iFlightPlanner



...
No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KNYG
QUANTICO MCAF (TURNER FLD)
PrivatePVT

1 miles S of QUANTICO, VA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
38° 30' 13"N 77° 18' 18"W
10' MSL
1010' MSL
11W
JET A-1+
LEESBURG (DCA)
WASHINGTON
WASHINGTON (ZDC)
4/17/25-5/15/25
KNYG VFR
10:56 AM EDT
Clear
10sm
69°F
32°F
30.09"Hg
350° 9kts
AO2 SLP190 T0206 51011 $
KNYG 021456Z 35009KT 10SM CLR 21/ A3009 RMK AO2 SLP190 T0206 51011 $
+ Add Your Business

KNYG FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 118.6

Approach/Departure

APCH/P DEP/P
 127.05

Emergency

EMERG
 121.5

Ground

GND/P
 121.75

Tower

LCL/P
 118.6

FAA A/FD Pages

Airport Diagrams

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

Instrument Approach

Terminal Area Forecast

KNYG
Mon, 6/2 4:57 PM EDT
Mon, 6/2 5:00 PM EDT - Tue, 6/3 5:00 PM EDT
VFR
5:00 PM EDT - 11:00 PM EDT
Sky Clear
6sm
30.00"Hg
150° 6kts
VFR
Becoming 11:00 PM EDT - 5:00 PM EDT
Few 12,000'
6sm
30.06"Hg
130° 6kts
TAF KNYG 0221/0321 15006KT 9999 SKC QNH3000INS
   BECMG 0303/0305 13006KT 9999 FEW120 QNH3007INS LAST NO AMDS AFT 0223 NEXT 0309 AUTOMATED SENSOR METWATCH 0223 TIL0312 TX28/0321Z TN12/0305Z
KNYG
Military
5/23/251200Z AERODROME R6608C ACTIVE SFC TO 4,499FT
5/22/251330Z AERODROME QUIET HOURS IN EFFECT. NO AIRCRAFT OR VEHICLE GROUND OPERATIONS. NO FLIGHT OPERATIONS IN THE CDSA WITHIN 3 NM OF KNYG OR BELOW 2,500 FT AGL, TO INCLUDE TOUCH AND GO LANDINGS, LOW APPROACHES, LOW ALTITUDE FLYOVERS, DEPARTURES AND ARRIVALS EXCEPT DECLARED IN-FLIGHT EMERGENCIES, BANNER MISSIONS AND HMX-1 ACFT IN DIRECT SPT OF POTUS/VPOTUS, AND JOSAC MSNS SUPPORTING DV CODE 6 AND ABOVE
5/21/251030Z !KNYG M0246/25 NYG SVC AIRPORT SURVEILLANCE RADAR U/S 2505211030-2505211230
5/20/252045Z AERODROME MCAF QUANTICO CLSD EXC HMX-1 ROTARY WING & V-22. CLASS D SERVICES UNAVAILABLE. QUANTICO RADAR SERVICES AVAILABLE. FOR RADAR SERVICES OUTSIDE THESE HOURS, CONTACT POTOMAC APPROACH AT 128.525
5/20/251227Z !KNYG M0247/25 NYG APRON NORTH RAMP WORK IN PROGRESS HVY EQPT AND PERSONNEL 170FT FROM RWY EDGE (285FT WEST RWY20 THRESHOLD) 2505201227-2506132100
5/19/251125Z M0244/25 NOTAMC M0242/25
5/19/251000Z !KNYG M0233/25 NYG TWY D CLSD TO ACFT OPS. PERSONNEL AND EQUIPMENT CONDUCTING CERTIFICATION OF TWY SURFACE 2505191000-2505231900
4/11/251309Z !KNYG M0184/25 NYG TWY A CLSD 2504111309-2507082359
3/10/251735Z !KNYG M0138/25 NYG TWY E LOCATION SIGN SOUTH SIDE NOT LGTD 2503101735-2506062359
3/10/251735Z !KNYG M0137/25 NYG RWY 02 3000FT DIST REMAINING SIGN RIGHT SIDE NOT LGTD 2503101735-2506062359
3/10/251734Z !KNYG M0136/25 NYG RWY 20 1000FT DIST REMAINING SIGN LEFT SIDE NOT LGTD 2503101734-2506062359
3/10/251734Z !KNYG M0135/25 NYG RWY 20 3000FT DIST REMAINING SIGN E SIDE NOT LGTD 2503101734-2506062359
3/10/251734Z !KNYG M0134/25 NYG RWY 20 1000FT DIST REMAINING SIGN RIGHT SIDE NOT LGTD 2503101734-2506062359
3/10/251733Z !KNYG M0133/25 NYG RWY 02 1000FT DIST REMAINING SIGN E SIDE NOT LGTD 2503101733-2506062359
3/10/251733Z !KNYG M0132/25 NYG RWY 02 3000FT DIST REMAINING SIGN LEFT SIDE NOT LGTD 2503101733-2506062359
3/10/251729Z SOUTH RAMP SOUTHERN MOST TAXILANE CLOSED TO ACFT OPS. FIXED OBSTACLES 50FT FROM CENTERLINE.
Yes
MON-THU 1300-0000Z++
FRI 1300-2200Z++
SAT SUN HOLS CLSD
US NAVY
OCEANOGRAPHIC OFC-CODE 3142
WASHINGTON, DC 20373
COMMANDING OFFICER
MARINE CORPS AIR STATION
QUANTICO, VA 22134
Phone: 703-784-2084
LEESBURG FSS (DCA)
Toll Free: 1-800-WX-BRIEF
DCA
--
WHEN TWR CLSD ACTVT REILS RWY 02 & 20; PAPI RWY 02; HIRL RWY 02/20; CL RWY 02; TWY LGTS - CTAF. TO ACTVT & INCR INTS CMSND KEY 118.6 7 TIMES HIGH, 5 TIMES MED, 3 TIMES LOW.
N/A
N/A
No
No
None
No
None
None
None
High Pressure
None

