No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KMTN
MARTIN STATE
PublicPUB

9 miles E of BALTIMORE, MD
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
39° 19' 32"N 76° 24' 50"W
22' MSL
1022' MSL
11W
JET A (FSII), 100LL
LEESBURG (DCA)
WASHINGTON
WASHINGTON (ZDC)
10/31/24-11/28/24
KMTN VFR
6:54 AM EST
Clear
10sm
46°F
27°F
30.37"Hg
350° 3kts
KMTN 091154Z 35003KT 10SM CLR 08/M03 A3037
Add Your Business

KMTN FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 121.3

ATIS

ATIS
 124.925

AWOS-3PT

AWOS-3PT
410-682-8848
 124.925

Emergency

EMERG
 121.5

Ground

GND/P
 121.8

Tower

LCL/P
 121.3

Other

COMD POST
175 WG
 139.6

Terminal Area Forecast

KMTN
Sat, 11/9 6:20 AM EST
Sat, 11/9 7:00 AM EST - Sun, 11/10 7:00 AM EST
VFR
7:00 AM EST - 8:00 AM EST
Sky Clear
6sm
340° 8kts
Gusts 16kts
VFR
8:00 AM EST - 11:00 AM EST
Sky Clear
6sm
010° 10kts
Gusts 18kts
VFR
11:00 AM EST - 10:00 PM EST
Few 25,000'
6sm
020° 6kts
VFR
10:00 PM EST - 4:00 AM EST
Scattered 25,000'
6sm
060° 3kts
VFR
4:00 AM EST - 7:00 AM EST
Broken 25,000'
Few 15,000'
6sm
140° 3kts
KMTN 091120Z 0912/1012 34008G16KT P6SM SKC
   FM091300 01010G18KT P6SM SKC
   FM091600 02006KT P6SM FEW250
   FM100300 06003KT P6SM SCT250
   FM100900 14003KT P6SM FEW150 BKN250
KMTN
Domestic
10/17/241100Z !MTN 10/010 MTN OBST CRANE (ASN UNKNOWN) 392006N0762507W (.5NM NE MTN)
128FT (110FT AGL) FLAGGED AND LGTD THU FRI MON TUE WED 1100-2200 2410171100-2411152200
9/28/240705Z !MTN 09/044 MTN OBST TOWER LGT (ASR 1262392) 392316.10N0763245.60W (7.1NM WNW MTN) 672.9FT (296.9FT AGL) U/S 2409280705-2412270400
9/4/241858Z !MTN 09/005 MTN AIRSPACE SEE FDC 4/1783, 4/1789, 4/9433 ZDC SECURITY INSTRUCTIONS 2409041858-PERM
8/15/240042Z !MTN 08/034 MTN NAV ILS RWY 33 DME U/S 2408150042-2412242355
8/15/240041Z !MTN 08/033 MTN NAV ILS RWY 15 DME U/S 2408150041-2412242355
8/6/241834Z !MTN 08/014 MTN NAV LOC RWY 15 DME U/S 2408061834-2502062111EST
7/27/241000Z !MTN 07/018 MTN RWY 15/33 150FT WIDE WITH 15FT SHOULDERS 2407271000-PERM
FDC
10/29/240111Z !FDC 4/5339 MTN IAP MARTIN STATE, BALTIMORE, MD.
LOC RWY 15, AMDT 3D...
ALTERNATE MINIMUMS NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
EMI VORTAC UNMONITORED. 2410290111-2411290111EST
8/12/242047Z !FDC 4/7265 MTN IAP MARTIN STATE, BALTIMORE, MD.
RNAV (GPS) RWY 15, AMDT 1C...
NOTE: VISUAL SEGMENT - OBSTACLES. DISREGARD VDA 3.10/TCH 55 AND VGSI AND DESCENT ANGLE NOT COINCIDENT.
2408122047-2608122047EST
8/9/241648Z !FDC 4/5977 MTN SID MARTIN STATE, BALTIMORE, MD.
TERPZ EIGHT DEPARTURE (RNAV)...
DO NOT FILE CLTCH TRANSITION, ATC ASSIGNED ONLY.
2408091648-2608091648EST
1/12/241440Z !FDC 4/3229 MTN IAP MARTIN STATE, BALTIMORE, MD.
LOC RWY 15, AMDT 3D...
PROCEDURE NA WHEN ATCT CLOSED.
2401121440-2601121440EST
Yes
0600-2300
MAA
BOX 1 701 WILSON PT RD
BALTIMORE, MD 21220
Phone: 410-682-8800
HAROLD A. FOWLER
BOX 1, 701 WILSON POINT RD
BALTIMORE, MD 21220
Phone: 410-682-8800
LEESBURG FSS (DCA)
Toll Free: 1-800-WX-BRIEF
MTN
--
DUSK-DAWN. WHEN ATCT CLSD ACTVT REIL RWYS 15 & 33; HIRL RWY 15/33 - CTAF. WHEN ATCT CLSD ACTVT TWY F LGTS - UNICOM.
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Minor
Minor
None
None
Air Ambulance
Avionics
Charter Service
Pilot Instruction
Aircraft Rental

