KMKE
GENERAL MITCHELL INTL
PublicPUB

5 miles S of MILWAUKEE, WI
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
42° 56' 49"N 87° 53' 49"W
728' MSL
1728' MSL
04W
JET A, 100LL
GREEN BAY (GRB)
CHICAGO
CHICAGO (ZAU)
7/11/24-8/8/24
KMKE VFR
5:52 AM CDT
Clear
10sm
63°F
59°F
29.96"Hg
280° 3kts
AO2 SLP141 T01720150
KMKE 191052Z 28003KT 10SM CLR 17/15 A2996 RMK AO2 SLP141 T01720150
Add Your Business

KMKE FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 --

ATIS

D-ATIS
 126.4

ASOS

ASOS
414-489-2168
 126.4

Approach

APCH/P
B SE
 118.0
APCH/P IC
A NW
 126.5

Departure

DEP/P
A NW
 125.35
DEP/P
B SE
 135.875

Clearance Delivery

CD/P
 120.8

Emergency

EMERG
 121.5

Ground

GND/P
 121.8

Tower

LCL/P
 124.575

Other

CLASS C
B SE
 118.0
CLASS C
A NW
 126.5
GOPAC STAR
 126.5
OPS
 139.5

Terminal Area Forecast

KMKE
Thu, 9/19 3:52 AM CDT
Thu, 9/19 4:00 AM CDT - Fri, 9/20 7:00 AM CDT
VFR
4:00 AM CDT - 12:00 PM CDT
Few 25,000'
6sm
Calm
VFR
12:00 PM CDT - 9:00 PM CDT
Few 25,000'
6sm
150° 8kts
VFR
9:00 PM CDT - 4:00 AM CDT
Scattered 25,000'
6sm
160° 6kts
VFR
4:00 AM CDT - 7:00 AM CDT
Broken 10,000'
6sm
200° 5kts
MVFR
4:00 AM CDT - 7:00 AM CDT
Light Thunderstorm and Rain
Overcast 2,500'
4sm
Calm
KMKE 190852Z 1909/2012 00000KT P6SM FEW250
   FM191700 15008KT P6SM FEW250
   FM200200 16006KT P6SM SCT250
   FM200900 20005KT P6SM BKN100
   PROB30 2009/2012 4SM -TSRA OVC025CB
KMKE
Domestic
9/18/241300Z !MKE 09/151 MKE SVC TAR/SSR U/S 2409181300-2409182200
9/18/240422Z !MKE 09/164 MKE RWY 01L/19R CLSD 2409180422-2409181200
9/18/240056Z !MKE 09/162 MKE AD AP WINDCONE FOR RWY 19R LGT U/S 2409180056-2410152359
9/17/241458Z !MKE 09/159 MKE APRON TERMINAL RAMP WIP CONST ADJ GATE D46 LGTD AND BARRICADED
2409171458-2410182300
9/13/241946Z !MKE 09/136 MKE TWY A3 BTN RWY 07R/25L AND TWY Y CLSD 2409131946-2410132359
9/13/241614Z !MKE 09/135 MKE TWY Y BTN VOJET RAMP EAST ACCESS AND TWY A3 CLSD 2409131614-2410132359
9/3/242021Z !MKE 09/008 MKE APRON NORTHEAST 1 RAMP CLSD 2409032021-2411042359
8/29/240911Z !MKE 08/290 MKE RWY 01R/19L CLSD 2408290911-2412312359
8/29/240910Z !MKE 08/289 MKE TWY B SFC MARKINGS BTN TWY G AND TWY V FADED 2408290910-2412312359
8/29/240907Z !MKE 08/287 MKE TWY Z SFC MARKINGS FADED 2408290907-2412312359
8/22/242108Z !MKE 08/231 MKE APRON TERMINAL RAMP WIP CONST BTN E60 AND E69 LGTD AND BARRICADED 2408222108-2409272359
8/20/241556Z !MKE 08/218 MKE RWY 01R RWY END ID LGT U/S 2408201556-2508202359
8/20/240410Z !MKE 08/207 MKE APRON TERMINAL RAMP WIP CONST D30 LGTD AND BARRICADED 2408200410-2410182359
8/18/240222Z !MKE 08/197 MKE TWY F HLDG PSN MARKINGS FOR APCH END RWY 19R FADED 2408180222-2409302359
8/5/241048Z !MKE 08/052 MKE COM REMOTE COM OUTLET 122.6 U/S 2408051048-2410152000EST