Runway 02/20

4250 ft. x 184 ft.

PEM
GRVD
HIGH
63 /R/C/W/T
--
--
--
--
  Runway 02 Runway 20
True Heading 15°195°
Traffic Pattern
Markings PIR PIR
Markings Condition FAIR FAIR
Latitude 38° 29' 53"N 38° 30' 33"N
Longitude 77° 18' 25"W 77° 18' 11"W
Elevation 9' 10'
Threshold Crossing Height 35 ft. AGL --
Visual Glide Path Angle 3° --
Visual Slope Indicator P4L --
Approach Lights
Centerline Lights Yes
Runway End Identifier Lights Yes Yes
A110-13FUEL: A++; LTD SUP. EXP NO MORE THAN 10K OVER PPR.
A110-14TRAN ALERT: NO TRAN MAINT AVBL. REQUIRE QUALIFIED CREW MEMBER TO ASSIST IN COLD REFUELING.
A110-16BIRD HAZ VCNTY RWY 02-20 SR-SS. HVY MIGRATORY BIRD ACT OCT-MAR, HVY OSPREY ACT MAR-JUL, HVY EAGLE ACT DEC-JUL.
A110-17NS ABTMT: THE AREA IN AND ARND THE QUANTICO CLASS D AIRSPACE IS NOISE SENSITIVE. COPTER TRANSIT QUANTICO CLASS D AIRSPACE AT OR ABV 1000 FT AGL.
A110-18MISC: CAT II CRASH/FIRE RESCUE SVC.
A110-19REMARKS: MCAF QUANTICO HAS NO PROVISIONS FOR SPACE A PASSENGERS. SPACE A PASSENGERS CANNOT BE ON-LOADED OR OFF-LOADED DUE TO SECURITY ISSUES.
A110-20MISC: MCAF QUANTICO AND R-6608 LIE WITH THE WASHINGTON ADIZ. PILOTS MUST ADHERE TO ADIZ RPRTG PROCS IN BOTH THESE AREAS. TWY A LTD TO R/W DALGT VFR ONLY.
A110-22CUSTOMS/AGRICULTURE/IMMIGRATION: CSTMS/AG/IMG - AVAILABLE WITH 72 HR PN BY PPR ONLY.
A110-23RSTD: ALL TRAN ACFT 24 HR PPR; BASE OPS DSN 278-2085/1459, OR C703-784-2085/1459. AFTER 2200Z++ AND ON WEEKEND CALL DSN 378-0920, C703-432-0920 OR C703-675-3623 FOR PPR. NO TRAN ACFT OPS OUTSIDE PUBL HR WO MCAF QUANTICO CO APVL.
A110-25CAUTION: NO MANDATORY RWY VFR HOLD POSITION SIGNS CO-LOCATED W/MARKINGS ON TWYS A, B, AND D. RWY 02 OVRN 100 FT. RWY 20 NO OVRN.
A110-26FOR CD WHEN NYG ATCT/APCH ARE CLSD CTC POTOMAC APCH AT 866-709-4993.
A110-27RWY: NO 180 DEG TURNS ON RWY ASP.
A110-28MISC: 180 DEG TURNS ONLY ON CONC EOR.
A110-29MISC: NO STAGGERED ACFT DEVS FR RCL.
A110-30CAUTION: TWY D SFC CONSISTS OF AM-2 ALUMINUM MATTING WITH NON-SKID ALL WX COATING; NO EDGE LGTNG ON TWY D. TWY B EDGE LGT NON STD FIRST 100 FT AT RWY ENTERANCE/EXIT (NORTH EDGE) LOCATED 20 FT FROM USABLE PAVEMENT.
A110-31C-17 LANDING ZONE MARKED BUT NOT CERTIFIED. ASSAULT LDGS NA.
QUANTICO MCAF (TURNER FLD) (ICAO: KNYG, IATA: NYG) is a private airport located in QUANTICO, VA.
