No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KNUQ
MOFFETT FEDERAL AIRFIELD
PrivatePVT

3 miles N of MOUNTAIN VIEW, CA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
37° 24' 58"N 122° 02' 57"W
37' MSL
1037' MSL
16E
JET A
OAKLAND (OAK)
SAN FRANCISCO
OAKLAND (ZOA)
4/17/25-5/15/25
KNUQ VFR
11:30 PM PDT
No Clouds
7sm
59°F
54°F
29.98"Hg
030° 6kts
AO2
KNUQ 030630Z AUTO 03006KT 7SM 15/12 A2998 RMK AO2
+ Add Your Business

KNUQ FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 119.55

ATIS

ATIS
 124.175

AWOS-3PT

AWOS-3PT
650-386-0655
 124.175

Emergency

EMERG
 121.5

Ground

GND/P
 121.85

Tower

LCL/P
 119.55

Terminal Area Forecast

KSJC (7nm)
Mon, 6/2 10:20 PM PDT
Mon, 6/2 11:00 PM PDT - Tue, 6/3 11:00 PM PDT
VFR
11:00 PM PDT - 8:00 AM PDT
Few 1,000'
6sm
310° 5kts
IFR
Temporary 4:00 AM PDT - 8:00 AM PDT
Broken 900'
N/A
Calm
MVFR
8:00 AM PDT - 11:00 AM PDT
Broken 1,000'
6sm
170° 4kts
VFR
11:00 AM PDT - 2:00 PM PDT
Sky Clear
6sm
VRB° 4kts
VFR
2:00 PM PDT - 8:00 PM PDT
Sky Clear
6sm
300° 12kts
VFR
8:00 PM PDT - 11:00 PM PDT
Sky Clear
6sm
310° 8kts
KSJC 030520Z 0306/0406 31005KT P6SM FEW010
   TEMPO 0311/0315 BKN009
   FM031500 17004KT P6SM BKN010
   FM031800 VRB04KT P6SM SKC
   FM032100 30012KT P6SM SKC
   FM040300 31008KT P6SM SKC
KNUQ
FDC
5/17/251300Z !FDC 5/0689 NUQ SID MOFFETT FEDERAL AIRFIELD, MOUNTAIN VIEW, CA.
WOODSIDE TWO DEPARTURE...
TAKEOFF MINIMUMS: RWY 14L, 300-1 WITH A MINIMUM CLIMB OF 402FT PER NM TO 5000. ADD TAKEOFF OBSTACLE NOTE: RWY 14L, TEMPORARY CRANE 2983FT FROM DER, 1232FT LEFT OF CENTERLINE, 180FT AGL/212FT MSL (2022-AWP-1840-OE). ALL OTHER DATA REMAINS AS PUBLISHED. 2505171300-2506171447EST
5/17/251300Z !FDC 5/0688 NUQ SID MOFFETT FEDERAL AIRFIELD, MOUNTAIN VIEW, CA.
HOOKS TWO DEPARTURE...
TAKEOFF MINIMUMS: RWY 14L, 300-1 WITH A MINIMUM CLIMB OF 328FT PER NM TO 6000. ADD TAKEOFF OBSTACLE NOTE: RWY 14L, TEMPORARY CRANE 2983FT FROM DER, 1232FT LEFT OF CENTERLINE, 180FT AGL/212FT MSL (2022-AWP-1840-OE). ALL OTHER DATA REMAINS AS PUBLISHED. 2505171300-2506171447EST
11/27/241540Z !FDC 4/9219 NUQ IAP MOFFETT FEDERAL AIRFIELD, MOUNTAIN VIEW, CA.
RNAV (GPS) RWY 32L, AMDT 1A...
LNAV/VNAV DA 502/ HAT 471 ALL CATS, VIS ALL CATS 1 3/8. BUILDING 178 MSL 5555FT S OF RWY 32L (2018-AWP-13987 THRU 13993-OE PERM BLDG).
2411271540-2611271540EST
Military
5/19/251506Z !KNUQ M0084/25 NUQ RWY 32R ALS U/S 2505191506-2505300100
5/19/251503Z BIRD ACT INCREASED NE SIDE
Yes
ALL
NASA AMES RESEARCH CENTER
AIRFIELD MGT OFS, 158 CODY RD
MOFFETT FIELD, CA 94035-1000
Phone: 650-604-0677
DEREK PRISTAVOK
158 CODY RD, ROOM 103
MOFFETT FIELD, CA 94035-1000
Phone: 650-386-0680
OAKLAND FSS (OAK)
Toll Free: 1-800-WX-BRIEF
NUQ
--
WHEN TWR CLSD, ACTVT REIL RWY 14L; MALSR RWY 32R; PAPI RWY 14L & 32R; HIRL RWY 14L/32R & 14R/32L- CTAF.
N/A
Yes - Lighted
Yes
No
Tie-Down
Landing Rights Airport
NOT an Airport of Entry
None
None
None
None
None

