KMCN
MIDDLE GEORGIA RGNL
PublicPUB

9 miles S of MACON, GA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
32° 41' 34"N 83° 38' 57"W
354' MSL
1354' MSL
06W
JET A, 100LL
MACON (MCN)
ATLANTA
ATLANTA (ZTL)
4/17/25-5/15/25
KMCN VFR
2:53 AM EDT
Clear
7sm
62°F
62°F
30.05"Hg
Calm
AO2 SLP172 T01670167
KMCN 030653Z AUTO 00000KT 7SM CLR 17/17 A3005 RMK AO2 SLP172 T01670167
+ Add Your Business

KMCN FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 128.2

ATIS

ATIS
 120.775

Emergency

EMERG
 121.5

Ground

GND/P
 121.65

Tower

LCL/P
 128.2

FAA A/FD Pages

Airport Diagrams

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KMCN
Tue, 6/3 1:27 AM EDT
Tue, 6/3 2:00 AM EDT - Wed, 6/4 2:00 AM EDT
VFR
2:00 AM EDT - 11:00 AM EDT
Few 25,000'
6sm
090° 3kts
VFR
11:00 AM EDT - 2:00 AM EDT
Scattered 25,000'
Few 6,000'
6sm
110° 9kts
KMCN 030527Z 0306/0406 09003KT P6SM FEW250
   FM031500 11009KT P6SM FEW060 SCT250
KMCN
Domestic
5/19/251120Z !MCN 05/615 MCN AD AP RVR ALL U/S 2505191120-2506122359EST
5/19/251107Z !MCN 05/614 MCN NAV ILS RWY 05 CAT II NA 2505191107-2506052359EST
5/19/250429Z !MCN 05/611 MCN OBST TOWER LGT (ASR 1254081) 324803.70N0834800.50W (9.9NM NW MCN) 754.9FT (255.9FT AGL) U/S 2505190429-2506030329
5/14/251221Z !MCN 05/464 MCN NAV ILS RWY 05 CAT II NA 2505141221-2505282359
5/11/251754Z !MCN 05/368 MCN NAV ILS RWY 05 LOC NOT MNT 2505111754-2505282359EST
5/11/250043Z !MCN 05/344 MCN OBST TOWER LGT (ASR 1324107) 331230.78N825329.55W (14.8NM N MCN) 789FT (265FT AGL) U/S 2505110043-2506112300
5/2/250000Z !MCN 05/024 MCN NAV ILS RWY 05 GP NOT MNT DLY 0000-1200 2505020000-2511011200EST
5/1/251602Z !MCN 05/039 MCN TWY B1 TWY DIRECTION SIGN FOR TWY B LGT U/S 2505011602-2506010001
5/1/251556Z !MCN 05/038 MCN AD AP WINDCONE FOR RWY 32 LGT U/S 2505011556-2506010001
4/30/252134Z !MCN 04/984 MCN TWY B1 LOCATION SIGN LGT U/S 2504302134-2506010100
4/30/252133Z !MCN 04/983 MCN TWY C TWY DIRECTION SIGN FOR CENTRAL RAMP LGT U/S 2504302133-2506010100
4/30/252133Z !MCN 04/982 MCN TWY C LOCATION SIGN BTN MAIN RAMP AND APCH END RWY 23 LGT U/S 2504302133-2506010100
4/30/252132Z !MCN 04/981 MCN TWY C1 TWY DIRECTION SIGN FOR RWY 14/32 LGT U/S 2504302132-2506010100
4/30/252132Z !MCN 04/980 MCN TWY C HLDG PSN SIGN FOR APCH END RWY 32 LGT U/S 2504302132-2506010100
4/30/252132Z !MCN 04/979 MCN TWY D HLDG PSN SIGN SOUTH SIDE BTN APCH END RWY 32 AND SOUTH RAMP LGT U/S 2504302132-2506010100
4/30/252131Z !MCN 04/978 MCN TWY C1 TWY DIRECTION SIGN FOR TWY C LGT U/S 2504302131-2506010001
4/30/252130Z !MCN 04/977 MCN TWY C1 TWY DIRECTION SIGN FOR TWY C LGT U/S 2504302130-2506010100
4/30/252130Z !MCN 04/976 MCN TWY B3 HLDG PSN SIGN FOR RWY 14/32 LEFT SIDE NOT LGTD 2504302130-2506010100
4/30/252129Z !MCN 04/975 MCN TWY B HLDG PSN SIGN NORTH SIDE FOR APCH END RWY 14 LGT U/S 2504302129-2506010100
4/30/252129Z !MCN 04/974 MCN TWY C HLDG PSN SIGN NORTH SIDE FOR APCH END RWY 23 LGT U/S 2504302129-2506010100
4/30/252128Z !MCN 04/973 MCN TWY C HLDG PSN SIGN SOUTH SIDE FOR APCH END RWY 23 LGT U/S 2504302128-2506010001
4/30/252127Z !MCN 04/972 MCN TWY B HLDG PSN SIGN FOR APCH END RWY 05 LGT U/S 2504302127-2506010001
4/30/252126Z !MCN 04/971 MCN RWY 23 TWY DIRECTION SIGN AT TWY C RIGHT SIDE LGT U/S 2504302126-2506010001
4/30/252126Z !MCN 04/970 MCN RWY 23 EXIT SIGN AT TWY B1 RIGHT SIDE LGT U/S 2504302126-2506010100
4/30/252125Z !MCN 04/969 MCN RWY 05 RWY EXIT SIGN AT TWY B2 LEFT SIDE LGT U/S 2504302125-2506010100
4/30/252125Z !MCN 04/968 MCN RWY 05 RTHL NOT STD 2504302125-2506010001
4/30/252124Z !MCN 04/967 MCN APRON MAIN RAMP DIRECTIONAL SIGN FOR RWY 05 AND RWY 14 NOT LGTD 2504302124-2506010001
4/30/252021Z !MCN 04/960 MCN RWY 05 RWY EXIT SIGN AT TWY C RIGHT SIDE LGT U/S 2504302021-2506010001
4/30/252019Z !MCN 04/958 MCN RWY 14 RWY EXIT SIGN AT TWY D RIGHT SIDE LGT U/S 2504302019-2506010001
4/30/252017Z !MCN 04/957 MCN RWY 05 RWY EXIT SIGN AT TWY C LEFT SIDE LGT U/S 2504302017-2506010001
4/30/252009Z !MCN 04/954 MCN RWY 14 RWY EXIT SIGN AT TWY C LEFT SIDE LGT U/S 2504302009-2506010001
4/30/252000Z !MCN 04/953 MCN RWY 23 RWY EXIT SIGN AT TWY B2 RIGHT SIDE LGT U/S 2504302000-2506010001EST
4/29/251057Z !MCN 04/913 MCN RWY 05 RAI LGT U/S 2504291057-2508042359EST
4/8/250250Z !MCN 04/261 MCN OBST TOWER LGT (ASR 1246729) 324820.90N0834937.10W (11.1NM NW MCN) 888.1FT (349.1FT AGL) U/S 2504080250-2507060400
1/31/251355Z !MCN 01/030 MCN AD AP FIXED BASE OPR NOW AT TERMINAL BLDG 2501311355-2512312359
4/26/212318Z !MCN 04/614 MCN RWY 05 SAFETY AREA NOT STD NW SIDE 236FT WID 2104262318-PERM
1/5/211709Z !MCN 01/149 MCN RWY 14/32 CHANGED TO 5000FT X 100FT. 2101051709-PERM
FDC
4/8/251000Z !FDC 5/3198 MCN IAP MIDDLE GEORGIA RGNL, MACON, GA.
RNAV (GPS) RWY 32, AMDT 1E...
LP MDA 780/HAT 429 ALL CATS, VIS CATS C/D 1 1/4. LNAV MDA 780/HAT 429 ALL CATS, VIS CATS C/D 1 1/4. TEMPORARY CRANES 468 MSL 1.0NM SE OF RWY 32 (2025-ASO-5859/5860-OE).
2504081000-2507301755EST
4/7/251810Z !FDC 5/3202 MCN IAP MIDDLE GEORGIA RGNL, MACON, GA.
ILS OR LOC RWY 5, AMDT 4...
RNAV (GPS) RWY 14, AMDT 2E...
RNAV (GPS) RWY 23, AMDT 2F...
RNAV (GPS) RWY 32, AMDT 1E...
RNAV (GPS) RWY 5, AMDT 3A...
CIRCLING MDA CAT C 980/HAA 626, VIS CAT C 1 3/4.
2504071810-2704071810EST
Yes
0500-2000
FOR SVC AFT HRS HIGHNOTE AVIATION - 478-957-9791.
MACON-BIBB COUNTY
CITY HALL
MACON, GA 31202
Phone: 478-788-3760
DOUGLAS FAOUR
1000 TERMINAL DR
MACON, GA 31297
Phone: 478-219-1145
MACON FSS (MCN)
Toll Free: 1-800-WX-BRIEF
MCN
--
ACTVT MALSR RWY 05; REIL RWY 23 & 32; HIRL RWY 05/23; MIRL RWY 14/32 & TWY LGTS - CTAF.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Major
Major
High & Low Pressure
None
Air Freight
Air Ambulance
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 05/23