8/1/241346Z !MKE 08/017 MKE AD AP CLSD TO UNSCHEDULED ACFT AND CHARTERS EXC ACFT WINGSPAN LESS THAN 118FT 2408011346-2410312300
8/1/241244Z !MKE 08/013 MKE TWY E SFC PAINTED HLDG PSN SIGNS FOR RWY 13/31 FADED 2408011244-2508012359
7/30/241300Z !MKE 07/294 MKE NAV ILS RWY 07R U/S 2407301300-2409202359
6/27/242111Z !MKE 06/382 MKE TWY A5 SFC PAINTED HLDG PSN SIGNS FOR APCH END RWY 07R FADED 2406272111-2412272359
6/11/240242Z !MKE 06/159 MKE TWY C SFC PAINTED HLDG PSN SIGNS FOR APCH END RWY 07L FADED 2406110242-2409302359
4/18/241408Z !MKE 04/294 MKE APRON TERMINAL RAMP WIP CONST ADJ GATE 27 LGTD AND BARRICADED 2404181408-2409272359
1/24/240734Z !MKE 01/751 MKE TWY D SFC PAINTED HLDG PSN SIGNS FOR RWY 07L/25R FADED 2401240734-2411292359
10/25/230042Z !MKE 10/272 MKE TWY V SFC PAINTED HLDG PSN SIGNS FOR RWY 13/31 FADED 2310250042-2410312359
FDC
9/12/241657Z !FDC 4/4493 MKE ODP GENERAL MITCHELL INTL, MILWAUKEE, WI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 9...
ADD TAKEOFF OBSTACLE NOTES: RWY 7R, TEMPORARY CRANE BEGINNING 2272FT FROM DER, 704FT RIGHT OF CENTERLINE, 110FT AGL/789FT MSL (2024-AGL-5482 TO 5485-OE). RWY 13, TEMPORARY CRANE BEGINNING 2353FT FROM DER, 995FT LEFT OF CENTERLINE, 110FT AGL/789FT MSL (2024-AGL-5484/5485-OE). ALL OTHER DATA REMAINS AS PUBLISHED. 2409121657-2410191657EST
8/12/241200Z !FDC 4/6088 MKE IAP GENERAL MITCHELL INTL, MILWAUKEE, WI.
RNAV (GPS) Z RWY 25L, AMDT 1E...
LPV DA 1025/HAT 342 ALL CATS. TEMPORARY CRANE 789 MSL 2886FT E OF RWY 25L (2024-AGL-5482 TO 5485-OE).
2408121200-2410192012EST
4/4/242031Z !FDC 4/7061 MKE IAP GENERAL MITCHELL INTL, MILWAUKEE, WI.
RNAV (GPS) RWY 19R, AMDT 2C...
LNAV/VNAV DA 1209/HAT 537 ALL CATS, VIS RVR 5500 ALL CATS. LNAV MDA 1220/HAT 548 ALL CATS, VIS CAT C/D RVR 5500. VDP: 1.45 NM TO RW19R.
2404042031-2604042031EST
Yes
ALL
MILWAUKEE COUNTY
907 N 10TH ST
MILWAUKEE, WI 53233
Phone: 414-747-5300
BRIAN DRANZIK
5300 S HOWELL AVE
MILWAUKEE, WI 53207
Phone: 414-747-5300
GREEN BAY FSS (GRB)
Toll Free: 1-800-WX-BRIEF
MKE
--
--
N/A
Yes - Lighted
No
No
Hangar
Landing Rights Airport
NOT an Airport of Entry
15
29
36
1
10
0
Major
Major
None
High Pressure
Air Ambulance
Avionics
Cargo Handling
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 01L/19R

9990 ft. x 200 ft.
ASPH CONC
Fair
GRVD
HIGH
64 /R/A/W/T
100,000lbs
185,000lbs
350,000lbs
--
  Runway 01L Runway 19R
True Heading 7°187°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 42° 55' 50"N 42° 57' 28"N
Longitude 87° 53' 52"W 87° 53' 35"W
Elevation 706' 673'
Threshold Crossing Height 72 ft. AGL 75 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4R P4R
Approach Lights ALSF2 MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights No No