Runway 15/33

6997 ft. x 180 ft.
ASPH
Good
GRVD
HIGH

65,000lbs
82,000lbs
140,000lbs
--
  Runway 15 Runway 33
True Heading 135°315°
Traffic Pattern Left Left
Markings NPI PIR
Markings Condition GOOD GOOD
Latitude 39° 19' 57"N 39° 19' 08"N
Longitude 76° 25' 21"W 76° 24' 18"W
Elevation 21' 9'
Threshold Crossing Height 37 ft. AGL 48 ft. AGL
Visual Glide Path Angle 4.01° 2.91°
Visual Slope Indicator PSIL PSIL
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes

Runway H1

60 ft. x 60 ft.

CONC
NONE


--
--
--
--
  Runway H1 Runway
True Heading 99°279°
Traffic Pattern
Markings
Markings Condition
Latitude 39° 19' 36"N N/A
Longitude 76° 25' 13"W N/A
Elevation 15' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1NOISE ABATEMENT PROCS IN EFCT. WHEN ATCT CLSD NO PRACTICE LNDGS OR APCHS.
A110-10BEARING STRENGTH RWY 15/33: ST175.
A110-12CAUTION: BASH II IN EFFECT AUG-JAN.
A110-13RMKS-ANG: CALL COMD POST/RAVEN OPS 275.500 OR 139.900 10 MIN PRIOR TO LNDG.
A110-14RMKS-ANG: NO SPACE A, FLEET SVC, OR TRAN QTRS AVBL. PPR AFTER DUTY HR RQR OG/CC APVL.
A110-15RMKS-ANG: C-5/C-17 ACFT RSTRD TO TWY A.
A110-16RMKS-ANG: PPR FOR SVC AND USE OF ANG PRK RAMP ONLY, DSN 243-6630/6637/6444, C410-918-6630/6637/6444; AFTER DUTY HR CTC C410-698-8947.
A110-17FOR CD WHEN TWR CLSD CTC POTOMAC APCH AT 866-429-5882.
A110-18ARFF SVCS AVBL 24 HRS DAILY. FOR ARFF SVCS WHEN ATCT CLSD CTC ARFF STATION; CTAF OR 410-918-6257 / 410-918-6911.
A110-19NO ACFT ACCESS TO TWY S FM STRAWBERRY POINT RAMP.
A110-2SEAGULLS ON & INVOF ARPT.
A110-4ARPT CONDS UNMON 2300-0600.
A110-5MOWING OPS CONDUCTED DURG DALGT.
A110-6PPR FOR PRACTICE TKOFS & LNDGS FOR ACFT WEIGHING MORE THAN 12500 LBS.
A110-7RECREATIONAL SAILBOAT MASTS TO +50 FT & MOTOR BOATS IN WATERWAY AT AER 33 813 FT FM THR ON CNTRLN.
A110-8FOR ADDL INFO CTC AMGR 410-682-8800.
MARTIN STATE (ICAO: KMTN, IATA: MTN) is a public airport located in BALTIMORE, MD.
