!FDC 3/4329 OBI PART 1 OF 4 ODP WOODBINE MUNI, WOODBINE, NJ.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
RWY 01: TREE, LIGHT POLES, VEGETATION BEGINNING 9 FT FROM DER, 112
FT LEFT OF CENTERLINE, UP TO 86 FT MSL. LIGHT POLES 11 FT FROM DER,
112 FT RIGHT OF CENTERLINE, 42 FT MSL. TREE, VEGETATION BEGINNING
40 FT FROM DER, 139 FT RIGHT OF CENTERLINE, UP TO 86 FT MSL. TREES
BEGINNING 130 FT FROM DER, 265 FT RIGHT OF CENTERLINE, UP TO 92 FT
MSL. TREE, VEGETATION BEGINNING 131 FT FROM DER, 187 FT LEFT OF
CENTERLINE, UP TO 87 FT MSL. TREE 188 FT FROM DER, 359 FT RIGHT OF
CENTERLINE, 95 FT MSL. TREES BEGINNING 222 FT FROM DER, 283 FT
RIGHT OF CENTERLINE, UP TO 99 FT MSL. TREES BEGINNING 228 FT FROM
DER, 320 FT LEFT OF CENTERLINE, UP TO 98 FT MSL. TREES BEGINNING
323 FT FROM DER, 292 FT LEFT OF CENTERLINE, UP TO 99 FT MSL. TREE
333 FT FROM DER, 325 FT RIGHT OF CENTERLINE, 100 FT MSL. TREES
BEGINNING 387 FT FROM DER, 289 FT RIGHT OF CENTERLINE, UP TO 102 FT
MSL. TREES BEGINNING 433 FT FROM DER, 343 FT LEFT OF CENTERLINE, UP
TO 102 FT MSL. TREES BEGINNING 550 FT FROM DER, 335 FT LEFT OF
CENTERLINE, UP TO 103 FT MSL. TREE 554 FT FROM DER, 536 FT RIGHT OF
CENTERLINE, 103 FT MSL. TREES BEGINNING 688 FT FROM DER, 8 FT RIGHT
OF CENTERLINE, UP TO 104 FT MSL. TREES BEGINNING 1013 FT FROM DER,
61 FT LEFT OF CENTERLINE, UP TO 105 FT MSL. TREES BEGINNING 1475 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2310311905-2510311905EST
END PART 1 OF 4
!FDC 3/4329 OBI PART 2 OF 4 ODP WOODBINE MUNI, WOODBINE, NJ.
FROM DER, 71 FT LEFT OF CENTERLINE, UP TO 107 FT MSL. TREES
BEGINNING 2002 FT FROM DER, 72 FT LEFT OF CENTERLINE, UP TO 109 FT
MSL. TREES BEGINNING 2101 FT FROM DER, 66 FT LEFT OF CENTERLINE, UP
TO 111 FT MSL. TREE 2275 FT FROM DER, 586 FT RIGHT OF CENTERLINE,
105 FT MSL. TREE 2413 FT FROM DER, 382 FT RIGHT OF CENTERLINE, 106
FT MSL. TREES BEGINNING 2506 FT FROM DER, 409 FT LEFT OF
CENTERLINE, UP TO 114 FT MSL. TREES BEGINNING 2611 FT FROM DER, 336
FT LEFT OF CENTERLINE, UP TO 115 FT MSL.TREE 2716 FT FROM DER, 534
FT RIGHT OF CENTERLINE, 110 FT MSL. TREES BEGINNING 2730 FT FROM
DER, 307 FT LEFT OF CENTERLINE, UP TO 116 FT MSL.
RWY 13: LIGHT POLES, SIGN BEGINNING 9 FT FROM DER, 78 FT LEFT OF
CENTERLINE, UP TO 36 FT MSL. LIGHT POLES 9 FT FROM DER, 76 FT RIGHT
OF CENTERLINE, 37 FT MSL. TREES BEGINNING 17 FT FROM DER, 213 FT
RIGHT OF CENTERLINE, UP TO 83 FT MSL. TREE 78 FT FROM DER, 209 FT
LEFT OF CENTERLINE, 46 FT MSL. TREE 96 FT FROM DER, 397 FT LEFT OF
CENTERLINE, 56 FT MSL. TREE, VEGETATION BEGINNING 154 FT FROM DER,
130 FT RIGHT OF CENTERLINE, UP TO 88 FT MSL. TREES BEGINNING 166 FT
FROM DER, 128 FT LEFT OF CENTERLINE, UP TO 86 FT MSL. TREES
BEGINNING 461 FT FROM DER, 82 FT LEFT OF CENTERLINE, UP TO 88 FT
MSL. TREES BEGINNING 510 FT FROM DER, 210 FT RIGHT OF CENTERLINE,
ALL OTHER DATA REMAINS AS PUBLISHED. 2310311905-2510311905EST
END PART 2 OF 4
!FDC 3/4329 OBI PART 3 OF 4 ODP WOODBINE MUNI, WOODBINE, NJ.