Runway 01R/19L

4182 ft. x 150 ft.
ASPH CONC
Fair
NONE
MED
23 /R/B/W/T
85,000lbs
115,000lbs
180,000lbs
--
  Runway 01R Runway 19L
True Heading 7°187°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 42° 56' 22"N 42° 57' 03"N
Longitude 87° 53' 33"W 87° 53' 25"W
Elevation 678' 670'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes No

Runway 07L/25R

4797 ft. x 100 ft.
ASPH CONC
Good
GRVD
MED
20 /F/A/X/T
30,000lbs
35,000lbs
55,000lbs
--
  Runway 07L Runway 25R
True Heading 72°252°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 42° 57' 10"N 42° 57' 25"N
Longitude 87° 54' 19"W 87° 53' 18"W
Elevation 672' 675'
Threshold Crossing Height 39 ft. AGL 42 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4R
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes Yes

Runway 07R/25L

8300 ft. x 150 ft.
ASPH CONC
Fair
GRVD
HIGH
58 /R/A/W/T
100,000lbs
185,000lbs
350,000lbs
--
  Runway 07R Runway 25L
True Heading 72°252°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 42° 56' 21"N 42° 56' 46"N
Longitude 87° 55' 04"W 87° 53' 18"W
Elevation 728' 670'
Threshold Crossing Height 63 ft. AGL 47 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALSR
Centerline Lights No No
Runway End Identifier Lights No Yes

