No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KMSY
LOUIS ARMSTRONG NEW ORLEANS INTL
PublicPUB

10 miles W of NEW ORLEANS, LA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
29° 59' 36"N 90° 15' 32"W
3' MSL
1003' MSL
01W
JET A, 100LL
DE RIDDER (DRI)
NEW ORLEANS
HOUSTON (ZHU)
10/31/24-11/28/24
KMSY MVFR
5:53 AM CST
Broken 1,300'
10sm
77°F
74°F
29.92"Hg
080° 11kts
AO2 SLP135 T02500233 10256 20239 53002
KMSY 091153Z 08011KT 10SM BKN013 25/23 A2992 RMK AO2 SLP135 T02500233 10256 20239 53002
Add Your Business

KMSY FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 --

ATIS

D-ATIS
504-471-4417
 127.55

Approach/Departure

APCH/P DEP/P
WEST
 125.5
APCH/P DEP/P
EAST
 133.15

Clearance Delivery

CD PRE TAXI CLNC
 120.925
CD/P
 120.925

Emergency

EMERG
 121.5

Ground

GND/P
 121.9

Tower

LCL/P
 119.5

Other

AWDAD STAR
WEST
 125.5
CLASS B
SE & SOUTH
 123.85
CLASS B
WEST
 125.5
CLASS B
NORTH & EAST
 133.15
MNSTR STAR
EAST
 133.15
OLEDD STAR
WEST
 125.5

