7/14/231900Z
|
!FDC 3/6754 MFI PART 1 OF 3 ODP MARSHFIELD MUNI, MARSHFIELD, WI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 5: VEGETATION 33 FT FROM DER, 183 FT
LEFT OF CENTERLINE, 1252 FT MSL.
POLES BEGINNING 464 FT FROM DER, 379 FT RIGHT OF CENTERLINE, UP TO
43 FT AGL/1284 FT MSL.
TREE 653 FT FROM DER, 566 FT RIGHT OF CENTERLINE, 1295 FT MSL.
TREES, POLES BEGINNING 749 FT FROM DER, 14 FT RIGHT OF CENTERLINE,
UP TO 1300 FT MSL.
TREES, POLE BEGINNING 857 FT FROM DER, 94 FT LEFT OF CENTERLINE, UP
TO 1275 FT MSL.
POLE 1140 FT FROM DER, 211 FT LEFT OF CENTERLINE, 51 FT AGL/1280 FT
MSL.
RWY 16: TREE 244 FT FROM DER, 453 FT RIGHT OF CENTERLINE, 1291 FT
MSL.
TREES BEGINNING 374 FT FROM DER, 478 FT RIGHT OF CENTERLINE, UP TO
1319 FT MSL.
RWY 23: TREE 11 FT FROM DER, 473 FT RIGHT OF CENTERLINE, 1255 FT
MSL.
TREE 100 FT FROM DER, 364 FT RIGHT OF CENTERLINE, 1261 FT MSL.
TREE 188 FT FROM DER, 271 FT RIGHT OF CENTERLINE, 1264 FT MSL.
AGL/1404 FT MSL. 2307141900-2507141900EST
END PART 1 OF 3
!FDC 3/6754 MFI PART 2 OF 3 ODP MARSHFIELD MUNI, MARSHFIELD, WI.
TREE 210 FT FROM DER, 470 FT RIGHT OF CENTERLINE, 1275 FT MSL.
TREE 225 FT FROM DER, 539 FT LEFT OF CENTERLINE, 1259 FT MSL.
TREES BEGINNING 538 FT FROM DER, 526 FT RIGHT OF CENTERLINE, UP TO
1282 FT MSL.
TREE 750 FT FROM DER, 583 FT RIGHT OF CENTERLINE, 1287 FT MSL.
TREES BEGINNING 865 FT FROM DER, 514 FT RIGHT OF CENTERLINE, UP TO
1293 FT MSL.
RWY 34: TERRAIN 45 FT FROM DER, 370 FT LEFT OF CENTERLINE, 1280 FT
MSL.
TERRAIN 195 FT FROM DER, 276 FT LEFT OF CENTERLINE, 1284 FT MSL.
TERRAIN 209 FT FROM DER, 485 FT LEFT OF CENTERLINE, 1285 FT MSL.
TRAVERSE WAY 1009 FT FROM DER, 759 FT LEFT OF CENTERLINE, 1306 FT
MSL.
POLE 1117 FT FROM DER, 684 FT LEFT OF CENTERLINE, 34 FT AGL/1317 FT
MSL.
POLE 1369 FT FROM DER, 587 FT LEFT OF CENTERLINE, 36 FT AGL/1319 FT
MSL.
POLE 1549 FT FROM DER, 517 FT LEFT OF CENTERLINE, 41 FT AGL/1327 FT
MSL.
ELEVATOR, BUILDING, TREES BEGINNING 1551 FT FROM DER, 554 FT LEFT
AGL/1404 FT MSL. 2307141900-2507141900EST
END PART 2 OF 3
!FDC 3/6754 MFI PART 3 OF 3 ODP MARSHFIELD MUNI, MARSHFIELD, WI.
OF CENTERLINE, UP TO 59 FT AGL/1350 FT MSL.
TREE, POLE BEGINNING 1770 FT FROM DER, 416 FT LEFT OF CENTERLINE,
UP TO 1351 FT MSL.
TREE 1837 FT FROM DER, 642 FT LEFT OF CENTERLINE, 1368 FT MSL.
TREES, POLE BEGINNING 1951 FT FROM DER, 342 FT LEFT OF CENTERLINE,
UP TO 1374 FT MSL.
TREE 1957 FT FROM DER, 284 FT RIGHT OF CENTERLINE, 1329 FT MSL.
TREE 1975 FT FROM DER, 244 FT RIGHT OF CENTERLINE, 1330 FT MSL.
TREES BEGINNING 2197 FT FROM DER, 8 FT LEFT OF CENTERLINE, UP TO
1385 FT MSL.
ELEVATOR 4537 FT FROM DER, 461 FT RIGHT OF CENTERLINE, 86 FT
AGL/1394 FT MSL.
ELEVATOR 4537 FT FROM DER, 465 FT RIGHT OF CENTERLINE, 96 FT
AGL/1404 FT MSL. 2307141900-2507141900EST
END PART 3 OF 3
|