Runway 14L/32R

9197 ft. x 200 ft.

CONC
NONE
HIGH
63 /R/B/W/T
--
--
--
--
  Runway 14L Runway 32R
True Heading 157°337°
Traffic Pattern
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 37° 25' 44"N 37° 24' 20"N
Longitude 122° 03' 17"W 122° 02' 33"W
Elevation 6' 32'
Threshold Crossing Height 53 ft. AGL 55 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALSR
Centerline Lights No No
Runway End Identifier Lights Yes

Runway 14R/32L

8121 ft. x 200 ft.

ASPH
NONE
HIGH
33 /R/B/W/T
--
--
--
--
  Runway 14R Runway 32L
True Heading 157°337°
Traffic Pattern
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 37° 25' 31"N 37° 24' 17"N
Longitude 122° 03' 18"W 122° 02' 40"W
Elevation 4' 36'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1BEARING STRENGTH RY 14L: S64 T110 ST144 SBTT410 TDT528 TRT390).
A110-12CSTMS/AG/IMG - CSTMS, AG, IMG AVBL ONLY BY PN MON-FRI 1700-0100Z++ EXC HOL.
A110-16CAUTION - POSSIBLE STRONG UPDRAFT VCNTY NASA/AMES WIND TUNNEL LCTD W SIDE OF AFLD. BIRD HAZ.
A110-17NS ABTMT - NO JET DEP RWY 14L/R BTN HRS OF 0700-1300Z++.
A110-2BEARING STRENGTH RY 32R: S82 T142 ST175 TT300 DDT609, TDT814.
A110-26CAUTION: AIRPORT SIGNAGE UNAVBL TO INCL RWY, TWY, INST, LOC, DIREC, DESTN, AND INFO SIGNS.
A110-28BIRD HAZ LIKELY TO BE HIGHEST FROM SEP TO MAR (BASH PHASE II) AND LOWER FROM APR TO AUG (PHASE I).
A110-29JET A++ FUEL AVBL. JP-8 NOT AVBL.
A110-3JASU - (AM32A-60) (AM32A-86).
A110-30RSTD - TWY D CLSD DRG NON-DALGT HRS.
A110-31FOR CD WHEN ATCT IS CLSD CTC NORCAL APCH AT 916-361-3748.
A110-32MISC - UPDATE ETA +15 MINS AT LEAST 2 HRS PRIOR ARR. TWR FREQ MONITOR BY NASA FIRE/SECURITY.
A110-33MILITARY REMARKS - ANG OPR 1330-2400Z++ MON-THU AND EVERY OTR FRI. CLSD SAT, SUN AND HOL. COMD POST C650-603-9333. PRKG ON ANG RAMP IS PPR OFFL BUS AND PRE-CDN WITH 129 OSF/OSA AT C650-603-8234 RQRD. LTD MAINT AND FUEL SUPPORT FOR C130 AND H60 ACFT, NO PAX AND NO TSNT ALERT SVC. LTD RAMP SPACE. TSNT ACFT MAY BE DIV TO NASA FBO. AIRFIELD MGR DOES NOT STORE COMSEC.
A110-36MILITARY SERVICES - FUEL AVBL MON-FRI 1700-0200Z++.
A110-5FLUID - SP LOX - LTD AVBL.
A110-9RSTD - PPR ALFD OPS OPR 24 HRS, TRAN ALERT SVC 24 HRS, C650-386-0677. RECOMMEND SID, EXP DELAY FOR RADAR VECTORS.
MOFFETT FEDERAL AIRFIELD (ICAO: KNUQ, IATA: NUQ) is a private airport located in MOUNTAIN VIEW, CA.
