KPAH
BARKLEY RGNL
PublicPUB

12 miles W of PADUCAH, KY
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
37° 03' 37"N 88° 46' 23"W
411' MSL
1411' MSL
01W
JET A, 100LL
LOUISVILLE (LOU)
ST LOUIS
MEMPHIS (ZME)
10/31/24-11/28/24
KPAH VFR
5:53 AM CST
Clear
10sm
54°F
43°F
30.13"Hg
080° 6kts
AO2 SLP202 T01220061 10133 20111 58009
KPAH 091153Z 08006KT 10SM CLR 12/06 A3013 RMK AO2 SLP202 T01220061 10133 20111 58009
Add Your Business

KPAH FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 119.6

ASOS

ASOS
270-744-6719
 118.375

Ground

GND/P
 121.7

Tower

LCL/P
 119.6

FAA A/FD Pages

Airport Diagrams

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KPAH
Sat, 11/9 5:40 AM CST
Sat, 11/9 6:00 AM CST - Sun, 11/10 6:00 AM CST
VFR
6:00 AM CST - 2:00 PM CST
Broken 15,000'
6sm
080° 4kts
VFR
2:00 PM CST - 7:00 PM CST
Light Showers and Rain
Overcast 6,000'
6sm
120° 5kts
MVFR
7:00 PM CST - 11:00 PM CST
Light Showers and Rain
Overcast 1,100'
6sm
140° 5kts
IFR
11:00 PM CST - 6:00 AM CST
Showers and Rain and Mist
Overcast 600'
3sm
180° 6kts
KPAH 091140Z 0912/1012 08004KT P6SM BKN150
   FM092000 12005KT P6SM -SHRA OVC060
   FM100100 14005KT P6SM -SHRA OVC011
   FM100500 18006KT 3SM SHRA BR OVC006
KPAH
Domestic
11/5/242152Z !PAH 11/003 PAH OBST TOWER LGT (ASR 1048118) 370052.00N0883650.00W (8.1NM ESE PAH) 777.9FT (438.0FT AGL) U/S 2411052152-2502052359
10/24/240059Z !PAH 10/036 PAH OBST TOWER LGT (ASR 1250480) 370238.60N0883843.40W (6.2NM E PAH) 794.9FT (330.1FT AGL) U/S 2410240059-2501222359
10/17/241348Z !PAH 10/022 PAH OBST TOWER LGT (ASR 1229578) 370352.30N0883743.50W (6.9NM E PAH) 565.3FT (215.6FT AGL) U/S 2410171348-2502141348
9/30/241304Z !PAH 09/080 PAH SVC PCL ALL U/S 2409301304-2412312200
FDC
11/6/241330Z !FDC 4/9506 PAH IAP BARKLEY RGNL, PADUCAH, KY.
ILS OR LOC RWY 5, AMDT 10E...
VOR RWY 23, AMDT 6E...
VOR RWY 5, AMDT 18C...
PROCEDURE NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
CNG VOR/DME OUT OF SERVICE. 2411061330-2411130200EST
Yes
0500-1800
BARKLEY REGIONAL AIRPORT AUTHORITY
2901 FISHER RD, PO BOX 38
WEST PADUCAH, KY 42086-1131
Phone: 270-744-0521
DENNIS ROULEAU
2901 FISHER RD, PO BOX 38
WEST PADUCAH, KY 42086-1131
Phone: 270-744-0521
LOUISVILLE FSS (LOU)
Toll Free: 1-800-WX-BRIEF
PAH
--
WHEN ATCT CLSD ACTVT MALSR RWY 05; REIL RWY 23 & 32; PAPI RWY 23 &32; HIRL RWY 05/23; MIRL RWY 14/32; TWY LGTS; LGTD WIND CONE - CTAF.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
High Pressure
None
Avionics

Runway 05/23

6500 ft. x 150 ft.
ASPH
Good
GRVD
HIGH
66 /F/C/X/T
76,000lbs
99,000lbs
170,000lbs
--
  Runway 05 Runway 23
True Heading 44°224°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 37° 03' 13"N 37° 03' 59"N
Longitude 88° 46' 53"W 88° 45' 58"W
Elevation 411' 381'
Threshold Crossing Height -- 50 ft. AGL
Visual Glide Path Angle -- 3°
Visual Slope Indicator -- P4L
Approach Lights MALSR
Centerline Lights
Runway End Identifier Lights Yes

Runway 14/32

5499 ft. x 150 ft.
ASPH
Good
GRVD
MED
52 /F/B/X/T
75,000lbs
100,000lbs
170,000lbs
--
  Runway 14 Runway 32
True Heading 139°319°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 37° 03' 59"N 37° 03' 18"N
Longitude 88° 46' 41"W 88° 45' 57"W
Elevation 392' 410'
Threshold Crossing Height -- 40 ft. AGL
Visual Glide Path Angle -- 3°
Visual Slope Indicator -- P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes
A110-1NWS ON ARPT - 270-744-6440.
A110-3SFC COND NOT MNTD 0001-0500; WET SFC COND NOT RPRTD.
A110-4FOR CD CTC MEMPHIS ARTCC AT 901-368-8453/8449.
BARKLEY RGNL (ICAO: KPAH, IATA: PAH) is a public airport located in PADUCAH, KY.
