No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KMHR
SACRAMENTO MATHER
PublicPUB

10 miles E of SACRAMENTO, CA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
38° 33' 19"N 121° 17' 50"W
98' MSL
1098' MSL
13E
JET A, 100LL
RANCHO MURIETA (RIU)
SAN FRANCISCO
OAKLAND (ZOA)
10/31/24-11/28/24
KMHR VFR
3:35 AM PST
Clear
10sm
41°F
37°F
30.01"Hg
Calm
A01
KMHR 091135Z AUTO 00000KT 10SM CLR 05/03 A3001 RMK A01
Add Your Business

KMHR FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 120.65

ATIS

ATIS
 118.325

AWOS-3PT

AWOS-3PT
916-366-3371
 118.325

Clearance Delivery

CD/P
 121.85

Ground

GND/P
 121.85

Tower

LCL/P
 120.65

FAA A/FD Pages

Airport Diagrams

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

Instrument Approach

Terminal Area Forecast

KMHR
Sat, 11/9 3:20 AM PST
Sat, 11/9 4:00 AM PST - Sun, 11/10 4:00 AM PST
VFR
4:00 AM PST - 4:00 AM PST
Broken 25,000'
6sm
VRB° 5kts
KMHR 091120Z 0912/1012 VRB05KT P6SM BKN250
KMHR
Domestic
10/31/240700Z !MHR 10/022 MHR RWY 04R PAPI NOW GPA 3.00DEG, TCH 60FT 2410310700-2411182300
10/31/240700Z !MHR 10/021 MHR RWY 04R VASI U/S 2410310700-2411182300
10/31/240700Z !MHR 10/020 MHR RWY 04R/22L SW 4301FT CLSD. DECLARED DIST: RWY 04R
TORA 7000FT TODA 7000FT ASDA 7000FT LDA 7000FT. RWY 22L TORA 7000FT TODA 7000FT ASDA 7000FT LDA 7000FT. 2410310700-2411182300
10/25/241918Z !MHR 10/019 MHR NAV ILS RWY 22L U/S 2410251918-2411182300
10/25/241912Z !MHR 10/017 MHR TWY G CLSD 2410251912-2411182300
10/25/241911Z !MHR 10/016 MHR TWY A BTN TWY G AND TWY F CLSD 2410251911-2411182300
10/25/241909Z !MHR 10/015 MHR TWY F CLSD 2410251909-2411182300
10/25/241907Z !MHR 10/018 MHR RWY 04R APCH END WIP LGTD BLAST FENCE 2410251907-2411182300
10/25/240355Z !MHR 10/014 MHR SVC AUTOMATED WX BCST SYSTEM VIS UNREL 2410250355-2411272359EST
10/23/242111Z !MHR 10/013 MHR RWY 04R 5000FT DIST REMAINING SIGN NOT LGTD 2410232111-2411082359
10/23/242111Z !MHR 10/012 MHR RWY 22L 2000FT DIST REMAINING SIGN NOT LGTD 2410232111-2411082359
10/16/241922Z !MHR 10/010 MHR SVC AUTOMATED WX BCST SYSTEM PRECIPITATION UNREL 2410161922-2411212359EST
8/11/221601Z !MHR 08/022 MHR RWY 04L/22R MIRL DECOMMISSIONED 2208111601-PERM
FDC
10/31/241331Z !FDC 4/7009 MHR IAP SACRAMENTO MATHER, SACRAMENTO, CA.
RNAV (GPS) RWY 4R, AMDT 3...
PROCEDURE NA.
2410311331-2506121331EST
7/11/241144Z !FDC 4/0537 MHR IAP SACRAMENTO MATHER, SACRAMENTO, CA.
RNAV (GPS) RWY 22R, ORIG-A...
LNAV/VNAV DA 532/HAT 438 ALL CATS, VIS ALL CATS 1 1/4. LNAV MDA 640/HAT 546 ALL CATS, VIS CAT C/D 1 5/8. CIRCLING CAT A/B/C MDA 640/HAA 542, VIS CAT C 1 5/8. WATER TANK 321 MSL 4191FT NW OF RWY 22R (06-235423).
2407111144-2607151144EST
1/4/231404Z !FDC 3/0791 MHR CHART SACRAMENTO MATHER,
SACRAMENTO, CA.
ILS OR LOC RWY 22L, AMDT 7A...
CORRECT MIDDLE BRIEFING STRIP: DELETE NOTE: PROCEDURE NA WHEN
TOWER CLOSED.
2301041404-PERM
Yes
MON 0500-2330
TUE-FRI 0300-2330
SAT 0300-2100
SUN 0500-2100
COUNTY OF SACRAMENTO
6900 AIRPORT BLVD.
SACRAMENTO, CA 95837
Phone: 916-875-7077
LARRY FLESHMAN
10425 NORDEN AVE
MATHER, CA 95655
Phone: 916-875-6760
RANCHO MURIETA FSS (RIU)
Toll Free: 1-800-WX-BRIEF
MHR
--
WHEN ATCT CLSD ACTVT MIRL RWY 04L/22R; HIRL RWY 04R/22L; VASI RWY 04R & 22L; MALSR RWY 22L - CTAF.
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
None
Low Pressure
Air Freight
Cargo Handling