Runway 13/31

5537 ft. x 150 ft.
ASPH CONC
Good
GRVD
MED
48 /R/B/W/T
80,000lbs
110,000lbs
170,000lbs
--
  Runway 13 Runway 31
True Heading 132°312°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 42° 57' 29"N 42° 56' 53"N
Longitude 87° 54' 12"W 87° 53' 17"W
Elevation 671' 669'
Threshold Crossing Height 54 ft. AGL 55 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4R
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes Yes
A110-1RY 07L/25R CLSD TO ALL JET ACFT.
A110-10ALL APCHS ARE OVER NOISE SENSITIVE AREAS; ALL TURBOJET ACFT SHOULD REFRAIN FM CONDUCTING MULTI VFR TFC PATTERN APCHS & DEPS WO PRIOR APVL FM AMGR CALL C414-747-5325.
A110-27ASDE-X IN USE. OPERATE TRANSPONDERS WITH ALTITUDE REPORTING MODE AND ADS-B (IF EQUIPPED) ENABLED ON ALL AIRPORT SURFACES.
A110-3RY 13/31 CLSD JET ACFT, UNLESS PMSN FROM TWR OR AMGR 414-747-5325.
A110-5TRNG FLGTS INVOLVING SUCCESSIVE USE OF ANY RY PROHIBITED 2200-0600.
A110-52ACFT WITH WINGSPAN GREATER THAN 175 FT CANNOT PASS SIMULTANEOUSLY ON TWY 'E' & TWY 'Z'.
A110-55TWY F (WEST OF TWY Z) CLSD TO ACFT WITH WINGSPAN GREATER THAN OR EQUAL TO 118 FT UNLESS PERMISSION FROM ARPT DIR AT 414-747-5325.
A110-56RY 19R TODA 8,750 FT FROM INT TWY V.
A110-57TWY V BTN TWY D AND RY 7L/25R CLSD TO ACFT WITH WINGSPAN GREATER THAN 170 FT WHEN RY 7L/25R IN USE.
A110-58TWY B BTN TWY V AND TWY P CLSD TO AFCT WITH WINGSPAN GREATER THAN 170 FT.
A110-6RYS 13/31 & 01R/19L & 07L/25R CLSD EXCP LGT WT SINGLE ENG ACFT 0400-1200Z DLY.
A110-60HOLDING BAY AT RY 19R WHEN IN USE, TWY Z ADJACENT TO BAY IS LIMITED TO ACFT WITH WINGSPAN UP TO 170 FT.
A110-61RY 07L/25R NO ACFT 65,000 LBS OR GREATER ALLOWED TO TAXI BTN TWY D & RY 13/31 AND EAST OF RY 19R.
A110-62RY 01R-19L AVAILABLE TO AIR CARRIERS FOR TAXI ONLY.
A110-64TWY S & TWY T BTN TWY R & RY 07R/25L AND RY 07R/25L BTN RY 1R/19L & TWY R CLSD DURG CAT II & III OPNS.
A110-68HOLDING BAY AT RY 01L CLSD EXCP ACFT WITH WINGSPAN LESS THAN 118 FT.
A110-72TWY A CLSD BTN TWY A4 AND TWY A5 TO ACFT WITH WINGSPAN GREATER THAN OR EQUAL TO 214' UNLESS PERMISSION FROM ARPT MGR 414-747-5325
A110-73ALL AIRCRAFT PUSHBACKS FROM GATES C20, C21, C22, C23, D39 D41 D43, D45, D48, D51, D53, D54, D55, E65, E66, & E67 REQUIRE CLEARANCE FROM GROUND CONTROL. PUSHBACKS FROM ALL OTHER GATES ARE AT RAMP/ PILOT DISCRETION; CONTACT GROUND CONTROL WHEN READY TO TAXI.
A110-74TWY C CLSD BTWN APCH END OF RWY 7L AND WEST RAMP NORTH TXL TO ACFT WITH WINGSPAN GTR THAN OR EQUAL TO 118 FT UNLESS PMSN FM ARPT MGR 414-747-5325.
A110-75DEICE PAD FOR RWY 07R NOT AUTH FOR THRU TAXI.
A110-76TWY B BTN TWY R AND TWY A1 CLSD TO ACFT WINGSPAN MORE THAN 118 FT EXC PPR 414-747-5325.
A110-77TWY A BTN TWY R AND TWY A1 CLSD TO ACFT WINGSPAN MORE THAN 171 FT EXC PPR 414-747-5325.
A110-78TWY A CLSD FM TWY R TO TWY E AND TWY E CLSD FM TWY T TO TWY E1 AND TWY T CLSD N OF RWY 07R/25L, AND TWY M CLSD FM TWY E TO RWY 01R/19L TO ACFT WITH TAIL HGT GTR THAN 54.5 FT DURG CAT II AND CAT III OPS.
A110-8BIRDS ON & INVOF ARPT.
A110-80ACFT ARE NOT PERMITTED TO MAKE LEFT TURN ONTO TWY E WHEN EXITING TWY E2.
A110-81TWY F (E OF RWY 19R), TWY H, TWY J, AND TWY P CLSD TO ACFT WITH WINGSPAN GTR THAN 78 FT UNLESS PMSN FM AMGR AT 414-747-5325.
A110-82ANG: PPR ALL ACFT 48HR PN, CTC AFLD MGMT DSN 580-8241, C414-944-8241. AFLD MGMT HR 1200Z-2230Z++ TUE-FRI, CLSD HOL, SAT-SUN EXC UNIT TMG. MAINT OPS (MOCC) FREQ - 379.85. ANY MDS (OTHER THAN KC-135) IS LTD TO STD TRAN MARSHALLING AND PRK. NO TECH DATA AVBL FOR TRAN MAINT. FUEL AND AGE SUPPORT EQUIP AVBL FOR SELF-SVC. NO ADNL CONFIGN ITEMS SUPPORTED SUCH AS LANTIRN PODS, EDM PODS, ETC. ANG: EOR, ACFT SHELTERS/REVETMENTS, AND ALERT FAC UNAVBL. APRON HAS LTD STATIC GND POINTS AND TIE DOWN POINTS. FLEET SVC/HOT CARGO PRKG UNAVBL. CTC UPSET CTL ON 321.0 30 MIN PRIOR TO LDG AND DEP. NSTD MRK ON APRON FOR WINGTIP CLNC USED BY BASE ASGND ACFT.
A110-9PREFERRED USAGE BY ACFT BTN 2200-0600 IS TKOF RY 19R & LNDG RY 01L.
GENERAL MITCHELL INTL (ICAO: KMKE, IATA: MKE) is a public airport located in MILWAUKEE, WI.
