ORCAS ISLAND - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KORS
ICAO KORSIATA ESDLocal ORS
ORCAS ISLAND
PublicPUB

1 miles N of EASTSOUND, WA, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
48° 42' 30"N 122° 54' 38"W
Elevation
35' MSL
Pattern Alt
1035' MSL
Mag Variation
16°E
Declination
17°E
Fuel
100LL
FSS
SEATTLE (SEA)
Sectional
SEATTLE
ARTCC
SEATTLE (ZSE)
Data Effective
2/19/26-3/19/26
KORS VFR
11:55 PM PST
Overcast 7,500'
Broken 6,500'
Scattered 2,000'
10sm
50°F
46°F
29.87"Hg
170° 9kts
AO2
METAR KORS 040755Z AUTO 17009KT 10SM SCT020 BKN065 OVC075 10/08 A2987 RMK AO2
+ Add Your Business

KORS FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Weather and Advisory

AWOS-3P 135.425
(360) 376-6045

Common

CTAF 128.25
ACTVT REIL RWY 16 & 34; PAPI RWY 16; MIRL RWY 16/34; TWY LGTS - CTAF. REIL RWY 16 & 34 PHOTOCELL NOT AVBL DALGT.

Approach

WHIDBEY APPROACH 118.2
WHIDBEY APPROACH 132.7

Departure

WHIDBEY DEPARTURE 118.2
WHIDBEY DEPARTURE 132.7

Terminal Area Forecast

KBLI (16nm)
Tue, 3/3 9:23 PM PST
Tue, 3/3 10:00 PM PST - Wed, 3/4 10:00 PM PST
MVFR
Temporary 10:00 PM PST - 2:00 AM PST
Overcast 4,500'
Broken 2,500'
N/A
Calm
VFR
10:00 PM PST - 7:00 AM PST
Light Showers and Rain
Overcast 7,000'
Broken 4,500'
Scattered 2,500'
6sm
180° 10kts
MVFR
7:00 AM PST - 1:00 PM PST
Light Showers and Rain
Overcast 4,000'
Broken 2,500'
Scattered 1,500'
6sm
200° 6kts
VFR
1:00 PM PST - 10:00 PM PST
Broken 6,000'
Broken 4,000'
Scattered 2,500'
6sm
200° 6kts
TAF KBLI 040523Z 0406/0506 18010KT P6SM -SHRA SCT025 BKN045 OVC070
   TEMPO 0406/0410 BKN025 OVC045
   FM041500 20006KT P6SM -SHRA SCT015 BKN025 OVC040
   FM042100 20006KT P6SM SCT025 BKN040 BKN060
KORS
EffectiveExpiresCategoryNOTAM
Domestic
3/4/26
1930Z
3/4/26
2330Z
!ORS 03/001 ORS AIRSPACE FLTCK ACFT OPS WI AN AREA DEFINED AS 5NM RADIUS OF ORS SFC-3500FT AGL ACFT CS FLC71
2603041930-2603042330
No
0800-1630
PORT OF ORCAS
P.O. BOX 53
EASTSOUND, WA 98245
Phone: 360-376-5285
CHIP LONG
PO BOX 53
EASTSOUND, WA 98245
Phone: 360-376-5285
SEATTLE FSS (SEA)
Toll Free: 1-800-WX-BRIEF
ORS
--
ACTVT REIL RWY 16 & 34; PAPI RWY 16; MIRL RWY 16/34; TWY LGTS - CTAF. REIL RWY 16 & 34 PHOTOCELL NOT AVBL DALGT.
N/A
Yes - Lighted
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
None
None
None
None
Air Freight
Air Ambulance
Charter Service
Pilot Instruction

Runway 16/34

2901 ft. x 60 ft.
ASPH
Good
AFSC
MED

12,000lbs
--
--
--
  Runway 16 Runway 34
True Heading 180°0°
Traffic Pattern Left Right
Markings NPI NPI
Markings Condition POOR POOR
Latitude 48° 42' 44"N 48° 42' 16"N
Longitude 122° 54' 38"W 122° 54' 38"W
Elevation 11' 35'
Threshold Crossing Height 35 ft. AGL 42 ft. AGL
Visual Glide Path Angle 3.48° 4°
Visual Slope Indicator P4R P2L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes
A110-2NOISE ABATEMENT PROCS IN EFCT - AMGR.
A110-3ADNL TSNT TURF TIEDOWNS S OF SEGEMENTED CIRCLE.
A110-4DEER ON & INVOF RWY.
A110-5NGT CIRCLING APCH NA FM W SIDE OF RWY.
A110-7GRASS SFC LNDG NA.
A110-8FOR CD FOR DEP FROM RWY 16/34, CTC VICTORIA TRML AT 604-586-4561.
A30-16/34RWY 34 CALM WIND RWY.
A42-16_CONDFADED.
A42-34_CONDFADED.
A43-34PAPI UNSUBL BYD 2 DEGS LEFT OF CNTRLN.
A58-163 FT SIGN 126 FT L & 19 FT FM THR; DITCH 100 FT R OF THR.
A70-100LLCREDIT CARD SELF SVC H24.
A81-APTACTVT REIL RWY 16 & 34; PAPI RWY 16; MIRL RWY 16/34; TWY LGTS - CTAF. REIL RWY 16 & 34 PHOTOCELL NOT AVBL DALGT.
E111ESTABLISHED PRIOR TO 5/15/59.
ORCAS ISLAND (ICAO: KORS, IATA: ORS) is a public airport located in EASTSOUND, WA, US.