UP TO 89 FT MSL. TREES BEGINNING 914 FT FROM DER, 148 FT LEFT OF
CENTERLINE, UP TO 93 FT MSL. TREES BEGINNING 945 FT FROM DER, 11 FT
RIGHT OF CENTERLINE, UP TO 92 FT MSL. TREES BEGINNING 956 FT FROM
DER, 36 FT LEFT OF CENTERLINE, UP TO 95 FT MSL. TREES BEGINNING
1177 FT FROM DER, 12 FT RIGHT OF CENTERLINE, UP TO 96 FT MSL. TREES
BEGINNING 1523 FT FROM DER, 20 FT LEFT OF CENTERLINE, UP TO 98 FT
MSL. TREES BEGINNING 2020 FT FROM DER, 643 FT LEFT OF CENTERLINE,
UP TO 103 FT MSL. TREES BEGINNING 2077 FT FROM DER, 186 FT LEFT OF
CENTERLINE, UP TO 106 FT MSL..
RWY 19: TREE, VEGETATION BEGINNING 11 FT FROM DER, 175 FT RIGHT OF
CENTERLINE, UP TO 81 FT MSL. TREES BEGINNING 13 FT FROM DER, 122 FT
LEFT OF CENTERLINE, UP TO 61 FT MSL. TREE, VEGETATION BEGINNING 126
FT FROM DER, 200 FT LEFT OF CENTERLINE, UP TO 86 FT MSL. TREE,
VEGETATION BEGINNING 448 FT FROM DER, 9 FT RIGHT OF CENTERLINE, UP
TO 94 FT MSL. TREE 1158 FT FROM DER, 782 FT LEFT OF CENTERLINE, 87
FT MSL. TREES BEGINNING 1196 FT FROM DER, 15 FT LEFT OF CENTERLINE,
UP TO 88 FT MSL. TREES BEGINNING 2314 FT FROM DER, 458 FT LEFT OF
CENTERLINE, UP TO 90 FT MSL..
RWY 31: TREE 45 FT FROM DER, 497 FT LEFT OF CENTERLINE, 82 FT MSL.
TREES BEGINNING 85 FT FROM DER, 255 FT LEFT OF CENTERLINE, UP TO 84
ALL OTHER DATA REMAINS AS PUBLISHED. 2310311905-2510311905EST
END PART 3 OF 4
!FDC 3/4329 OBI PART 4 OF 4 ODP WOODBINE MUNI, WOODBINE, NJ.
FT MSL. VEGETATION 152 FT FROM DER, 210 FT RIGHT OF CENTERLINE, 53
FT MSL. TREES BEGINNING 181 FT FROM DER, 402 FT LEFT OF CENTERLINE,
UP TO 95 FT MSL. VEGETATION BEGINNING 230 FT FROM DER, 245 FT RIGHT
OF CENTERLINE, UP TO 59 FT MSL. TREES BEGINNING 289 FT FROM DER, 34
FT LEFT OF CENTERLINE, UP TO 100 FT MSL. TREE, VEGETATION BEGINNING
369 FT FROM DER, 317 FT RIGHT OF CENTERLINE, UP TO 86 FT MSL. TREE
505 FT FROM DER, 401 FT RIGHT OF CENTERLINE, 87 FT MSL. TREES
BEGINNING 529 FT FROM DER, 282 FT RIGHT OF CENTERLINE, UP TO 98 FT
MSL. TREE 649 FT FROM DER, 540 FT RIGHT OF CENTERLINE, 99 FT MSL.
TREES BEGINNING 652 FT FROM DER, 133 FT RIGHT OF CENTERLINE, UP TO
102 FT MSL. TREES BEGINNING 1379 FT FROM DER, 299 FT RIGHT OF
CENTERLINE, UP TO 105 FT MSL. TREES BEGINNING 1639 FT FROM DER, 12
FT RIGHT OF CENTERLINE, UP TO 106 FT MSL. TREES BEGINNING 2057 FT
FROM DER, 99 FT LEFT OF CENTERLINE, UP TO 105 FT MSL. TREES
BEGINNING 2236 FT FROM DER, 188 FT LEFT OF CENTERLINE, UP TO 114 FT
MSL. TREES BEGINNING 2536 FT FROM DER, 362 FT LEFT OF CENTERLINE,
UP TO 116 FT MSL. TREES BEGINNING 2674 FT FROM DER, 119 FT LEFT OF
CENTERLINE, UP TO 118 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2310311905-2510311905EST