Terminal Area Forecast

KMSY
Sat, 11/9 5:20 AM CST
Sat, 11/9 6:00 AM CST - Sun, 11/10 12:00 PM CST
VFR
6:00 AM CST - 12:00 PM CST
Broken 9,000'
Scattered 3,000'
6sm
060° 8kts
MVFR
12:00 PM CST - 6:00 PM CST
Broken 2,500'
Scattered 1,500'
6sm
100° 11kts
Gusts 20kts
VFR
6:00 PM CST - 6:00 AM CST
Broken 3,500'
Scattered 1,500'
6sm
120° 9kts
VFR
6:00 AM CST - 12:00 PM CST
Overcast 5,000'
6sm
120° 9kts
MVFR
6:00 AM CST - 12:00 PM CST
Light Showers and Rain
Broken 2,500'
6sm
Calm
KMSY 091120Z 0912/1018 06008KT P6SM SCT030 BKN090
   FM091800 10011G20KT P6SM SCT015 BKN025
   FM100000 12009KT P6SM SCT015 BKN035
   FM101200 12009KT P6SM OVC050
   PROB30 1012/1018 6SM -SHRA BKN025
KMSY
Domestic
11/6/241300Z !MSY 11/002 MSY SVC SMR U/S 2411061300-2411062355
11/5/242101Z !MSY 11/013 MSY SVC MBST/WS DETECTION SYSTEM NOT AVBL 2411052101-2411152300
11/5/241608Z !MSY 11/008 MSY OBST TOWER LGT (ASR 1031897) 295042.00N0900640.00W (11.7NM SE MSY) 275.6FT (270.7FT AGL) U/S 2411051608-2502282359
11/5/241426Z !MSY 11/007 MSY RWY 20 PAPI U/S 2411051426-2411122000EST
11/2/241100Z !MSY 11/003 MSY OBST TOWER LGT (ASR 1022281) 295828.60N0900836.50W (6.1NM E MSY) 431.1FT (431.1FT AGL) U/S 2411021100-2501310400
10/23/241649Z !MSY 10/075 MSY OBST TOWER LGT (ASR 1045289) 295648.00N0901121.00W (4.6NM SE MSY) 273.6FT (265.7FT AGL) U/S 2410231649-2502201649
10/11/240010Z !MSY 10/048 MSY OBST TOWER LGT (ASR 1266500) 295610.80N0901451.70W (3.4NM S MSY) 225.1FT (224.1FT AGL) U/S 2410110010-2501080400
10/3/240724Z !MSY 10/015 MSY RWY 11 SEQUENCED FLG LGT U/S 2410030724-2510012000EST
9/11/242350Z !MSY 09/029 MSY OBST TOWER LGT (ASR 1229764) 295811.70N0902504.20W (8.5NM W MSY) 268.0FT (260.2FT AGL) U/S 2409112350-2412100400
9/4/241049Z !MSY 09/007 MSY RWY 11 RAI LGT U/S 2409041049-2509052000
6/26/241337Z !MSY 06/072 MSY OBST TOWER LGT (ASR 1049092) 295537.80N0900920.40W (6.6NM SE MSY) 340.9FT (336.9FT AGL) U/S 2406261337-2412262359
FDC
10/25/241213Z !FDC 4/4117 MSY IAP LOUIS ARMSTRONG NEW ORLEANS INTL, NEW ORLEANS, LA.
LOC RWY 20, AMDT 3A...
SHORE FIX MINIMUMS: S-20 MDA 420/HAT 421 ALL CATS.
CIRCLING CAT B MDA 540/HAA 536.
2410251213-2610251213EST
10/25/241210Z !FDC 4/4114 MSY IAP LOUIS ARMSTRONG NEW ORLEANS INTL, NEW ORLEANS, LA.
ILS OR LOC RWY 2, AMDT 20A...
YERUB FIX MINIMUMS: S-LOC 2 MDA 440/HAT 438 ALL CATS.
CIRCLING CAT B MDA 540/HAA 536.
2410251210-2610251210EST
10/15/241840Z !FDC 4/9377 MSY IAP LOUIS ARMSTRONG NEW ORLEANS INTL, NEW ORLEANS, LA.
RNAV (GPS) Y RWY 11, AMDT 2C...
LNAV/VNAV DA 319/HAT 315 ALL CATS.
LNAV MDA 420/HAT 416 ALL CATS. VIS CATS C/D RVR 3500.
FOR INOP ALSF-2, INCREASE LNAV/VNAV ALL CATS VISIBILITY TO RVR 4500 AND LNAV CATS C/D VISIBILITY TO RVR 6000.
TEMPORARY CRANE, 108 MSL, 1298FT EAST OF RWY 11 (2024-ASW-2401-NRA).
2410151840-2503041840EST
10/15/241840Z !FDC 4/9376 MSY IAP LOUIS ARMSTRONG NEW ORLEANS INTL, NEW ORLEANS, LA.
ILS OR LOC RWY 11, AMDT 5B...
WENUP FIX MINIMUMS:
S-LOC 11 MDA 420/HAT 416 ALL CATS. VIS CATS C/D RVR 3500.
VDP NA.
FOR INOP ALS, INCREASE S-LOC 11 VISIBILITY TO 1 3/8 SM AND INCREASE WENUP FIX MINIMUMS S-LOC 11 CAT C/D VISIBILITY TO RVR 6000.
TEMPORARY CRANE, 108 MSL, 1298FT EAST OF RWY 11 (2024-ASW-2401-NRA).
2410151840-2503041840EST
10/15/241833Z !FDC 4/9373 MSY ODP LOUIS ARMSTRONG NEW ORLEANS INTL, NEW ORLEANS, LA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
TAKEOFF OBSTACLE NOTES: RWY 11, TEMPORARY MEN AND EQUIPMENT, BEGINNING 557 FT FROM DER, BEGINNING 497 FT RIGHT OF CENTERLINE, UP TO 60 AGL/UP TO 60 MSL (2022-ASW-3305/3306/3308/3309-NRA). ALL OTHER DATA REMAINS AS PUBLISHED. 2410151833-2501201833EST
10/7/241403Z !FDC 4/5668 MSY IAP LOUIS ARMSTRONG NEW ORLEANS INTL, NEW ORLEANS, LA.
ILS OR LOC RWY 11, AMDT 5B...
ILS RWY 11 (SA CAT I) RWY 11, AMDT 5B...
ILS RWY 11 (CAT I AND II) RWY 11, AMDT 5B...
DME REQUIRED EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
HRV VOR OUT OF SERVICE. 2410071403-2501101403EST
10/7/241403Z !FDC 4/5667 MSY IAP LOUIS ARMSTRONG NEW ORLEANS INTL, NEW ORLEANS, LA.
ILS OR LOC RWY 2, AMDT 20A...
DME REQUIRED EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS.
RADAR REQUIRED FOR PROCEDURE ENTRY EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
HRV VOR OUT OF SERVICE. 2410071403-2501101403EST
10/7/241403Z !FDC 4/5664 MSY IAP LOUIS ARMSTRONG NEW ORLEANS INTL, NEW ORLEANS, LA.
ILS OR LOC RWY 29, AMDT 10A...
RADAR REQUIRED FOR PROCEDURE ENTRY EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
HRV VOR OUT OF SERVICE. 2410071403-2501101403EST
9/5/241349Z !FDC 4/0896 MSY IAP LOUIS ARMSTRONG NEW ORLEANS INTL, NEW ORLEANS, LA.
ILS OR LOC RWY 11, AMDT 5B...
ILS RWY 11 (SA CAT I), AMDT 5B...
ILS RWY 11 (CAT II-III), AMDT 5B....
MISSED APPROACH: CLIMB TO 800 THEN CLIMBING RIGHT TURN TO 2600 DIRECT HRV VORTAC AND HOLD SE, RT, 303.90 INBOUND,
LEV VORTAC OUT OF SERVICE. 2409051349-2504171347EST
9/5/241239Z !FDC 4/0767 MSY IAP LOUIS ARMSTRONG NEW ORLEANS INTL, NEW ORLEANS, LA.
ILS OR LOC RWY 29, AMDT 10A...
RNAV (GPS) RWY 2, AMDT 3...
RNAV (GPS) Y RWY 11, AMDT 2C...
RNAV (GPS) Y RWY 20, AMDT 3A...
RNAV (GPS) Y RWY 29, AMDT 4A...
VOR/DME RWY 11, AMDT 1A...
CIRCLING CAT B MDA 540/HAA 536.
2409051239-2609051239EST
9/5/241221Z !FDC 4/0752 MSY IAP LOUIS ARMSTRONG NEW ORLEANS INTL, NEW ORLEANS, LA.
ILS OR LOC RWY 11, AMDT 5B...
WENUP FIX MINIMUM: S-LOC 11 MDA 340/HAT 336 ALL CATS.
CIRCLING CAT B MDA 540/HAA 536.
2409051221-2609051221EST
8/12/241615Z !FDC 4/7052 MSY IAP LOUIS ARMSTRONG NEW ORLEANS INTL, NEW ORLEANS, LA.
RNAV (RNP) Z RWY 29, AMDT 2...
RNP 0.30 DA 424/HAT 422 ALL CATS.
TOWER, 85 MSL, 4942 FT SE OF APCH END RWY 29 (22-053179), TOWER, 77 MSL, 1.13 NM SE OF APCH END RWY 29 (22-045261).
2408121615-2608121615EST
4/12/241648Z !FDC 4/0217 MSY IAP LOUIS ARMSTRONG NEW ORLEANS INTL, NEW ORLEANS, LA.
VOR/DME RWY 11, AMDT 1A...
PROCEDURE NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
LEV VORTAC OUT OF SERVICE. 2404121648-2504231648EST
Yes
ALL
CITY OF NEW ORLEANS
PO BOX 20007
NEW ORLEANS, LA 70141
Phone: 504-658-4900
KEVIN DOLLIOLE
PO BOX 20007
NEW ORLEANS, LA 70141
Phone: (504) 303-7652
DE RIDDER FSS (DRI)
Toll Free: 1-800-WX-BRIEF
MSY
Sunset to Sunrise
--
N/A
Yes - Lighted
No
Yes
Tie-Down
Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
Air Freight
Cargo Handling