6500 ft. x 150 ft.
ASPH
Good
GRVD
HIGH
54 /F/B/W/U
80,000lbs
128,000lbs
237,000lbs
--
  Runway 05 Runway 23
True Heading 48°228°
Traffic Pattern Left Right
Markings PIR NPI
Markings Condition GOOD GOOD
Latitude 32° 41' 10"N 32° 41' 53"N
Longitude 83° 39' 38"W 83° 38' 42"W
Elevation 331' 354'
Threshold Crossing Height -- 67 ft. AGL
Visual Glide Path Angle -- 3°
Visual Slope Indicator -- P4L
Approach Lights MALSR
Centerline Lights
Runway End Identifier Lights Yes

Runway 14/32

5000 ft. x 150 ft.
ASPH
Excellent
GRVD
MED
46 /F/B/W/U
44,000lbs
65,000lbs
110,000lbs
--
  Runway 14 Runway 32
True Heading 130°310°
Traffic Pattern Right Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 32° 41' 54"N 32° 41' 22"N
Longitude 83° 39' 03"W 83° 38' 18"W
Elevation 354' 345'
Threshold Crossing Height 46 ft. AGL 46 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights No Yes
A110-1ROBINS AFB CLASS D AIRSPACE .4 MI SE OF DEP END RY 14. VFR ACFT DEP RY 14 BTN 2000-0800 ARE ADVISED TO CTC ROBINS ATCT 133.22/320.1 PRIOR TO DEP.
A110-2DEER ON & INVOF ARPT.
A110-3PAEW ADJ TO THE MOVEMENT AREAS FROM MARCH 1 TO NOV 1 FOR GRASS CUTTING.
A110-4FOR CD IF UNA TO CTC ON FSS FREQ, CTC ATLANTA APCH AT 678-364-6132, WHEN ATCT CLSD CTC ATLANTA ARTCC AT 770-210-7692.
A110-5NO ACFT WITH WINGSPAN GTR THAN 118 FT MAY TAXI ON TWY C BTN RWY 23 AND RWY 32.
MIDDLE GEORGIA RGNL (ICAO: KMCN, IATA: MCN) is a public airport located in MACON, GA.
