KMZJ
PINAL AIRPARK
PublicPUB

7 miles NW of MARANA, AZ
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
32° 30' 35"N 111° 19' 31"W
1893' MSL
2893' MSL
12E
JET A, 100LL
PRESCOTT (PRC)
PHOENIX
ALBUQUERQUE (ZAB)
10/31/24-11/28/24
KMZJ VFR
4:35 AM MST
Clear
10sm
39°F
30°F
30.05"Hg
150° 4kts
AO2
KMZJ 091135Z AUTO 15004KT 10SM CLR 04/M01 A3005 RMK AO2
Add Your Business

KMZJ FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
123.05 123.05

AWOS-3PT

AWOS-3PT
520-682-3519
 130.375

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

  • No Documents

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

  • No Documents

Terminal Area Forecast

KTUS (29nm)
Sat, 11/9 4:20 AM MST
Sat, 11/9 5:00 AM MST - Sun, 11/10 5:00 AM MST
VFR
5:00 AM MST - 12:00 PM MST
Sky Clear
6sm
140° 7kts
VFR
12:00 PM MST - 9:00 PM MST
Sky Clear
6sm
350° 7kts
VFR
9:00 PM MST - 5:00 AM MST
Sky Clear
6sm
150° 5kts
KTUS 091120Z 0912/1012 14007KT P6SM SKC
   FM091900 35007KT P6SM SKC
   FM100400 15005KT P6SM SKC
KMZJ
Domestic
9/23/241300Z !MZJ 09/006 MZJ OBST CRANE (ASN 2024-AWP-1509-NRA)
323040N1111914W (0.3NM ENE MZJ) 2112FT (225FT AGL) LGTD
2409231300-2411222359
9/23/241300Z !MZJ 09/005 MZJ OBST CRANE (ASN 2024-AWP-1508-NRA) 323038N1111911W (0.3NM E MZJ) 2111FT (225FT AGL) LGTD 2409231300-2411222359
9/23/241300Z !MZJ 09/004 MZJ OBST CRANE (ASN 2024-AWP-1507-NRA) 323035N1111915W (0.2NM E MZJ) 2112FT (225FT AGL) LGTD 2409231300-2411222359
9/23/241300Z !MZJ 09/003 MZJ OBST CRANE (ASN 2024-AWP-1506-NRA) 323030N1111909W (0.3NM ESE MZJ) 2114FT (225FT AGL) LGTD 2409231300-2411222359
9/23/241300Z !MZJ 09/002 MZJ OBST CRANE (ASN 2024-AWP-1505-NRA) 323036N1111901W (0.4NM E MZJ) 2114FT (225FT AGL) LGTD DLY 1300-2359 2409231300-2411222359
9/23/241300Z !MZJ 09/001 MZJ OBST CRANE (ASN 2024-AWP-1504-NRA)
323044N1111910W (0.3NM ENE MZJ) 2114FT (225FT AGL) FLAGGED DLY
1300-2359 2409231300-2411222359
4/16/240500Z !MZJ 04/008 MZJ AIRSPACE SEE ZAB 01/208 PJE 2404160500-2601190500
No
0700-1530
PINAL COUNTY
31 NORTH PINAL
FLORENCE, AZ 85232
Phone: 520-382-8052
JIM PETTY
P.O. BOX 727, BOX #91
FLORENCE, AZ 85132
Phone: 520-866-6545
PRESCOTT FSS (PRC)
Toll Free: 1-800-WX-BRIEF
MZJ
--
--
N/A
Yes - Lighted
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
None
High & Low Pressure
None

Runway 12/30

6849 ft. x 150 ft.
ASPH
Good
NONE
MED

68,000lbs
100,000lbs
270,000lbs
500,000lbs
  Runway 12 Runway 30
True Heading 135°315°
Traffic Pattern Left Right
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 32° 30' 59"N 32° 30' 12"N
Longitude 111° 19' 60"W 111° 19' 03"W
Elevation 1,875' 1,893'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No
A110-1NUMEROUS CONTROLLED VEHICLES CROSSING RWY 12/30.
A110-10RWY 12 PREFERRED CALM WIND RWY.
A110-11RSTD: PPR FOR TRAN ACFT TO NATIONAL GUARD COMPLEX/SILVER BELL NGHP PHONE DSN 853-5931, C520-750-5931.
A110-12TWY C CLSD INDEFLY.
A110-13AWOS FREQ-130.375, PHONE:520-682-3519. OPERATED BY PARACHUTE JUMP SCHOOL.
A110-14WILDLIFE ON OR INVOF ARPT.
A110-16FOR CD CTC TUCSON APCH AT 520-829-6121.
A110-3EXTENSIVE MILITARY HELICOPTER TRAINING 0700-2300 EXCEPT HOLIDAYS.
A110-4BE ALERT TO 10 FT OPEN CHANNEL AT 1000 FT FM RWY 12 END.
A110-5EXTENSIVE MILITARY PARACHUTE TRAINING HIGH & LOW LEVELS ALL HOURS. PARACHUTE JUMP AREA LCTD SW OF RWY 12/30.
A110-7STRAIGHT-IN ARRIVALS CONTACT UNICOM WHEN 5 MI OUT.
A110-9ACFT STORAGE/OVERNIGHT FEE CTC 520-682-4181 EXTN 5755.
PINAL AIRPARK (ICAO: KMZJ, IATA: MZJ) is a public airport located in MARANA, AZ.
