN TWY V & TWY A4 CLSD TO ACFT WINGSPAN MORE THAN 118 FT.
A110-63MILITARY: ANG: OREGON ANG E RAMP SUN SHADE OBST LGTS O/S.
A110-8NOISE ABATEMENT PROCEDURES IN EFFECT; CALL NOISE OFFICE AT 503-460-4100. RY 28L ARRIVALS ARE NOISE SENSITIVE, EXPECT APCH TO 28R WITH TRANSITION TO 28L.
A110-9180 DEGREE TURNS BY ACFT WEIGHING IN EXCESS OF 12500 LBS PROHIBITED ON RY 10L/28R, RY 03/21 AND ALL TWYS.
PORTLAND INTL (ICAO: KPDX, IATA: PDX) is a public airport located in PORTLAND, OR.
