6/23/231547Z
|
!FDC 3/5549 OGA PART 1 OF 3 ODP SEARLE FLD, OGALLALA, NE.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 5...
CHANGE RWY 31 TAKEOFF MINIMUMS TO READ: STANDARD WITH MINIMUM CLIMB
OF 320 FT PER NM TO 4400 OR 1300-3 FOR VCOA.
VCOA:
RWY 31: OBTAIN ATC APPROVAL FOR VCOA WHEN REQUESTING IFR CLEARANCE.
CLIMB IN VISUAL CONDITIONS TO CROSS SEARLE FLD AIRPORT AT OR ABOVE
4400 BEFORE PROCEEDING ON COURSE.
TAKEOFF OBSTACLE NOTES:
NOTE: RWY 8: POLE 9 FT FROM DER, 17 FT RIGHT OF CENTERLINE, 2 FT
AGL/3247 FT MSL.
SIGN 26 FT FROM DER, 200 FT LEFT OF CENTERLINE, 2 FT AGL/3246 FT
MSL.
TREE 198 FT FROM DER, 526 FT RIGHT OF CENTERLINE, 3253 FT MSL.
POLE 234 FT FROM DER, 416 FT LEFT OF CENTERLINE, 23 FT AGL/3265 FT
MSL.
TRAVERSE WAYS, TREE BEGINNING 273 FT FROM DER, 470 FT RIGHT OF
CENTERLINE, UP TO 3257 FT MSL.
TRAVERSE WAYS BEGINNING 361 FT FROM DER, 491 FT RIGHT OF
CENTERLINE, UP TO 3258 FT MSL.
POLE, TRAVERSE WAY BEGINNING 451 FT FROM DER, 466 FT RIGHT OF
ALL OTHER DATA REMAINS AS PUBLISHED. 2306231547-2506231545EST
END PART 1 OF 3
!FDC 3/5549 OGA PART 2 OF 3 ODP SEARLE FLD, OGALLALA, NE.
CENTERLINE, UP TO 24 FT AGL/3262 FT MSL.
TRAVERSE WAYS, POLES BEGINNING 483 FT FROM DER, 460 FT RIGHT OF
CENTERLINE, UP TO 3265 FT MSL.
ANTENNA 1032 FT FROM DER, 723 FT LEFT OF CENTERLINE, 51 FT AGL/3296
FT MSL.
NOTE: RWY 13: POLE 7 FT FROM DER, 39 FT RIGHT OF CENTERLINE, 2 FT
AGL/3246 FT MSL.
POLE 11 FT FROM DER, 9 FT LEFT OF CENTERLINE, 2 FT AGL/3246 FT MSL.
TREE, POLES, TRAVERSE WAYS BEGINNING 504 FT FROM DER, 120 FT RIGHT
OF CENTERLINE, UP TO 3269 FT MSL.
TREE 742 FT FROM DER, 351 FT RIGHT OF CENTERLINE, 3290 FT MSL.
TRAVERSE WAY 759 FT FROM DER, 91 FT LEFT OF CENTERLINE, 3265 FT
MSL.
NOTE: RWY 26: TERRAIN 66 FT FROM DER, 509 FT RIGHT OF CENTERLINE,
3262 FT MSL.
FENCE 73 FT FROM DER, 109 FT LEFT OF CENTERLINE, 4 FT AGL/3262 FT
MSL.
FENCE 76 FT FROM DER, 251 FT RIGHT OF CENTERLINE, 4 FT AGL/3265 FT
MSL.
TRAVERSE WAY 196 FT FROM DER, 499 FT LEFT OF CENTERLINE, 3268 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2306231547-2506231545EST
END PART 2 OF 3
!FDC 3/5549 OGA PART 3 OF 3 ODP SEARLE FLD, OGALLALA, NE.
MSL.
AGRICULTURAL EQUIPMENT BEGINNING 203 FT FROM DER, 38 FT LEFT OF
CENTERLINE, UP TO 47 FT AGL/3301 FT MSL.
AGRICULTURAL EQUIPMENT, POLES BEGINNING 250 FT FROM DER, 45 FT
RIGHT OF CENTERLINE, UP TO 40 FT AGL/3301 FT MSL.
TERRAIN BEGINNING 2.2 NM FROM DER, 4168 FT RIGHT OF CENTERLINE, UP
TO 3724 FT MSL.
NOTE: RWY 31: POLE 9 FT FROM DER, 10 FT RIGHT OF CENTERLINE, 1 FT
AGL/3281 FT MSL.
TREE 272 FT FROM DER, 248 FT LEFT OF CENTERLINE, 3286 FT MSL.
TREE 382 FT FROM DER, 246 FT LEFT OF CENTERLINE, 3310 FT MSL.
TERRAIN, TRAVERSE WAYS, FENCES, WINDMILL, VEGETATION, TREE
BEGINNING 599 FT FROM DER, 491 FT RIGHT OF CENTERLINE, UP TO 3803
FT MSL.
TREES, BUILDING, TERRAIN, FENCES BEGINNING 859 FT FROM DER, 283 FT
LEFT OF CENTERLINE, UP TO 3711 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2306231547-2506231545EST
END PART 3 OF 3
|
