No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KNQX
KEY WEST NAS (BOCA CHICA FLD)
PrivatePVT

4 miles E of KEY WEST, FL
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
24° 34' 29"N 81° 41' 12"W
6' MSL
1006' MSL
06W
JP-5
MIAMI (MIA)
MIAMI
MIAMI (ZMA)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

KNQX FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- --

Approach/Departure

APCH/P DEP/P
 124.025
APCH/S DEP/S
 126.575

Clearance Delivery

CD/P
 121.2

Emergency

EMERG
 121.5

Ground

GND/P
 121.7

Tower

LCL/P
 118.575

Terminal Area Forecast

No TAF is available for this location.
KNQX
Military
1/14/251710Z M0008/25 NOTAMC M0007/25
1/14/251308Z AIRFIELD CLOSURE FROM 17JAN25 AT 1900L, UNTIL REOPEN ON 21JAN25 AT 0700L.
1/13/251522Z M0005/25 NOTAMC M0003/25
12/30/241438Z RY 4 SHORT FIELD ARRESTING GEAR UNAVAILABLE UFN.
12/26/241650Z ALS OTS UFN. SEE FLIP FOR APPLICABLE APPROACH MINIMUMS.
12/3/241731Z LOW BARRICADES ON HOLD SHORT MARKINGS BETWEEN TWY HOTEL AND APPROACH END RY 22 UTILIZE CAUTION.
12/3/241729Z WHITE OBSTRUCTION LIGHT 0.25 MILES NORTH OF FIGHTER RAMP OTS UFN.
12/3/241701Z BOCA CHICA FIELD WILL BE TEMPORARILY REDUCING FIELD HOURS. AIRFIELD HOURS ARE NOW MONDAY THROUGH SATURDAY 0700-1900. SUNDAY CLOSED.
Yes
1200-0300Z
OT BY NOTAM; CTC BASE OPS DSN 483-2770, C305-293-2770, FAX DSN 483-2771, C305-293-2771. BASE OPS NOT STAFFED OUTSIDE FLD HR. SEE FLIP AP/1 SUPPLEMENTARY ARPT RMK AND AP/1A.
US NAVY
OCEANOGRAPHIC OFC-CODE 3142
WASHINGTON, DC 20373
COMMANDING OFFICER
NAVAL AIR STATION
KEY WEST, FL 33040
Phone: 305-293-2770
MIAMI FSS (MIA)
Toll Free: 1-800-WX-BRIEF
MIA
--
AVBL DURG OPS HRS.
N/A
N/A
No
No
None
No
0
0
0
0
0
0
None
None
None
None
None

Runway 04/22

7001 ft. x 150 ft.
PEM
Fair
NONE
HIGH
40 /F/C/W/T
--
--
--
--
  Runway 04 Runway 22
True Heading 32°212°
Traffic Pattern
Markings PIR NPI
Markings Condition GOOD GOOD
Latitude 24° 33' 57"N 24° 34' 56"N
Longitude 81° 41' 45"W 81° 41' 06"W
Elevation 3' 6'
Threshold Crossing Height 35 ft. AGL 44 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 08/26

10001 ft. x 200 ft.
PEM
Fair
NONE
HIGH
53 /R/A/W/T
--
--
--
--
  Runway 08 Runway 26
True Heading 73°253°
Traffic Pattern
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 24° 34' 21"N 24° 34' 50"N
Longitude 81° 42' 00"W 81° 40' 17"W
Elevation 4' 4'
Threshold Crossing Height 43 ft. AGL 43 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights ALSF1
Centerline Lights
Runway End Identifier Lights

Runway 14/32

7000 ft. x 150 ft.
PEM
Fair
NONE
HIGH
47 /R/B/W/T
--
--
--
--
  Runway 14 Runway 32
True Heading 131°311°
Traffic Pattern
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 24° 34' 44"N 24° 33' 59"N
Longitude 81° 41' 32"W 81° 40' 35"W
Elevation 3' 3'
Threshold Crossing Height 45 ft. AGL 45 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-10A-GEAR: ALL E-28(B) SHORT FLD A-G IN RAISED POSN. EXC SHORT FLD A-G DUTY RWY DERIGGED.
A110-11JASU: (NC-10) (MSU-200)
A110-13FLUID: SP
A110-14OIL: -O-128-156
A110-16RSTD: UNLGTD RAMP PARL TO TWY L.
A110-18TFC PAT: REDUCED RWY SEPARATION STD IN EFF USN/USMC ACFT.
A110-19CSTMS/AG/IMG: AVLB 1200-2000Z++ MON - SAT, WITH PRIOR COORDINATION. ACFT REQ INSPECTIONS MUST ANNOTATE ON PPR AND NOTIFY NAVY APP WHEN IN RDO CTC WITH UPDATED ETA AND REQUEST CSTMS COORDINATION, FAILURE MAY CAUSE UNDUE DELAYS WITH CSTMS LIMITED RESOURCES.
A110-20RSTD: PPR CTC AIR TERMINAL DSN 483-2769/2779, 305-293-2769/2779, FAX DSN 483-2355, C305-293-2355.
A110-21CAUTION: UNLGT RAMP PARL TO TWY I; R2916 TETHERED AEROSTAT RADAR SYSTEM OPS CONT TO 14000; KEY WEST NAS & KEY WEST INTL HAVE ADJ CLASS D; CIVIL TFC SW & NW SECTS KEY WEST NAS CLASS D; BIRD HAZ; UNMRK/UNLGT TWY OBSTN.
A110-24HAZARDOUS CARGO, TRANSIENT RAMP, AND FIGHTER RAMP LABELS.
A110-25HOT CARGO PAD UNLIT; DAY USE ONLY.
A110-26RSTD: PPR IS VALID FOR +/- 1 HR OF PROPOSED ETA. IF OUTSIDE OF ETA SLOT, CTC AIR TRML TO UPDATE PPR.
A110-27MISC: FIGHTER ACFT OPS DLY M-SA 0800-1700. TRAN ACFT PRAC APCH NOT TO INTERFERE BASIS; PPR FOR COPTER LDG TRUMBO PT - CTC BASE OPS 15 MIN PRIOR TO ETA.
A110-29SAR ONLY AVBL ON SAT-SUN WITH PRIOR CDN AND SKED ASP BY FRI PRIOR TO 1300Z++.
A110-30TRAN ALERT: EXP SVC DELAYS; NO PRIORITY BASIS; LTD MAINT 1200-2100Z++ MON-FRI; TRANS ACFT RQRG FUEL PRVD QLFYD PSNL; FLEET SVC, POTABLE WATER & BASE TRNSPN NA; CLSD FED HOL.
A110-32RSTD: CIV ACFT LDG PMT INFO - AMGR 305-293-2250; 305-293-2779.
A110-33CAUTION: RWY 04/22, 7 FT OBST 87 FT WEST OF CNTRLN. FLOLS. 758 FT FM APCH END RWY 04, DER RWY 22. ONLY C-130 (WINGSPAN 32 FT) TYPE ACFT OR SMLR MAY OPR FOR LDG AND TKOF. ALL ACFT MAY TAXI DOWN RWY 22 TIL THE DER A-G.
A110-34MISC: EV THU ALL APCHS PRIOR TO 1030L WILL BE IAW IFR PROCS.
KEY WEST NAS (BOCA CHICA FLD) (ICAO: KNQX, IATA: NQX) is a private airport located in KEY WEST, FL.