Runway 02/20

7002 ft. x 150 ft.
CONC
Good
GRVD
HIGH
64 /R/C/W/T
75,000lbs
180,000lbs
380,000lbs
--
  Runway 02 Runway 20
True Heading 15°195°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 29° 59' 04"N 30° 00' 11"N
Longitude 90° 15' 05"W 90° 14' 44"W
Elevation 1' -3'
Threshold Crossing Height 52 ft. AGL 52 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights RLLS MALS
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway 11/29

10104 ft. x 150 ft.
CONC
Good
GRVD
HIGH
123/R/C/W/T
75,000lbs
180,000lbs
380,000lbs
--
  Runway 11 Runway 29
True Heading 105°285°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 29° 59' 48"N 29° 59' 21"N
Longitude 90° 16' 54"W 90° 15' 03"W
Elevation 3' 0'
Threshold Crossing Height 73 ft. AGL 68 ft. AGL
Visual Glide Path Angle 2.8° 3°
Visual Slope Indicator P4R P4R
Approach Lights ALSF2 MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway H1

50 ft. x 50 ft.
ASPH
Fair
NONE


--
--
--
--
  Runway H1 Runway
True Heading 90°270°
Traffic Pattern
Markings
Markings Condition
Latitude 29° 59' 32"N N/A
Longitude 90° 16' 07"W N/A
Elevation 0' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway H2

50 ft. x 50 ft.
CONC
Fair
NONE


--
--
--
--
  Runway H2 Runway
True Heading 90°270°
Traffic Pattern
Markings
Markings Condition
Latitude 29° 59' 42"N N/A
Longitude 90° 15' 54"W N/A
Elevation 0' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1180 DEG & LOCKED WHEEL TURNS PROHIBITED ON ASPH SFC ACFT 12500 LBS & OVER.
A110-3FLOCKS OF BIRDS ON & IN VICINITY OF ARPT.
A110-5RY 11 NOISE SENSITIVE FOR DEP; AVBL FOR OPNL NECESSITY. ALL RYS NOISE SENSITIVE FOR ARR. ARRIVING TURBOJETS MUST MAKE 5 MILE FINAL APCH TO MINIMIZE NOISE.
A110-7TWY G BTN RWY 11/29 AND TWY S SFC MOV GUIDANCE AND CTL SYSTEM U/S PERM
LOUIS ARMSTRONG NEW ORLEANS INTL (ICAO: KMSY, IATA: MSY) is a public airport located in NEW ORLEANS, LA.