Runway 04L/22R

6081 ft. x 150 ft.
ASPH
Good
NONE
MED

90,000lbs
105,000lbs
190,000lbs
--
  Runway 04L Runway 22R
True Heading 54°234°
Traffic Pattern Left Right
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 38° 33' 11"N 38° 33' 46"N
Longitude 121° 18' 18"W 121° 17' 17"W
Elevation 81' 94'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No

Runway 04R/22L

11301 ft. x 150 ft.
ASPH CONC
Good
NONE
HIGH

160,000lbs
280,000lbs
500,000lbs
--
  Runway 04R Runway 22L
True Heading 54°234°
Traffic Pattern Right Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 38° 32' 41"N 38° 33' 47"N
Longitude 121° 18' 49"W 121° 16' 54"W
Elevation 77' 98'
Threshold Crossing Height 51 ft. AGL 50 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator V4L V4L
Approach Lights MALSR
Centerline Lights No No
Runway End Identifier Lights

Runway H1

30 ft. x 30 ft.
ASPH
Fair
NONE


--
--
--
--
  Runway H1 Runway
True Heading 69°249°
Traffic Pattern
Markings
Markings Condition
Latitude 38° 33' 46"N N/A
Longitude 121° 17' 29"W N/A
Elevation 95' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway H2

100 ft. x 100 ft.
ASPH
Fair
NONE


--
--
--
--
  Runway H2 Runway
True Heading 69°249°
Traffic Pattern
Markings
Markings Condition
Latitude 38° 33' 22"N N/A
Longitude 121° 17' 08"W N/A
Elevation 92' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-10BE ADVISED RY 4L THLD LGTS ARE NON-STANDARD.
A110-11FOR CD WHEN ATCT IS CLSD CTC NORCAL APCH AT 916-361-6874.
A110-12TWY D1 CLSD TO ACFT WITH WINGSPAN MORE THAN 69 FT.
A110-13NO FLD COND NOTAMS AVBL 1600-0600.
A110-2RY 22L CALM WIND RY.
A110-3BE ALERT FOR LARGE TRANSPORT ACFT TKOFS & LNDGS AND HIGH PERFORMANCE MILITARY T-38 JETS.
A110-5AVOID NOISE SENSITIVE RESIDENTIAL AREAS NORTH/EAST OF RY 22L ILS FINAL APCH COURSE. TURBOJET NIGHTTIME NOISE ABATEMENT ARRIVAL AND DEPARTURE PROCEDURES IN EFFECT 2200-0700 DAILY.
A110-6PILOT INFORMATION ON NOISE ABATEMENT (916) 874-0359.
A110-7TWY D LTD TO ACFT WITH MAX GWT 50000 LBS OR LESS. TWY D1 LTD TO ACFT WITH MAX GWT OF 50000 LBS OR LESS.
A110-8BIRDS INVOF OF ARPT.
A110-9ACFT ENTERING RY 22R TFC PAT FM THE NORTH SHOULD EXPECT TO FLY BASE LEG EXTENDED 2 MILES FM RY THLD.
SACRAMENTO MATHER (ICAO: KMHR, IATA: MHR) is a public airport located in SACRAMENTO, CA.
